Computers and Networking Systems

1
Computers and Networking Systems

• Class 4.2

2
Chapter 7

• Understanding and Supporting Hard Drives

3
You Will Learn

• About hard drive technologies
• How communication with hard drive BIOS is
  accomplished
• How a hard drive is logically organized to hold
  data
• How to install a hard drive
• How to troubleshoot hard drives

4
Hard Drive Technology

• Technology of how the hard drive interfaces with
  the system
• Technology used within the hard drive to read and
  write data to the drive

5
The EIDE Interface Standards

• Define how hard drives and other drives relate to
  the system
• Drives other than hard drives can use EIDE if
  they follow ATAPI (Advanced Technology Attachment
  Packet Interface)
• Specify data transfer speed more than any other
  single factor
• Most popular ANSI standard is Ultra ATA/100

6
(No Transcript)
7
EIDE Standards

• Support two IDE connections, a primary and a
  secondary
• Each connection can support up to two IDE devices
  for a total of four devices on a system
• Possible configurations
• Primary IDE channel, master device
• Primary IDE channel, slave device
• Secondary IDE channel, master device
• Secondary IDE channel, slave device

8
IDE Channels on a Motherboard
9
Other Interface Standards

• SCSI
• Second most popular interface
• IEEE 1394
• Uses serial transmission
• Popular for multimedia and home entertainment
• Also called FireWire or i.Link
• Fibre Channel
• For high-end systems with multiple hard drives
• Faster than SCSI, but expensive

10
How Hard Drives Work

• Platter(s) are stacked together and spin in
  unison
• Read/write heads are controlled by an actuator
  and move in unison across disk surfaces as disks
  rotate on a spindle
• Require hard drive controller for instructions

11
Hard Drive with Four Platters
12
Hardware Subsystem Including an IDE Hard Drive
13
Tracks and Sectors on IDE Drive

• Older MFM and RLL technologies
• Have 17 or 26 sectors per track over entire drive
  platter
• All tracks contain same number of bytes
• IDE drives use zone bit recording formatting
  system
• Number of sectors per track is not same
  throughout platter
• Tracks near center have smallest number of
  sectors per track
• OS cannot communicate with IDE drive by
  contacting hard drive controller BIOS and using
  sector/track coordinates

14
Older Technologies
15
Zone Bit Recording
16
Low-Level Formatting

• Track and sector markings are written on hard
  drive at the factory
• IDE drives cannot be low-level formatted as part
  of preventive maintenance
• OS does high-level formatting by executing
  remainder of the format process (creating boot
  sector, FAT, and root directory)

17
Adjusting for More Complex Hard Drive Organization

• CHS (cylinder, head, sector) mode or normal mode
  for drives less than 528 MB
• Large mode or ECHS (extended CHS) for drives
  between 504 MB and 8.4 GB
• LBA (logical block addressing) mode for drives
  larger than 504 MB
• OS and software can bypass system BIOS and
  communicate directly with controller BIOS using
  device drivers

18
How a Hard Drive Is Logically Organized to Hold
Data

• Requirements to boot from hard drive and get to a
  command prompt
• Drive must have track and sector markings written
  on it
• A file system must be installed
• Files needed to boot the PC must be copied to
  root directory of drive

19
Preparing a Hard Driveto Hold Files

• Low-level format
• Partition hard drive
• High-level format

20
Hard Drive Partitions

• High-level divisions
• Partition table is 512 bytes long and occupies
  one sector
• Active partition
• Partition of hard drive used to boot OS
• Contains only a single logical drive (drive C)
• Always the first partition on the drive

21
Contents of a Partition Table
22
Logical Drives (Volumes)

• Further division of partitions (primary and
  extended)
• Have letters assigned to them
• Each has its own file system (eg, FAT16, VFAT,
  FAT32)

23
Hard Drive Partitions
24
How Many Logical Drives?

• Use multiple logical drives to optimize space and
  access time to the drive
• The larger the drive, the larger the cluster
  size, and the more slack or wasted space
• Goal is to use as few logical drives as possible
  and still keep cluster size to a minimum
• Use Fdisk, Diskpart, or Disk Management to create
  logical drives

25
How Many Logical Drives?
26
How Many Logical Drives?

27
When to Partition a Drive

• When installing a new hard drive
• If existing hard drive is giving errors
• If you suspect a virus has attacked the drive
• To wipe hard drive clean and install new OS

28
What Happens During Formatting

• OS format for each logical drive creates
• OS boot record
• FAT
• Root directory

29
Installing a Hard Drive

• Set jumpers or DIP switches on drive physically
  install drive inside case attach power cord and
  data cable
• Inform CMOS setup of new drive, or verify that
  autodetect correctly detected the drive
• Use Fdisk utility to create partition(s) on
  drive divide extended partition into logical
  drives
• Use Format command to high-level format each
  logical drive
• Install OS and other software

30
Prepare for Installation

• Read documentation
• Have a good bootable disk or Windows 9x rescue
  disk available
• Plan drive configuration
• Prepare work area and take precautions

31
Preparing for Installation
32
Set Jumpers and DIP Switches
33
Set Jumpers and DIP Switches
34
Set Jumpers and DIP Switches
35
Mount Drive in the Bay
36
Mount Drive in the Bay
37
Mount Drive in the Bay
38
Mount Drive in the Bay
39
Mount Drive in the Bay
40
Mount Drive in the Bay
41
Mount Drive in the Bay
42
If Bay Is Too Large
43
Use CMOS Setup to Change Hard Drive Settings
44
Use CMOS Setup to Change Hard Drive Settings
45
Use CMOS Setup to Change Hard Drive Settings
46
Use CMOS Setup to Change Hard Drive Settings
47
Use Fdisk to Partition a Drive
48
Use Fdisk to Partition a Drive
49
Use Fdisk to Partition a Drive
50
Format Each Logical Drive

• Use these commands
• Format C/S
• Format D
• Format E

51
A Note on Moving a Hard Drive or Changing BIOS

• Back up data on the drive before you move it
• If BIOS on new computer does not let you access
  data on the drive, you can partition and format
  the drive again, and then move the backed-up data
  onto the newly formatted drive
• Dont change options in setup unless you are sure
  of what you are doing

52
An Ounce of Prevention

• Make backups and keep them current
• Run antivirus software regularly
• Defragment files scan hard drive occasionally
• Dont smoke around the hard drive
• Dont leave PC turned off for weeks/months at a
  time
• High humidity can be dangerous for hard drives
• Be gentle with a hard drive

53
Commands to Usewith Hard Drives

• Fdisk
• Format
• Defrag and Windows Disk Defragmenter to detect
  and repair fragmentation
• ScanDisk to correct cross-linked and lost clusters

54
Lost and Cross-Linked Clusters
55
ScanDisk fromCommand Prompt
56
ScanDisk from the Desktop
57
Resolving CommonHard Drive Problems

• Describe/reproduce the problem?
• Computer recently moved?
• New hardware or software recently installed?
• Software recently reconfigured or upgraded?
• History of similar problems?
• Anyone else recently use the computer?

58
Common Hard Drive Problems

• Computer will not recognize newly installed hard
  drive
• Hardware problems
• Hard drive not found
• Invalid drive or drive specification
• Damaged boot record
• Damaged FAT or root directory or bad sectors
• Cannot boot from hard drive
• Drive retrieves and saves data slowly

59
Getting Technical Support

• Before you call
• Drive model and description
• Manufacturer and model of computer
• Exact wording of error message, if any
• Description of problem
• Hardware and software configuration for the system
