DOM

1
DOM

• Document Object Model
• Presented by

• Anthony Corbett

2
What is the DOM?

• The Document Object Model is an platform- and
  language-neutral application programming
  interface (API) for valid HTML and well-formed
  XML documents.

3
Why use the DOM?

• With the Document Object Model, programmers can
  build documents, navigate their structure, and
  add, modify, or delete elements and content.
• Anything found in an HTML or XML document can be
  accessed, changed, deleted, or added dynamically
  using the Document Object Model

4
W3C Recommendations

• The DOM is defined by a set of W3C
  Recommendations that describe a logical object
  structure of documents and the methods used to
  access and manipulate a document.
• The latest Recommendation, the DOM Level 3 Core
  Recommendation, which was released on April 7,
  2004, provides models for manipulating HTML and
  XML documents.

5
Level 1 Level 2

• W3Cs first release, Level 1 Recommendation only
  specified the structure and processing of an
  existing HTML and XML document in a browser
  context.
• Level 2 Recommendation added functionality, a set
  of specifications, updating existing Core and
  HTML modules and adding new modules for Views,
  Events, Style, Traversal, and Range.

6
Level 3

• Level 3 added Abstract Schemas, Load, Save, XPath
  modules and updated the Core and Events modules.
• The DOM Level 3 Core Recommendation specified the
  updated Core and XML modules and underlying
  interfaces, to which this presentation pertains.

7
DOM Architecture
View of the modules, by feature name, defined by
the DOM specifications
Image from W3.org
8
Objective of DOM Specifications

• The objective of the DOM specifications are to
  provide a standard interface that can be used in
  a variety of applications and platforms.
• This means that DOM interfaces are programming
  language-neutral and can be implemented in any
  language.

9
DOM Notation

• The Document Object Model is specified using the
  Interface Description Language (IDL) notation
  defined by the Object Management Group.

10
IDL Example

• interface NodeList
• Node item(int unsigned long index)
• readonly attribute unsigned long length
• This notation must then be translated into a
  specific programming language, like Java.

11
Java binding of IDL example

• package org.w3c.dom
• public interface NodeList
• public Node item(int index)
• public int getLength( )
• Note that there is no length attribute as
  described by the IDL example, this is because
  Java interfaces can not have data members.
  Instead IDL attributes are usually mapped to
  getter and setter methods in a specific interface
  implementation.
• If the attribute is defined readonly the specific
  implementation will only have a getter method, as
  is in this example.

12
DOM Core - Structure Model

• A document parsed by DOM is represented as a
  hierarchical tree of objects in memory.
• Some types of objects may have child objects of
  various types, and others are leaf objects that
  cannot have anything below them in the document
  structure.

13
Generic vs Specific Interfaces

• To simplify different types of document
  processing and enable efficient implementation of
  DOM there are actually two distinct methods for
  accessing a document tree from within the DOM.
• Through the generic interfaces of the Core module
  or the specific interfaces in the XML module.

14
DOM Core Interfaces

• At the root of the DOM Core generic interfaces is
  the Node interface, which provides a generic set
  of methods for accessing a document or documents
  nodes and their content.
• All other interfaces, those specified in the XML
  module, are derived from the Node interface.

15
Derived Node Types
16
Parent, children, siblings

• Each Node-derived object in a parsed DOM document
  contains pointers to its parent, child, and
  sibling nodes.
• These pointers make it possible to using a
  variety of tree-traversal methods to enumerate
  document data in the DOM.

17
Document Node

• Each parsed document causes the creation of a
  single Document node, which is the root of the
  tree.
• As the children of this Document node is the
  DocumentType node and a single Element node that
  contains the entire body of the parsed document
  can be accessed

18
Mapping Structure to Nodes

• ltsample bogus"value"gtlttext_nodegtTest
  data.lt/text_nodegtlt/samplegt

Image from XML in a Nutshell, 3rd Edition
19
XML File

• lt?xml-stylesheet type"text/css"
  href"song.css"?gt
• ltSONG xmlns"http//www.cafeconleche.org/namespace
  /song" xmlnsxlink"http//www.w3.org/1999/xlink"gt

• ltTITLEgtHot Coplt/TITLEgt
• ltPHOTO ALT"Victor Willis in Cop Outfit"
  HEIGHT"200" WIDTH"100" xlinkhref"hotcop.jpg"
  xlinkshow"onLoad" xlinktype"simple"gt
• lt/PHOTOgt
• ltCOMPOSERgtJacques Moralilt/COMPOSERgt
• ltCOMPOSERgtHenri Belololt/COMPOSERgt
• ltCOMPOSERgtVictor Willislt/COMPOSERgt
• ltPRODUCERgtJacques Moralilt/PRODUCERgt
• ltPUBLISHER xlinkhref"http//www.amrecords.com/"
  xlinktype"simple"gt A amp M Records
  lt/PUBLISHERgt
• ltLENGTHgt620lt/LENGTHgt
• ltYEARgt1978lt/YEARgt
• ltARTISTgtVillage Peoplelt/ARTISTgt
• lt/SONGgt

xml file from http//www.ibiblio.org/xml/slides/xm
lone/london2002/advancedxml/06.html
20
The DOM representation
Image from ibiblio.org
21
Java example books.xml

• ltcataloggt
• lt!Sample gt
• ltbook id"101"gt
• lttitlegtXML in a Nutshelllt/titlegt
• ltauthorgtElliotte Rusty Harold, W. Scott
  Meanslt/authorgt ltpricegt39.95lt/pricegt
• lt/bookgt
• ltbook id"121"gt
• lttitlegtWho Moved My Cheeselt/titlegt
• ltauthorgtSpencer, M.D. Johnson, Kenneth H.
  Blanchardlt/authorgt ltpricegt19.95lt/pricegt
• lt/bookgt
• lt/cataloggt

Example from http//www.oracle.com/technology/oram
ag/oracle/03-sep/o53devxml.html
22
Java example continued

• DOMParser parser new DOMParser()
• parser.parse("books.xml")
• Document document parser.getDocument()
• NodeList nodes document.getElementsByTagName("ti
  tle")
• while(int i 0 i lt nodes.length() i )
• Element titleElem (Element)nodes.item(i)
• Node childNode titleElem.getFirstChild()
• if (childNode instanceof Text)
• System.out.println("Book title is "
  childNode.getNodeValue())

Example from http//www.oracle.com/technology/oram
ag/oracle/03-sep/o53devxml.html
23
Advantages

• Easy to use
• Rich set of APIs for easy navigation
• Entire tree loaded into memory, allowing random
  access to XML document

24
Disadvantages

• Entire XML document must be parsed at one time
• Expensive to load entire tree into memory
• Generic DOM node not ideal for object-type
  binding, must create objects for all nodes

25
Summary
Image from http//www.developerlife.com/domintro/
The DOM specifications are a set of interfaces
that define a logical structure of a document and
the methods of accessing the information in the
document.
26
Summary
Image from http//www.developerlife.com/domintro/
Almost all specific interfaces inherit from the
Node interface, which provides generic methods
for accessing information in the object model
tree.
27
Summary

• The DOM is an object model, meaning that all
  data is encapsulated and has methods associated
  with it.
• The DOM is represented as a hierarchical or tree
  structure, with the root being the document node
  and a single root-element node.

Image from http//www.developerlife.com/domintro/
28
Summary

• Each node is a specific type holding the related
  data and the methods to enumerate that data.
• Some nodes have children and some nodes are
  leaves.
• All nodes have knowledge of its parents,
  children, and siblings thus allowing the use of
  well known tree-traversal methods.

29

• Questions?

30
Work Cited

• XML in a Nutshell, 3rd Edition
• http//www.w3.org/TR/DOM-Level-3-Core/
• http//www.developerlife.com/domintro/
• http//www.ibiblio.org/xml/slides/xmlone/london200
  2/advancedxml/
• http//www.oracle.com/technology/oramag/oracle/03-
  sep/o53devxml.html
