CONTROLLED FLIGHT

1

• CONTROLLED FLIGHT
• INTO TERRAIN
• C F I T

2
C F I T

• DEFINITION
• AN EVENT WHERE A MECHANICALLY NORMALLY
  FUNCTIONING AIRPLANE IS INADVERTENTLY FLOWN INTO
  THE GROUND, WATER, OR AN OBSTACLE

3
OVERVIEW FOR MANAGEMENT
4
INTRODUCTION

• CFIT CONTINUES TO BE THE DOMINANT REASON FOR
  ACCIDENTS INVOLVING HULL LOSSES AND FATALITIES
• 9000 PEOPLE HAVE DIED WORLD WIDE BECAUSE OF CFIT
• AT CURRENT RATE CFIT COULD CAUSE ONE MAJOR
  AIRLINE HULL LOSS, AND ASSOCIATED FATALITIES, PER
  WEEK BY YEAR 2010
• IT IS IMPERATIVE THAT CFIT ACCIDENT RATE BE
  LOWERED
• OPERATORS MUST BE MADE AWARE OF THE CFIT PROBLEM
  AS WELL AS TRAINED TO AVOID THESE ACCIDENTS

5
GENERAL GOALS OBJECTIVES

• EDUCATE BOTH OPERATIONAL MANAGEMENT PERSONNEL
• PROVIDE SPECIFIC, APPROPRIATE EDUCATIONAL
  MATERIAL
• PROPOSE AN EXAMPLE TRAINING PROGRAM
• PROVIDE MANAGERS WITH AN EFFECTIVE CFIT AVOIDANCE
  STRATEGY

6
RESOURCE UTILIZATION

• OPERATORS SHOULD USE BOTH THE ACADEMIC AND
  SIMULATOR TRAINING PROGRAM TO ACHIEVE A
  WELL-BALANCED, EFFECTIVE CFIT TRAINING PROGRAM
• ALLOCATION OF TRAINING TIME FOR CFIT WITHIN BOTH
  RECURRENT AND TRANSITION PROGRAM WILL VARY WITH
  EACH OPERATOR

7
DECISION MAKERS GUIDE

• AIRLINE MANAGEMENT CREATES THE SAFETY CULTURE OF
  THE ORGANIZATION. THIS CULTURE THEN AFFECTS
  EVERYONE WITHIN THE ORGANIZATION
• ACCIDENTS AND INCIDENTS ARE PREVENTABLE THROUGH
  EFFECTIVE MANAGEMENT DOING SO IS COST EFFECTIVE

8
C F I T ACCIDENTS
9
HULL-LOSS ACCIDENTS FOR WORLDWIDE COMMERCIAL JET
FLEET
10
CFIT HULL-LOSS ACCIDENTS FOR WORLDWIDE COMMERCIAL
JET FLEET
11
WORLDWIDE AIRLINE ACCIDENTS CLASSIFIED BY TYPE
- 1991 THROUGH 1995
12
WORLDWIDE AIRLINE FATALITIES CLASSIFIED BY TYPE
OF ACCIDENT-1991 THROUGH 1995
13
POSITIVE RESULTS OF GROUND WARNING SYSTEMS (GPWS)
14
CFIT ACCIDENT PER YEAR-USA AND WORLD CARRIERS
15
GPWS INITIAL RELIABILITY AND FOLLOW- ON
IMPROVEMENTS
16
FLIGHT PATH PROFILE 707-300, Santa Maria,
Azores, February 8, 1989
17
INDUSTRY SUPPORT REQUIRED FOR GPWS
18
WORLD AIRLINE JET FLEET EQUIPPED WITH GPWS
19
COMMERCIAL JET CFIT ACCIDENTS 7-YEAR PERIOD-1989
THROUGH 1995
20
CFIT AND FLIGHT CREW
21
CAUSES FOR CFIT ACCIDENTS
22
PRIMARY CAUSE FACTORS FOR HULL-LOSS ACCIDENTS FOR
WORLDWIDE COMMERCIAL JET FLEET
23
FACTORS THAT CONTRIBUTE TO CFIT

• ALTIMETER SETTING UNITS OF MEASUREMENT
• ALTIMETER SETTING
• SAFE ALTITUDES
• AIR TRAFFIC CONTROL
• FLIGHT CREW COMPLACENCY
• PROCEDURAL
• Contd.

24
PERCENTAGE OF ALL ACCIDENTS BY PHASE OF FLIGHT
AND THE PERCENTAGE OF FLIGHT TIME THAT THE FLIGHT
CREW IS EXPOSED DURING THAT PHASE
25
MAP LOCATION OF CFIT ACCIDENTS/INCIDENTS
26
FACTORS THAT CONTRIBUTE TO CFIT

• DESCENT, APPROACH AND LANDING

27
PRIMARY CAUSE FACTORS FOR HULL-LOSS ACCIDENTS FOR
WORLDWIDE COMMERCIAL JET FLEET
28
GEOGRAPHICAL LOCATION OF CFIT ACCIDENTS
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
FACTORS THAT CONTRIBUTE TO C F I T

• AUTOFLIGHT SYSTEM
• TRAINING

33
C F I T PREVENTION

• MINIMUM SAFE ALTITUDE WARNING SYSTEM (MSAWS)

34
(No Transcript)
35
C F I T PREVENTION

• MSAWS
• CREW BRIEFING
• AUTOFLIGHT SYSTEMS
• ROUTE DESTINATION FAMILIARIZATION
• ALTITUDE AWARENESS
• USE OF CALL OUTS
• GPWS WARNING ESCAPE MANEUVER
• CHARTS
• TRAINING

36
EXAMPLE CFITTRAINING PROGRAM
37
ACADEMIC TRAINING PROGRAM
38
ACADEMIC TRAINING PROGRAM

• RECOGNIZE FACTORS THAT LEAD TO CFIT ACCIDENTS AND
  INCIDENTS
• KNOW PREVENTION STRATEGIES THAT WILL ENSURE SAFE
  FLIGHT
• IMPROVE SITUATIONAL AWARENESS TO AVOID CFIT
• LEARN ESCAPE MANEUVER AND TECHNIQUES TO ENHANCE
  POSSIBILITY OF SURVIVAL

39
CFIT SIMULATOR TRAINING PROGRAM
40
SIMULATOR TRAINING OBJECTIVES

• RECOGNIZE CONTRIBUTING FACTORS THAT CAN LEAD TO A
  CFIT INCIDENT
• MAINTAIN PROPER HORIZONTAL AND VERTICAL
  SITUATIONAL AWARENESS
• COMMUNICATE COORDINATE ON FLIGHT DECK DURING
  CRITICAL PHASES OF FLIGHT
• RECOGNIZE A POTENTIAL CFIT SITUATION AND TAKE
  APPROPRIATE ACTION
• GAIN CONFIDENCE IN THE GPWS
• PERFORM A SUCCESSFUL CFIT ESCAPE MANEUVER

41
PILOT SIMULATOR BRIEFING

• REVIEW CONTRIBUTING FACTORS AND CAUSES
• EXPLAIN NEED FOR GOOD FLIGHT CREW COORDINATION
• DISCUSS GPWS OPERATING MODES
• REVIEW AIRPLANE ESCAPE MANEUVER / PROCEDURE AND
  PILOT TECHNIQUES
• DISCUSS COMMON FLIGHT CREW ERRORS

42
GENERIC GPWS WARNING ESCAPE MANEUVER

• REACT IMMEDIATELY TO A GPWS WARNING
• POSITIVELY APPLY MAXIMUM THRUST AND ROTATE TO
  THE APPROPRIATE PITCH FOR YOUR AEROPLANE
• PULL UP WITH WINGS LEVEL TO ENSURE MAXIMUM
  PERFORMANCE
• ALWAYS RESPECT STICK SHAKER

43
GROUND PROXIMITY WARNING MODES (MARK VI)
44
GPWS MODE 1
45
GPWS MODE 1
46
GPWS MODE 2
47
GPWS MODE 3
Fig.4
48
GPWS MODE 4
49
GPWS MODE 4
Fig. 4
50
GPWS MODE 5
51
GPWS MODE 6
52
ICAO ACTION ON CFIT PREVENTION

• EXPANDED GPWS CARRIAGE REQUIREMENTS (31
  DECEMBER 1998)
• MINIMUM GPWS MODE REQUIREMENTS (31
  DECEMBER 1998)
• NON-PRECISION APPROACH PROCEDURE DESIGN
• SPECIFICATIONS FOR INSTRUMENT APPROACH CHARTS AND
  OTHER CHARTS (SID, STAR, AND TERMINAL AREA)

53
ICAO ACTION ON CFIT PREVENTION (2)

• FUTURE PUBLICATION OF THE CFIT PREVENTION
  PROGRAMME
• FUTURE MAJOR EFFORT TO ENSURE IMPLEMENTATION OF
  THE PROGRAMME IN INTERNATIONAL AND IN DOMESTIC
  OPERATIONS
