Properties of a Gas

1
Properties of a Gas

• Edward A. Mottel
• Department of Chemistry
• Rose-Hulman Institute of Technology

2
Properties of a Gas

• Reading Assignment Fine, Beall Stuehr, Chapter
  4.1-4.6
• This lecture introduces the interrelated
  dependence of moles, temperature, pressure and
  volume of a confined gas.
• Based on assumptions of ideal gas behavior, these
  parameters when combined form the ideal gas
  equation, PVnRT.

3
Gases
No long or short range structural order
Large intermolecular distances, compared to
molecular size
What happens when the stopcock is opened?
4
Gases
Mix together in any proportions
Intermolecular collisions are elastic -- energy
is transferred through collisions
5
Important Physical Properties of a Gas

• Temperature
• Pressure
• Volume
• Moles

6
Temperature

• Temperature is a measure of molecular motion
  vibration, rotation and translation
• Gases move at high velocity
• (gt 1000 msec1)
• Common units
• Celsius (C), Fahrenheit (F)
• Absolute units Kelvin (K), Rankine (R)

7
Temperature

• Absolute units Kelvin (K), Rankine (R)
• 0.00 C 273.15 K
• 32.00 F 491.67 R
• 100.00 C 373.15 K
• 212.00 F 671.67 R
• Isothermal - constant temperature

8
Pressure
Due to molecules hitting the surface
Force per unit area
9
Pressure
What do you know about
the pressure in a balloon?
10
Pressure
11
Barometer
What forces determine the height of the
mercury in the glass tube?
12
Barometer
What forces determine the height of the
mercury in the glass tube?
atmospheric pressure
13
Barometer
1.03 kgcm2 14.7 lbin2
14
Barometer
33 feet
15
Pressure

• Common units
• lbsin2, atmospheres (atm), mm Hg, torr, pascals
  (Nm2, Pa)
• 1.00 atm 14.7 lbsin2
• 760 mm Hg 760 torr
• 1.013 x105 Pa

16
Pressure

• The actual atmospheric pressure is a function of
  the weather (high or low pressure) and altitude.
• Typical Terre Haute pressure is 730-750 mm Hg.
• Isobaric - constant pressure

17
Volume

• Gases occupy the complete volume to which they
  are constrained
• Liquids and solids occupy a volume corresponding
  to their mass and density
• Isochoric - constant volume

18
Moles

• A counting unit for the number of molecules being
  considered

19
Physical Laws of Gases

• Boyle's Law
• Charles' Law
• Avogadro's Law
• Ideal Gas Law

20
Boyle's Law

• PV constant

isothermal constant amount of gas
What does a plot of this relationship look like?
21
Charles' Law

• VµT

isobaric constant amount of gas
What does a plot of this relationship look like?
What does the y-intercept indicate?
22
Avogadro's Law

• Vµn

isobaric isothermal
What does a plot of this relationship look like?
23
Ideal Gas Law

• PV µ nT
• PV nRT
• where R ideal gas constant
• 0.08205 Latmmol1K1

24
Boyle's Law

• PV constant

How will this plot change if the same number
of moles of gas are at a higher temperature?
25
Common GasesRoom Temperature, One Atmosphere
Pressure

• Monatomic He, Ne, Ar, Kr, Xe, Rn
• Polyatomic
• Elements N2, O2, O3, F2, Cl2
• Compounds CO, CO2, NO, N2O, NO2, N2O4, N2O5,
  CH4, C2H6, C2F4, etc.

26
Atmospheric Composition

• Dry air
• 78 N2, 21 O2, 1Ar
• Normal air
• N2, O2, Ar, 0.03 CO2, 1.6 H2O

27
(No Transcript)
28
(No Transcript)
29
Boyle's Law

• PV constant

isothermal constant amount of gas
30
Charles' Law

• VµT

isobaric constant amount of gas
What does the y-intercept indicate?
31
Avogadro's Law

• Vµn

isobaric isothermal
32
Boyle's Law

• PV constant
