Scheduling Flowcast 3'0

1
Scheduling Flowcast 3.0

• Midwest Regional User Group Meeting
• March 22, 2004

2
What are the known updates?

• References to "Visit(s)" referring to
  appointments will be replaced with the word
  "Appointment(s)
• Notes field for the on-line bump list
• Notes field for the on-line wait list
• Significant changes to Schedule Set-up and
  Maintenance

3
What are the known updates?

• Changes to the way Master schedule information is
  displayed
• After distributing a master, the system displays
  "conflict" work list of days that did not get
  changed.
• Conflict list displays information as to why the
  daily schedule is on the list, i.e. day in use,
  day had appts, day has been edited.
• Ability to distribute Master to days on conflict
  list
• Ability to view daily schedules from conflict
  list
• Ability to remove past date schedules from
  conflict list

4
What are the known updates?

• Ability to remove a date from the list of days to
  transfer a template
• Additional Daily and Template changes
• Enhanced daily schedule audit trail

5
Visit to Appointment Change

• In Sched, anywhere the word visit" appeared
  where it was referring to an appointment was
  replaced with the word "Appointment
• Examples
• Appt Type from Visit Type
• Appointment Data Form from Visit Data Form
• Why?
• Sched books appointments
• AVM creates visits

6
Bump List Notes

• A new action code N appears on the on-line bump
  list
• A note on can be entered by typing an E to edit
  the word processing field.
• Uses
• Documentation of patient contact
• Documentation of actions taken to reschedule the
  appointment

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
Wait List Notes

• A new action code N appears on the on-line wait
  list
• A note on can be entered by typing an E to edit
  the word processing field.
• Uses
• Documentation of attempts to contact patient
• Documentation of patient responses to the
  possibility of moving up appointment

11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Appearance Changes

• Scheduling and session comments moved off the
  first screen
• Vertical sessions format
• Action codes for editing
• Freeze labels on the right side of the screen
• New screen for adding a superslot
• Actions are added as situations arise on the
  screens for them to be used.

15
(No Transcript)
16
(No Transcript)
17
Table of Action Codes
18
Table of Action Codes
19
Action Code A

• To define a new session or edit the information
  for an existing session, press A.
• A bottom form will display on which you will
  specify the session, AM, PM or EVE.
• Then you can add or edit the ending time and the
  location for the session selected.
• NOTE EVE sessions have a system defaulted end
  time of 1200 midnight. This can not be
  overridden by the user.

20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Action Code S

• In order to add a regular slot or a non-clinic
  slot, you press S.
• A bottom form will appear in which you will
  specify the
• Session where you want to add a slot
• Start time of the slot
• Appointment type
• Allocation, i.e., how many of that appointment
  type you want to allow at that time.
• If the appointment type is defined as a
  non-clinic type, you will have to enter the
  duration in minutes you want the non-clinic type
  to be effective.
• Press file when you are finished, and you will
  be taken back into the top screen.

24
(No Transcript)
25
(No Transcript)
26
Action Code U

• In order to add a superslot, press U.
• After the new screen opens, enter the following
  information
• Session where you want to add the slot
• Begin time of the first appointment in the
  superslot
• End time of the last appointment in the
  superslot,
• Interval (using the lowest common denominator for
  all the appointments to be included in the
  superslot)
• Repeat count. (how many appointments you want to
  allow for each interval duration)

27
(No Transcript)
28
Action Code U (cont.)

• For Superslots using ANY or WLK slots
• At the Type to Include field, accept the
  default of ANY to use ANY, ANY, WLK or WLK
• The total allocation will default in.
• To set the superslot up for WLK, or WLK, enter a
  Y at the Accommodate Walk-ins field.
• If you want to use an ANY or WLK, enter the
  appointment types to exclude, i.e., those not
  allowed in the slot, under the Excluding prompt

29
(No Transcript)
30
(No Transcript)
31
Action Code U (cont.)

• For Superslots using specific appointment types
• At the Types to include prompt, change the ANY
  to SPECIFIC
• The screen changes so that you have a place to
  enter the appointment type(s) and allocation.
• When you are finished entering appointment types,
  file.
• Note When specifying appointment types, the
  allocation is for each appointment type, not the
  superslot as a whole.

32
(No Transcript)
33
(No Transcript)
34
Action Code E

• To edit an existing regular slot, select the
  slot(s) and press E.
• A bottom form will open where you can edit the
  appointment
• Time
• Type
• Allocation

35
(No Transcript)
36
Action Code E (cont.)

• To edit an existing superslot, select the slot
  header and press E.
• A new screen will open where you can edit the
  superslot information
• If you are editing a superslot in a master
  schedule, the following information can be
  edited
• Begin time
• End time
• Interval
• Repeat count
• Appointment type
• Allocation

37
(No Transcript)
38
Action Code E (cont.)

• If you are editing a superslot in a daily
  schedule, the following information can be
  edited
• Repeat count
• Appointment type
• Allocation

39
(No Transcript)
40
Action Code F

• To freeze or future freeze/thaw slots, select the
  slot(s) you want to freeze and press F.
• A bottom form will open where you may enter
  freeze/thaw information if desired.
• F10 to accept the N default at the Define
  Thaw information? to freeze a slot.
• Change the default to Y at the Define Thaw
  information? to add future thaw information.
• At the Thaw day(s) before schedule date,
  enter the number of days prior to the future date
  for the system to thaw the slot.
• F10 when finished. Freeze or Freeze/Thaw
  will appear in the display to indicate the slot
  is frozen.

41
(No Transcript)
42
(No Transcript)
43
Action Code F (cont.)

• If a slot is already frozen with a regular freeze
  (not future freeze/thaw) and you want to change
  the slot to a future freeze/thaw, you will have
  to
• Thaw the slot first
• Then re-freeze it, applying the freeze/thaw
  information at the time you are freezing the slot.

44
Action Code W

• To specify an appointment type switch on a
  regular slot(s), select the slot(s) and press W.
• Complete the information in the bottom form that
  appears including
• Appointment type you want to switch to
• How many of that appointment type you want to
  allow
• How many days before the schedule date you want
  the switch to occur.

45
(No Transcript)
46
Action Code W (cont.)

• For a superslot, you can either switch the whole
  superslot to an ANY, or for each appointment type
  defined in the superslot you can specify a
  different appointment type to switch to.
• You also set the number of appointments you wish
  to allow.
• Note, you cannot change more than one
  appointment type to the same switch to
  appointment type.

47
(No Transcript)
48
(No Transcript)
49
Action Code X

• To see the detail information on future freeze
  thaws and switches, press X.
• The freeze/thaw or switch information is
  displayed in the line underneath the slot.

50
(No Transcript)
51
Action Code V

• This action code is only valid for daily
  schedules
• To see a before and after snapshot of changes
  made to the daily schedule, press V.
• A screen will open on which you can see some
  information about changes to the daily schedule
  including the
• Date and time of the edit
• Username of the person who made the change
• Transaction number of the change from the main
  Sched Audit Trail
• Type of edit made.

52
Action Code V (cont.)

• At the bottom of the screen there are two
  additional action codes.
• V allows you to view the before and after view of
  the day.
• To scroll this display and see more time slots,
  type an F for forward or a B for backward.
• When there has been more than one type of edit
  made to the schedule at one time, for example
  Slot changed and Comment changed, a set of
  ellipses (...) will be displayed next to the type
  of edit.
• To see the other edits made, press X to expand
  the display. The other types of edits are listed
  underneath the first edit for the slot.

53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
Action Code Y

• This action code is only valid for Master
  Schedules
• Pressing Y opens a bottom form on which you can
  specify the date you want the master to end.
• After you file the master, you will get a list of
  daily schedules that were affected by adding the
  end date.
• You cannot do anything to these dates from this
  page. These daily schedules must be fixed by
  either deleting them or by creating a new master
  schedule for the same day(s) of the week and
  cycle (recurrence).

57
(No Transcript)
58
(No Transcript)
59
Action Code B

• This action code is only valid for Templates.
• To add or edit the description of a template,
  press B
• A bottom form will appear where you can add or
  edit the template description.
• F10 when you are finished with the description.

• Note This is the text that displays when you
  type a ? at a template prompt and will help you
  to identify the correct template with which you
  want to work.

60
(No Transcript)
61
Action Code C

• Pressing a C will take you to the Schedule
  Comment and Session Comments that formerly
  appeared on the opening Add/Edit screen.
• The Schedule Comment is a typically used as a
  descriptor for the person managing the schedules.
  Schedulers will not see these.
• The Session Comments are messages for to help the
  schedulers correctly utilize the schedules.

62
(No Transcript)
63
Action Code D

• To delete a slot or series of slots, select the
  slot(s) and press D.
• The slots will be immediately deleted.
• If you deleted any slots in error, cancel out of
  the edits without filing.

64
(No Transcript)
65
Action Code R

• To remove appointment type switches on a slot,
  select the slot(s) and press R.
• A message will appear if you are removing a
  switch for an entire superslot notifying you that
  you can remove individual switches using Action
  Code W.

66
(No Transcript)
67
Action Code T

• To thaw (unfreeze) a slot, select the slot(s) and
  press T.
• The slots will be immediately thawed.
• If you thawed any slots in error, cancel out of
  the edits without filing or refreeze them using
  Action Code F.

68
Removing a day when transferring a template

• When transferring a template, if an errant day is
  entered while listing all the days to transfer
  the template to, the incorrect dates can be
  deleted by pressing the NumLock key following
  by pressing Enter

69
(No Transcript)
70
(No Transcript)
71
Conflict List

• Stops the need to print master schedule
  discrepancy reports
• On-line available to show days schedules did not
  distribute to.
• Includes the reason the schedule did not
  distribute to a certain day.
• Allows the user to view the daily and/or master
  schedule before deciding whether or not to
  distribute the schedule anyway

72
(No Transcript)
73
(No Transcript)
74
V Action Code Brings you to this screen
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
