Instruction Set Issues

1
(No Transcript)
2
Instruction Set Issues

• MIPS easy
• Instructions are only committed at MEM?WB
  transition
• Other architectures are more difficult
• Instructions may update state early
• FP more difficult
• Memory updating ops (e.g. string moves)

3
Instruction Set Issues (cont.)

• Difficult architectural features
• Odd bits of state (e.g. condition codes)
• May need saving/restoring on exceptions
• Implicitly set condition codes
• Complicate branch resolution
• Explicit setting helps here (still a RAW hazard)
• Multicycle operations
• Widely differing execution times, lots of
  potential data hazards, etc.

4
Instruction Set Issues

• VAX suffers from many of these problems
• Solution pipeline the microcode
• Intel 32-bit 80x86 processors since 1995 use a
  similar approach

5
A.5. Handling Multicycle Operations

• MIPS FP operations
• Long latency (EX repeated)
• Several functional units
• Structural hazards
• Data hazards

6
DLX FP Design

• Four functional units
• Integer ALU
• as before
• FP multiplier
• also used for integer multiplication
• FP adder
• addition, subtraction and conversion
• FP divider
• also used for integer division

7
MIPS Design with FP Units
8
MIPS Multicycle Operations
Unit Latency Initiation Interval
Integer ALU 0 1
Memory (loads) 1 1
FP add 3 1
FP multiply 6 1
FP divide 24 25
9
Hazards

• Divides
• Structural hazard
• Multiple register writes possible in a cycle
• Out-of-order completion
• WAW hazards
• Exception-handling complications
• RAW hazards increase

10
Potential RAW Hazards

• Example (SPARC syntax)

ldd fp-8, f4 fmuld f4, f6, f0 faddd
f0, f8, f2 std f2, fp-16
Instr. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
ld F D X M W
mul F D X X X X X X X M W
add F D X X X X M W
st F D X M
11
Multiple Writes

• Up to four instructions may need to write in the
  same cycle
• Solution
• Track writes in ID
• Stall at instruction issue
• Alternatively
• Stall at MEM or WB
• Stall instruction with shorter latency (may free
  RAW hazards)

12
WAW Hazards

• Example

faddd f4, f6, f2 !
Integer op ldd fp-8, f2
Instr. 1 2 3 4 5 6 7 8
faddd F D X X X X M W
F D X M W
ldd F D X M W
13
WAW Hazards (cont.)

• Rare
• Compiler scheduling may result in unlikely
  instruction sequences, so must be caught
• Solutions
• Stall issue of ldd
• Prevent write by faddd

14
Maintaining Precise Exceptions

• Out-of-order completion

fdivd f2, f4, f0 faddd f10, f8, f10 fsubd
f12, f14, f12

• Sub may cause an exception after add is complete,
  but not div
• No longer precise

15
Maintaining Precise Exceptions

• It may be very difficult to handle exceptions
  precisely
• E.g. the add has destroyed one of its operands!
• Four solutions
• Accept imprecise exceptions
• Needed for VM IEEE FP
• Allow switching between precise and imprecise
  modes

16
Maintaining Precise Exceptions

• Solutions (cont.)
• Buffer results until earlier instructions
  complete
• Buffers may grow very large, and extensive
  forwarding required
• History files restore original register values
• Future files store new register values
• Software executes intervening instructions to get
  up to date before returning from exception

17
Maintaining Precise Exceptions

• Solutions (cont.)
• Hybrid scheme
• Instructions are only issued when it is certain
  that preceding instructions will not cause an
  exception
• May require stalling the pipeline

18
Performance of the MIPS FP Pipeline

• Structural Hazards (divide unit)
• Very low 0-2 cycles per FP operation
• RAW hazards
• Divide 12-24 cycles, average 14.2
• Add 0.7-2.3 cycles, average 1.7
• In general, about 0.5 latency

19
Overall MIPS FP Performance

• Stalls per instruction
• 0.65-1.21 cycles
• Average 0.87
• 82 from FP RAW hazards

20
A.6. Putting It All TogetherMIPS R4000 Pipeline

• 64-bit instruction set
• Eight stage pipeline
• superpipelining
• IF IS instruction fetch
• RF decode/register fetch
• EX execution
• DF DS TC data cache access
• WB write back

21
MIPS R4000 Pipeline

• Performance
• Load delay two cycles
• Branch delay three cycles
• Delayed branch (one cycle)
• Predict-not-taken strategy, with anulling
• Increased forwarding requirements
• Three stages between EX and WB now

22
MIPS R4000 Pipeline

• Floating Point
• Three functional units
• Divider, multiplier, adder
• Shared components (8 sub-units)
• Latency 2112 cycles
• Initiation rate 1111 cycles
• Complicated stall handling

23
MIPS R4000 Pipeline

• Performance
• CPI between 1.2 and 2.8 for SPEC92 benchmarks
• Average 2.0
• Integer 1.54
• FP 2.48
• Integer apps mainly branch delays
• FP apps mainly FP data hazard stalls (RAW)

24
