Improving Hash Join Performance Through Prefetching

1
Improving Hash Join Performance Through
Prefetching
Shimin Chen
Anastassia Ailamaki
Todd C. Mowry

Phillip B. Gibbons
2
Hash Join

• Simple hash join
• Build hash table on smaller (build) relation
• Probe hash table using larger (probe) relation
• Random access patterns inherent in hashing
• Excessive random I/Os
• If build relation and hash table cannot fit in
  memory

3
I/O Partitioning

• Avoid excessive random disk accesses
• Join pairs of build and probe partitions
  separately
• Sequential I/O patterns for relations and
  partitions
• Hash join is CPU-bound with reasonable I/O
  bandwidth

Build
Probe
4
Hash Join Cache Performance

• Partition divides a 1GB relation into 800
  partitions
• Join 50MB build partition 100MB probe
  partition
• Detailed simulations based on Compaq ES40 system
• Most of execution time is wasted on data cache
  misses
• 82 for partition, 73 for join
• Because of random access patterns in memory

5
Employing Partitioning for Cache?

• Cache partitioning generating cache-sized
  partitions
• Effective in main-memory databases Shatdal et
  al., 94, Boncz et al., 99, Manegold et
  al.,00
• Two limitations when used in commercial databases
• Usually need additional in-memory partitioning
  pass
• Cache is much smaller than main memory
• 50 worse than our techniques
• 2) Sensitive to cache sharing by multiple
  activities

6
Our Approach Cache Prefetching

• Modern processors support
• Multiple cache misses to be serviced
  simultaneously
• Prefetch assembly instructions for exploiting the
  parallelism
• Overlap cache miss latency with computation
• Successfully applied to
• Array-based programs Mowry et al., 92
• Pointer-based programs Luk Mowry, 96
• Database B-trees Chen et al., 01

7
Challenges for Cache Prefetching

• Difficult to obtain memory addresses early
• Randomness of hashing prohibits address
  prediction
• Data dependencies within the processing of a
  tuple
• Naïve approach does not work
• Complexity of hash join code
• Ambiguous pointer references
• Multiple code paths
• Cannot apply compiler prefetching techniques

8
Our Solution

• Dependencies are rare across subsequent tuples
• Exploit inter-tuple parallelism
• Overlap cache misses of one tuple with
  computation and cache misses of other tuples
• We propose two prefetching techniques
• Group prefetching
• Software-pipelined prefetching

9
Outline

• Overview
• Our Proposed Techniques
• Simplified Probing Algorithm
• Naïve Prefetching
• Group Prefetching
• Software-Pipelined Prefetching
• Dealing with Complexities
• Experimental Results
• Conclusions

10
Simplified Probing Algorithm

• foreach probe tuple
• (0)compute bucket number
• (1)visit header
• (2)visit cell array
• (3)visit matching build tuple

11
Naïve Prefetching

• foreach probe tuple
• (0)compute bucket number
• prefetch header
• (1)visit header
• prefetch cell array
• (2)visit cell array
• prefetch matching build tuple
• (3)visit matching build tuple

Data dependencies make it difficult to obtain
addresses early
12
Group Prefetching
a group

• foreach group of probe tuples
• foreach tuple in group
• (0)compute bucket number
• prefetch header
• foreach tuple in group
• (1)visit header
• prefetch cell array
• foreach tuple in group
• (2)visit cell array
• prefetch build tuple
• foreach tuple in group
• (3)visit matching build tuple

13
Software-Pipelined Prefetching

• Prologue
• for j0 to N-4 do
• tuple j3
• (0)compute bucket number
• prefetch header
• tuple j2
• (1)visit header
• prefetch cell array
• tuple j1
• (2)visit cell array
• prefetch build tuple
• tuple j
• (3)visit matching build tuple
• Epilogue

14
Dealing with Multiple Code Paths

• Multiple code paths
• There could be 0 or many matches
• Hash buckets could be empty or full
• Keep state information for tuples being processed

Record state

• Test state to decide
• Do nothing, if state B
• Execute D, if state C
• Execute G, if state F

• Previous compiler techniques cannot handle this

15
Dealing with Read-write Conflicts

• In hash table building

• Use busy flag in bucket header to detect
  conflicts
• Postpone hashing 2nd tuple until finish
  processing 1st
• Compiler cannot perform this transformation

16
More Details In Paper

• General group prefetching algorithm
• General software-pipelined prefetching algorithm
• Analytical models
• Discussion of important parameters
• group size, prefetching distance
• Implementation details

17
Outline

• Overview
• Our Proposed Techniques
• Experimental Results
• Setup
• Performance of Our Techniques
• Comparison with Cache Partitioning
• Conclusions

18
Experimental Setup

• Relation schema 4-byte join attribute fixed
  length payload
• No selection, no projection
• 50MB memory available for the join phase
• Detailed cycle-by-cycle simulations
• 1GHz superscalar processor
• Memory hierarchy is based on Compaq ES40

19
Joining a Pair of Build and Probe Partitions

• A 50MB build partition joins a 100MB probe
  partition
• 12 matching
• Number of tuples decreases as tuple size increases

• Our techniques achieve 2.1-2.9X speedups over
  original hash join

20
Varying Memory Latency

• A 50MB build partition joins a 100MB probe
  partition
• 12 matching
• 100 B tuples

• 150 cycles default parameter
• 1000 cycles memory latency in future
• Our techniques achieve 9X speedups over baseline
  at 1000 cycles
• Absolute performances of our techniques are very
  close

21
Comparison with Cache Partitioning

• A 200MB build relation joins a 400MB probe
  relation
• 12 matching
• Partitioning join

• Cache partitioning generating cache sized
  partitions Shatdal et al., 94, Boncz et al.,
  99, Manegold et al.,00
• Additional in-memory partition step after I/O
  partitioning
• At least 50 worse than our prefetching schemes

22
Robustness Impact of Cache Interference

• Cache partitioning relies on exclusive use of
  cache
• Periodically flush cache worst case interference
• Self normalized to execution time when no flush
• Cache partitioning degrades 8-38
• Our prefetching schemes are very robust

23
Conclusions

• Exploited inter-tuple parallelism
• Proposed group prefetching and software-pipelined
  prefetching
• Prior prefetching techniques cannot handle code
  complexity
• Our techniques achieve dramatically better
  performance
• 2.1-2.9X speedups for join phase
• 1.4-2.6X speedups for partition phase
• 9X speedups at 1000 cycle memory latency in
  future
• Absolute performances are close to that at 150
  cycles
• Robust against cache interference
• Unlike cache partitioning
• Our prefetching techniques are effective for hash
  joins

24
Thank you !
25
Back Up Slides
26
Is Hash Join CPU-bound ?

• 550MHz CPUs, 512MB RAM, Seagate Cheetah X15 36LP
  SCSI disks (max transfer rate 68MByte/sec),
  Linux 2.4.18
• 100B tuples, 4B keys, 12 matching
• Striping unit 256KB
• 10 measurements, std lt 10 mean or std lt 1s

• Quad-processor Pentium III, four disks
• A 1.5 GB build relation, a 3GB probe relation
• Main thread GRACE hash join
• Background I/O thread per disk I/O prefetching
  and writing
• Hash join is CPU-bound with reasonable I/O
  bandwidth
• Still large room for CPU performance improvement

27
Hiding Latency within A Group

• Hide cache miss latency across multiple tuples
  within a group
• Group size can be increased to hide most cache
  miss latency for hash joins
• Generic algorithm and analytical model (please
  see paper)
• There are gaps between groups

28
Prefetching Distance
D1

• Prefetching distance (D) the number of
  iterations between two subsequent code stages for
  a single tuple
• Increase prefetching distance to hide all cache
  miss latency
• Generic algorithm and analytical model (please
  see paper)

29
Group Pref Multiple Code Paths
A

• We keep state information for tuples in a group
• One of the states decides which code path to take

30
Prefetching Distance D

• Prologue
• for j0 to N-3D-1 do
• tuple j3D
• compute hash bucket number
• prefetch the target bucket header
• tuple j2D
• visit the hash bucket header
• prefetch the hash cell array
• tuple jD
• visit the hash cell array
• prefetch the matching build tuple
• tuple j
• visit the matching build tuple to
• compare keys and produce output tuple
• Epilogue

31
Experiment Setup

• We have implemented our own hash join engine
• Relations are stored in files with slotted page
  structure
• A simple XOR and shift based hash function is
  used
• GRACE hash join (baseline), Simple prefetching,
  Group prefetching, Software-pipelined
  prefetching
• Experiment Design
• Same schema for build and probe relations
• 4-byte key fixed length payload
• No selection and projection
• 50MB memory available for the joins

32
Simulation Platform

• Detailed cycle-by-cycle simulations
• Out-of-order processor pipeline
• Integer multiply and divide latency are based on
  Pentium4
• Memory hierarchy is based on Compaq ES40
• memory system parameters in near future
• better prefetching support
• Supports TLB prefetching

33
Simulation Parameters
34
Simulator vs. Real Machine

• Better prefetching support
• Never ignore prefetching
• Our prefetches are not hints!
• TLB prefetching
• When a prefetch incurs a TLB miss, perform TLB
  loading
• More miss handlers
• 32 for data

35
Varying Group Size and Prefetching Distance

• Varying params for the 20B case in the previous
  figure
• Hash table probing

• Too small latencies are not fully hidden
• Too large many prefetched cache lines are
  replaced by other memory references
• Similar performance even when latency increases
  to 1000 cycles!

36
Breakdowns of Cache Misses to Understand the
Tuning Curves
37
Cache Performance Breakdowns

• Our schemes indeed hide most of the data cache
  miss latencies
• Overheads lead to larger portions of busy times

38
Partition Phase Performance

• When the number of partitions is small, use
  simple prefetching
• When the number of partitions is large, use group
  or software-pipelined prefetching
• Combined 1.9-2.6X speedups over the baseline

39
Cache Partitioning Schemes

• Two ways to employ cache partitioning in GRACE
  join
• Direct cache generate the cache partitions
  in the I/O partition
  phase
• Two-step cache generate the cache partitions in
  the join phase as a
  preprocessing step
• Requires to generate larger number of smaller I/O
  partitions
• Bounded by available memory
• Bounded by requirements of underlying storage
  managers
• So cache partitioning may not be used when
  joining relations are very large
• Not robust with multiple activities going on
• Require exclusive use of (part of) cache
• Performance penalty due to cache conflicts

40
Comparison with Cache Partitioning

• Direct cache suffers from larger number of
  partitions generated in the I/O partition phase
• Two-step cache suffers from the additional
  partition step
• Our schemes are the best (slightly better than
  direct cache)

41
Robustness Impact of Cache Interference
100 corresponds to the join phase execution
time when there is no cache flush

• Performance degradation when the cache is
  periodically flushed
• The worst cache interference
• Direct cache and 2-step cache degrade 15-67 and
  8-38
• Our prefetching schemes are very robust

42
Group Pref vs. Software-pipelined Pref

• Hiding latency
• Software-pipelined pref is always able to hide
  all latencies (according to our analytical model)
• Book-keeping overhead
• Software-pipelined pref has more overhead
• Code complexity
• Group prefetching is easier to implement
• Natural group boundary provides a place to do
  necessary processing left (e.g. for read-write
  conflicts)
• A natural place to send outputs to the parent
  operator if pipelined operator is needed

43
Challenges in Applying Prefetching

• Try to hide the latency within the processing of
  a single tuple
• Example hash table probing
• Does not work
• Dependencies essentially form a critical path
• Randomness makes prediction almost impossible

Hash Cell Array
BuildPartition
HashBucketHeaders
44
Naïve Prefetching

• foreach probe tuple
• compute bucket number
• prefetch header
• visit header
• prefetch cell array
• visit cell array
• prefetch matching build tuple
• visit matching build tuple

1
2
3
Data dependencies make it difficult to obtain
addresses early
45
Group Prefetching

• foreach group of probe tuples
• foreach tuple in group
• compute bucket number
• prefetch header
• foreach tuple in group
• visit header
• prefetch cell array
• foreach tuple in group
• visit cell array
• prefetch matching build tuple
• foreach tuple in group
• visit matching build tuple

46
Software-Pipelined Prefetching

• Prologue
• for j0 to N-4 do
• tuple j3
• compute bucket number
• prefetch header
• tuple j2
• visit header
• prefetch cell array
• tuple j1
• visit cell array
• prefetch matching build tuple
• tuple j
• visit matching build tuple
• Epilogue
