C3 International, LLC

1
C3 International, LLC
Molecular Infusion Surface Treatment (MIST)

• Technology Overview

2
C3 International

• Founded in 1999 to commercialize diffused oxide
  nano-films
• Headquarters Alpharetta, GA (Atlanta)
• Oak Ridge National Labs (ORNL) Partnership
• Winner, 2006 RD 100 Award
• Provide Services and Products
• Revolutionary Nanometer-Scale Surface Treatment
  Technology
• Ultra-thin films of chosen elements and oxides
• Molecular Infusion Surface Treatment (M.I.S.T.)
• Contract treatment services and OEM Licensing

3
C3 Molecular Infusion Surface Treatment

• Oxide nanoparticles can provide superior
  mechanical and chemical performance in surface
  treatment applications
• Attachment method of oxides in ultra-thin films
  has been elusive
• Diffusion process for various elements (oxides
  and metals) was discovered in Russian research
  laboratories circa 1995
• Technology was acquired by U.S. group and has
  been developed into a viable commercial process

4
Nano-scale for IC Industry

• Materials science being driven by integrated
  circuit industry
• Technical advances expand into other industries

5
C3 Nano-scale Thin Films
100 to 500 nanometers (.1micron to .5
microns)
C3
Ultra -Thin Film
40 to 50 nanometers (.04 to .05 microns)
C3
Infusion Layer
Substrate Material

• Substrates of
• Metals
• Carbides
• Ceramics
• Cermets
• Single Crystals
• Non-Organic Material

• The C3 process results in a conformal surface
  treatment diffused into substrate
• Thicknesses of thin film 0.1 micron to 0.5
  micron (100 nm 0.1 µm)
• Infusion layer produces a alloy layer firmly
  attached to substrate 50 nm deep

6
Infused Thin Films

• Superior adhesion possible
• with forced-diffusion into
• substrate inner-granular boundaries
• Nano-scale thin film becomes
• locked to host material
• During mechanical or chemical attack, residual
  effects remain
• If thin film is worn away, substrate retains
  performance characteristics
• A result of the inner-granular diffusion alloy
  layer
• Opens possibility of downgrading a tools
  substrate and upgrading the wearing surface only
• Put investment into the surface, not the core of
  the tool

7
Comparison Surface Treatment Methods
8
M.I.S.T. Process Attributes

• Wide variety of elements can be applied to
  metals, ceramics, etc.
• Zirconium Oxide, Cerium Oxide currently in wide
  application
• Choose from 57 elements for various effects
• Ultra-thin film adhered to substrate
• Flexible in nature
• Conforms to surface (surface finish lt16 Ra is
  preferred)
• No thermal coef. of expansion issues (CTE)
• Infused to substrate superior adhesion
• Lubrication
• Solid state lubricant
• Porosity can be added as holding sites
• for liquid lubricants
• Surface Protection
• Corrosion protection
• Environmental Boundary Coating
• Thermal property tuning (emissivity,
  transmissivity)

9
Infused Nano-Film Characteristics

• M.I.S.T. process produces fine-grain size
• ORNL X-Ray diffraction study shows grain size to
  average 3 nm

10
ORNL Material Analysis

• Zirconium Oxide (Zirconia) version of C3 M.I.S.T.
  process analyzed on
• 304 Stainless coupons
• Sputter profiles measured the interface formed
  between the substrate and thin film
• Ultra-thin film diffused into substrate
• Approximately 48 nm depth of Zirconia into
  substrate
• Multiple applications of the C3 process built up
  a 250 nm thin film
• Final diffused nano-film can be described as an
  oxycarbide

11
SEM and Auger Analysis
ZrFeO
ZrCO
SEM

• M.I.S.T. process on SS 304
• Sequence of SEMs and Auger maps taken during a
  sputter profile
• As the coating is removed the underlying
  substrate is revealed
• Zrred
• Oblue
• Cgreen

12
C3 Competitive Technologies
13
Nano-film Diffusion Process
14
Corrosion Resistance

• Aqua Regia Test
• Sample exposed to specific volume of 3 parts HCL
  to 1 part HNO3 for 1 hour

MIST 1000 Treatment
MIST 5000 Treatment
15
Corrosion Resistance

• High Temperature Salt Spray Test
• Samples heated to 1652F in air, then sprayed
  with 10 salt water solution for 1 hour. Test
  recommended by Alberta Research Council.

MIST 1000 Treatment
MIST 5000 Treatment
16
Micro Welding

• When exposed to molten metal, micro welding
  occurs in tool steels, stainless steels, etc.
• This also applies to machining operations where
  micro-welding is one failure mechanism in metal
  cutting tools
• Metal forming operations can experience micro
  welding in high stress areas

17
Case Study Molten Aluminum Attack
Thermocouple Sheath Test 1010 steel exposed to
molten/liquid aluminum
18
Case Study Wallace Dunker Test

• Case Western Reserve University trial using
  Wallace Dunker Test

• Test blocks made from test steel sized 2 x 2 x 7
  inch rectangular shape
• 1.5 inch diameter hole in the center for internal
  water cooling
• Four corners with 0.010 inch radius intensifies
  the predominately uniaxial stresses
• Test produces considerable constraint and high
  thermal fluctuations during immersion and removal
  from the aluminum 380 alloy bath (1350F)
• Specimen is immersed for 12 seconds
• Specimen then removed from the bath for
• 24 seconds to produce the thermal cycle
• Outer surface of the specimen sprayed with
• water-base lubricant prior to dunking
• Water flows through the central hole at
• a constant rate of four gallons per minute
• C3 treated test block ran for 15,000 cycles
• Ni-based super alloy performance unsatisfactory

19
Case Study Ladle Durability

• Aluminum Foundry Ladles
• Casting ladles made from 440 SS
• Ceramic paint applied at start of each shift
  after cleaning
• Standard 1200 pours to failure
• MIST process applied to identical ladle
• Treated ladle lasted 52,125 pours

20
Case Study Core Pins

• Die Cast core pins
• H13 Steel in low pressure operation
• MIST process results in 7X life over Nitrided
  pins
• (See graph at right)
• Untreated pin (top photo, below) shows typical
  aluminum soldering after 3,500 cycles
• Treated pin (bottom photo) lasts 200,000 cycles
  w/o soldering

21
Case Study Intricate Die Molds

• Complex auto transmission valve body die casting
• H13 die with heat treatment Nitriding
• 383 Aluminum pour _at_ 1250F
• 8000 part limit before intense soldering occurs
• C3 M.I.S.T. process applied to untreated mold
• After 27,000 parts mold fails due to fin fracture
  unrelated to surface treatment

22
Case Study Shot Sleeves

• High pressure die casting shot sleeves
• H13 construction with water cooling circuits
• Molten Aluminum _at_ 1150-130F temperatures
• 4.0 ID size
• Graphite bead lube between shots
• Normal life 20,000 cycles to tool failure
• C3 treated shot sleeves last 98,000 cycles
• Beryllium plunger tips last longer when used with
  C3
• treated sleeves
• Standard life with untreated sleeves 7,200
  shots
• Tip life when operated in treated sleeves
  12,500 shots
• Coefficient of friction reduced between tip and
  sleeve with infused nano-film of ZrO2

23
Case Study Metal Forming

• Infused nano-films of Zirconia extend metal
  forming tool life
• Stamping
• Forging
• Also applicable to punches and extruders
• Extends life of shearing blades
• Reduces need for coolants
• Surface finish of stamped parts
• is improved

24
Case Study Metal Cutting Tools

• Infused nano-film of ZrO2 extends
  cutting tool life
• Near-diamond hardness in nano-film and substrate
  surface
• Tool life and/or cutting speed improved
• Surface finish of machined part is improved
• Synergistic with coolants and cutting fluids

25
C3 Process Critical Applications Benefits

• Gun Barrel Program
• High temperature rise in short time frame
• High rate of mechanical wear at high T
• Exposure to caustic chemicals at high T
• Close dimensional tolerances
• Hazardous material electroplating currently used
  (hard chrome plating)
• Performance is key
• Lubricity of C3 film improves range lethality
• Greater rounds per minute possible for longer
  durations
• Extended time between replacement

26
C3 Process Friction Reduction

• Bearing Steel Wear Friction Test

Two bearing steel coupons were tested. The coupon
coated with the C3 infused thin film gave a 10
reduction in the coefficient of friction and
provided an 80 reduction in wear rate as
compared to the standard steel coupon. All tests
run using reference test oil.
27
C3 Process Provides Multiple Benefits

• C3 Process addresses multiple areas of concern
• Can withstand extremely high temperature rise
  rates
• 4500ºF in 100 milliseconds
• Infusion into grain boundaries provides alloying
  strength
• Zirconia infusion provides high wear hardness
• Zirconia is second only to industrial diamonds in
  hardness
• Zirconia infusion provides inert barrier to
  caustic chemicals
• Nano-scale film does not cause dimensional change
• Application process is quick, with no HazMat
  issues
• Carrier fluid classification similar to kerosene
• No large capital investment needed
• Well-suited to licensing to manufacturers

28
C3 Process Catalytic Surfaces

• C3 infused surface treatment can make surfaces
  chemically active
• CeO2 coating prevents carbon deposits
• CeO2 plus other elements increase surface
  activity (Platinum, etc.)
• Turbine engine combustion chambers
• Automotive engine combustion chambers
• MEMS engine combustion rate
• Diesel Particulate Filters
• Oil Refinery Piping systems
• Extends process pipe life by 600
• Jet/Turbine engine fuel injector nozzles
• Reduces internal coking

29
C3 International, LLC

• 1370 E Union Hill Industrial Court
• Alpharetta, GA 30004
• Phone [phone] Fax [phone]
• www.c3international.com
