Shibboleth: EBSCOhost implementation

1
ShibbolethEBSCOhost implementation

• Lech Wojtowicz
• Director of Software Development
• EBSCO Publishing
•
• Access 2003
• October 3, 2003

2
Overview

• About EBSCO Publishing and EBSCOhost
• EBSCOs involvement in Internet2
• Current authentication methods
• Why Shibboleth
• Shibboleth implementation time-line
• EBSCOhost configuration
• Outstanding issues and future

3
About EBSCO Publishing

• Part of EBSCO Information Services
• Provide information and tools to access
  information online
• Primarily institutional market
• International customer base
• Began in 1986 with CD-ROMs and evolved to Web
• EBSCOhost at version 6.4, version 7.0 will
  release in Fall

4
About EBSCOhost

• Web based search and retrieval system
• Supporting
• 50 full text databases
• 65 secondary databases
• Links to 12,000 e-journals
• Native interface and Z39.50 access
• Internet network access from
• UUnet
• Genuity
• Internet2 (Abilene Network)

5
About EBSCOhost, contd

• Multi-tiered system
• Windows 2000 with IIS on front lines
• EBSCOhost is an ASP Web application, XML is an
  internal data format and protocol
• Several supporting services Email, Transaction
  Logging, Content Enhancements, Article
  Matching/Rights Checking
• Solaris and Linux back end tier for performing
  searches
• Multiple NFS servers used for data storage

6
About EBSCOhost, contd

• Peak load
• 25,000 simultaneous ASP sessions during peak time
• 200,000 searches peak hours, over 2 mln. searches
  a day
• 600,000 user logins per day
• 25 million transactions per day
• 50 of outbound bandwidth is Internet2

7
EBSCO and Internet2

• Most Internet2 members are EBSCO customers
• Many customers on affiliated network
• Recognized need for reliable high-speed
  connectivity (http//loadrunner.uits.iu.edu/weathe
  rmaps/abilene)
• Became Corporate Member in Fall 2000
• Initial connection via vBNS
• Spring 2002 became Collaborating site
• Current connection to Abilene are two T3s

8
Current authentication methods

• IP Address
• Username and password
• Referring URL
• Customer coordinated patron ID (library bar code)
• Pattern matching (patron ID)
• Athens
• Introducing Shibboleth...

9
IP Address

• Mechanism
• IP address ranges recorded in EBSCOadmin
• Associated with customer and group
• Shortcomings
• Multiple campuses with shared dynamic IPs may be
  a problem
• Remote access requires use of proxy server

10
Username/password

• Mechanism
• In EBSCOadmin a given user group is associated
  with a username and password
• User is prompted for username and password
• Shortcomings
• Communication of usernames and passwords
• Not very secure as usernames tend to be
  advertised
• No incentive for a patron to not share

11
Referring URL

• Mechanism
• Customer performs authentication
• Access to EBSCOhost is from secure page
• URL of secure page recorded in EBSCOadmin
• HTTP Referrer of request looked up
• Shortcomings
• Assumes customers page is secure
• End user must access through library
  authentication system

12
Customer coordinated

• Mechanism
• Customer uploads patron IDs (library bar code) to
  EBSCOadmin
• Patron IDs can be associated with a specific user
  group
• User must enter valid patron ID to access
• Shortcomings
• Link to EBSCOhost must include CustID
• Maintenance of patron ID

13
Pattern matching

• Mechanism
• Customer enters pattern of patron ID
• Associates pattern with user group
• User prompted for patron ID to access
• Length and significant characters must match
• Shortcomings
• Patron ID must follow a pattern
• Not very secure
• Maintenance no easy way to remove a patron

14
Athens

• Mechanism
• Access rights managed centrally in UK by Athens
  group
• Prompt for users Athens User ID and password
  (http//search.epnet.com/athens.asp)
• Call to Athens server to validate and get
  institution code
• Institution code matched to account in EBSCOadmin
• Shortcomings
• Management of users and rights in separate system
  from institution

15
Why Shibboleth

• EBSCO offers multiple services from different
  locations
• EBSCOhost databases
• EBSCOhost Electronic Journals Service (EJS)
• A-Z journal locator service
• LinkSource OpenURL resolver
• Redirect customers to publisher sites

16
Why Shibboleth, contd

• Currently supporting multiple (independent)
  authentication options
• Customers want seamless access between services
• Users want single login
• EBSCO needs to provide secure authentication to
  meet expectations of data providers

17
Shibboleth project timeline

• Mar 14/02 initial contact by Steven Carmody
• Apr 4/02 development initiated
• Apr 29/02 DLF/CNI meeting proof of concept in
  place and demonstration of Shibboleth in action
• --- port of Shibboleth package to Win32 ---
• Sep 12/02 Win32 Shib Package available (Version
  0.7)
• Sep 26/02 EBSCO Pilot project completed Scott
  Cantor performs first real world test from Ohio
  State University to EBSCOhost
• July 2003 Shibboleth version 1.1 released with
  Win32 support
• Aug. 2003 EBSCOhost Shibboleth Pilot project
  upgraded to use version 1.1 (http//search.epnet.c
  om/shib.asp)

18
EBSCOhost configuration
19
Outstanding issues

• Handling multiple sites for an institution
• Example OSU has 14 EBSCOhost accounts
• Associate originSiteID with customer account(s)
  in EBSCOadmin
• If one originSiteID is associated with multiple
  customer accounts, use entitlement for finer
  resolution
• Allow self administration
• EBSCO specific eduPerson entitlement
  urnmaceebsco.comltEBSCO customer accountgt

20
Future proposal use of attributes

• originSiteID single custID and groupID
  (majority of cases)
• affiliation single custID and multiple groupID
  (includes walk-ins)
• entitlement multiple custID

21
Observations

• Development effort
• Implement ISAPI filter
• Supporting infrastructure inside EBSCOadmin
• Administration effort
• Find appropriate contacts at institution
• Determine customer account to use and domains and
  affiliation
• Set up mapping or allow customers establish this
• Meets goal of single login for multi-site sessions

22
Future

• Expand test to other EBSCO sites
• EBSCOhost Electronic Journals Service
• LinkSource
• MetaPress
• Work with major publishers to extend reach of
  seamless access
• Handling multiple federations by accessing
  multiple WAYF servers, based on information from
  user
