SDSL

1
SDSL (Symmetric Digital Subscriber Line)
AST-SDM6000
2

• International Standards of SDSL
• Introduction of AST-SDM6000
• 3. SDSL Network Design

3
International Standards of SDSL
4
Overview of SDSL

• Symmetric Digital Subscriber Line
• Up stream / Down stream same speed
• Provide Data Voice service through existing
  telephone line
• Standardization 2B1Q (2 Bit 1 Quaternary)
• ETSI, ANSI
• DSP technology and Line Coding technology
• Speed and Distance
• - Symmetric 784Kbps 2.3Mbps
• - 3Km Max. 5Km

5
Channel Separate
Splitter Voice Data separate
SDSL Data filter
Voice filter
SDSL
POT
4kHz
2.3MHz
Data transmit
Voice Data transmit
Use Splitter
6
Data rate Distance
Distance
3Km 2.3Mbps

• SDSL

Bandwidth
1.2Km 13Mbps

• VDSL

7
Introduction of AST-SDM6000
8
AST-SDM6000 Benefit

• Hardware and Software provided Apsuns own
  technology
• HomePNA product developing / supplying
• Passed KT BMT, Dream Line BMT function test
• Perfect understanding of installation site
  circumstance
• Specialized technology to meet recent market
  trend
• Experience for maintenance and installation

9
AST-SDM6000 Strength

• Comply SDSL international standard by 2B1Q
  method
• Provide Total Solution through product line -up
• Use existing telephone line in the building
• Transmit Voice and Data at the same time
  (Splitter Option)
• Need splitter between CO and CPE to
  connect both side
• Symmetric 2.3Mbps Speed
• Excellent counter Cross-talk

10
AST-SDM6000 Feature

• Symmetric Max. distance 3Km at 2.3Mbps
• Compact size and high accumulation (Max. 156
  Ports)
• Excellent expansion ability (unit 12 Ports /
  Board)
• Hot Swap (Board based swap) function
• Dual Power Supply (Redundancy)
• Easy installation (standard 19 Rack mountable)
• Improve reliance in management and maintenance
• Use SNMP for NMS function
• Manage individual subscriber (Port On/Off)

11
AST-SDM6000 Main Specifications
12
AST-SDM6000 Specification
13
Additional Specification

• Main Switch and Management Board
• - Gigabit Uplink interface 2 Ports (1 Port
  Option)
• - 100Mbps 6 Channel Trunk Port
• - Channel Board Management
• Channel Board
• - Port based VLAN
• - MAC Filtering
• - Included Splitter Module (Option)

14
Management system

• Management Software
• - Telnet, CLI
• - RS232C Console
• - TFTP image upgrade
• - Remote Auto Software upgrade
• - System configuration
• Management Functions
• - Self Diagnostics
• - Operating Statistics
• - Auto Fault reporting
• - SNMP, RMON, Ethernet MIB
• - VLAN
• - Packet Filtering

15
AST-SDM6000 System Layout Front
16
AST-SDM6000 System Layout Rear
17
AST-SDM6000 Board Layout
Telco Cable Wrapping / RJ-11 etc. various types
available
18
AST-SDM6000 Air flow
19
SDSL Network Design
20
SDSL Network Exam.
AST-SDM6000
SDSL Modem
Data
Telephone
Splitter
Computer
Voice
Splitter
PSTN PBX
21
SDSL Network configuration
MDU
CO
Customer
Voice
Apartment
SDSL
Router
Leased Line
.
Ethernet
Apartment
Switching Hub
22
End Thank you ! Have a good time
