Ectropic Design: Support for Open Source Development

1
Ectropic DesignSupport for Open Source
Development
Spencer Rugaber, Kathy Gray,Mark Guzdial
2
What is Ectropy??

• Ectropy Entropy
• Ectropy is order out of chaos
• Good Description of Open Source Development!

3
Open Source Success Stories

• Linux
• Linus Torvals
• gcc
• Richard Stallman
• python
• Guido Von Rossum

4
Open Source Development only works...

• When there is a Champion
• Someone who maintains coherence of the design
  over time,
• Someone who integrates changes in a reasonable
  way,
• Someone who is the recognized authority in
  identifying a new release.

5
Can we do Open Source with an automated Champion?

• Imagine a server that
• Accepts code from a team of programmers
• Knows the programmers and their tasks
• Makes sure that the code meets design
  requirements
• Alerts the team to issues
• Integrates software to define a release
• Big job!

6
Our Solution Ectropic Software

• Ectropic Software evolves over time
• becoming more highly structured
• better able to accomplish goals of its users
• Ectropic Objects are all bound to the goals they
  meet

7
Ectropic Software

• Two Key Ideas
• Ectropic Design
• A design method by which order and structure are
  created from collaborative efforts of multiple,
  unrelated software developers
• Ectrospace
• active collaboration space to support Ectropic
  Design

8
Introducing ECode

• Ectropic
• COllaborative
• Design
• Environment
• (pronounced echoed)

9
But First!A Review of OOA/OOD/OOP

• A Review of Object Oriented Software Design
• OOA
• OOD
• OOP

10
OOA

• Object Oriented Analysis (OOA)
• Requirements Analysis
• Use of Scenarios in Requirements Analysis
• Build List of Collaborator-Responsibility Cards
  (CRC Cards)
• Distribute Responsibilities Among CRC Cards

11
OOD

• Object Oriented Design
• Complete all Scenarios with Responsibility-CRC
  Card Pairs
• Add Method Names, with method categories and
  descriptions
• Integrity Check!

12
OOP

• Object Oriented Programming
• Select CRC Cards for Classes
• Generate Class Stubs
• Complete Full Implementation of Classes

13
ECODE

• Ectropic Collaborative Design Environment
• A design tool to assist you in mapping an
  Object-oriented design process to Ectropic
• A non-collaborative prototype release
• For design purposes - not to replace the Squeak
  programming environment!

14
Getting Started with Ecode

• Download and filein from the class coweb
• Ectropic-Basic.st
• Ectropic-Views.st
• Copy to your Squeak folder
• logo.gif
• Save your image.

15
Ectropic Objects

• EctropicDesign
• has Scenario(s) and CRCCard(s)
• Scenario
• has Responsibility/CRCCard pairs
• CRCCard
• has Responsibility(s)
• Responsibility
• has a Method and possibly a CRCCard collaborator

16
Main Ecode Approach

• Analysis Mode
• Determine CRCCards and Responsibilities using
  Scenarios
• Design Mode
• Distribute Responsibilities to CRCCards and
  create a Method for all Responsibilities
• Program Mode
• Create Class stubs from selected CRCCards

17
Analysis Mode

• Requirements Analysis
• Use Scenarios to Help with Requirements Analysis
• Build List of Collaborator-Responsibility Cards
  (CRC Cards)
• Distribute Responsibilities Among CRC Cards

18
Scenarios Help with Design!

• Determine a Scenario for a Task
• Build the Scenario, step-by-step by creating a
  set of Responsibilities
• Assign each Responsibility to a CRCCard
• ECoDE will allow you to select or create CRCCards
• All Responsibilities should be assigned to or
  removed

19
Design Mode

• Complete all Scenarios with Responsibility-CRC
  Card Pairs
• Add Method Names, with method categories and
  descriptions
• Integrity Check!

20
Integrity Check

• When shifting to Program Mode, ECoDE makes a
  quick integrity check for you
• Are all responsibilities assigned to CRCCards?
• Do all responsibilities have associated method
  names?
• You have the option to continue

21
Program Mode

• Select CRC Cards for Classes
• Generate Class Stubs
• Parent Class
• Instance Variables
• Complete Full Implementation of Classes
• In a System Browser!

22
Compile Errors

• This version of ECoDE will not catch all compile
  errors
• When generating code, if you get the pink compile
  error
• Abandon
• Correct your code
• Retry

23
Completing the Implementation

• ECoDE is not intended to replace the built-in
  programming environment in Squeak
• It is a design tool which will generate Class
  stubs for you
• It is highly recommended that you switch to a
  System Browser when completing your implementation

24
Saving Your Work 2 Ways

• Save Project (for turnin)
• Snapshot of your image as a .pr file
• Many open windows long long time!
• BUT main ECoDE window MUST be open!
• Save
• Saves your design with a simple fileout
• Saves a .ect file and a .st file

25
Loading Designs

• When loading your design (not as project)
• ECoDE loads the corresponding .st file
• MAKE SURE the .st file in the same directory with
  your .ect file is the MOST RECENT copy
• Of course you can always close and retry without
  saving image

26
Critical Reminders!

• Copy logo.gif to your squeak directory
• When transferring saved designs, you need to
  transfer both
• designName.ect file
• designName.st file (MOST RECENT!)
• When saving project for turnin, USE ECoDE for
  save, NOT Squeak Navigator Publish It

27
UML Options

• In Squeak, ConnectorMorphs
• Rational Rose
• Visio
• Hand-draw diagrams and scan
• Power-point drawings
• See http//coweb.cc.gatech.edu/cs2340/2112

28
Turnin

• See http//coweb.cc.gatech.edu/cs2340/1937 for
  details
• TAs want PROJECTS!!
• But if any problems saving as project
• Do regular save
• Turnin .ect and .st files along with diagrams

29
Technical Assistance

• Kathy Gray, kgray_at_cc
• Office hours Tuesday, 130 300
• Jonathan DAndries, bane_at_cc
• Office hours Wednesday, 11 1

30
ECoDE on CoWeb

• ECoDE on CoWeb
• from class admin page)
• http//coweb.cc.gatech.edu/cs2340/2100
• Defect Log
• Usability Log
• Comments/Feedback/Suggestions

31
Classroom Experiment

• Consent Forms
• Preliminary Survey
• Problems with Prototype
• Your feedback is critical!

32
Advice!

• Design before coding!
• Save and manage saved files well
• Teams should consider configuration management
  with Designs!
• Back up your work
• Report Bugs immediately

33

• Questions?
