HF Radio Standards Development NATO HF Working
Group Report

• January 2002
• Eric E. Johnson
• Science Applications International Corporation
• New Mexico State University
• eejohnson _at_ ieee.org

2
MIL-STD Development Status

• 188-110B Data Modems Published
• 188-141B Radio Protocols Published
  Change Notice 1 delivered to IXMP 9/01
• Appendix C Third Generation Protocols
• Appendix E Application Protocols (incl. E-Mail)
• Appendix F Anti-Jam/Anti-Interference
• Appendix G Data Link Protocol
• http//wireless.nmsu.edu/hf/standards/MIL/

3
188-141B Notice 1 Appendix C

• Existing 3G protocols revised to match STANAG
  4538
• 3G ALE dwell 51 slots of 900 ms
• NATO-Mode addressing
• Added LDL packet sizes
• Revised HDL sequence numbering

4
188-141B Notice 1 Appendix E

• CFTP is now standardized for US interop Deployed
  in 5066 systems but not specified in STANAG
  5066
• HF Mail Transfer Protocol (HMTP) Revised to
  match STANAG 5066 Mandatory for interop with
  5066 and for future PKI architecture

5
HF E-Mail Protocol Structure
6
188-141B Notice 1 Appendix F

• Anti-jam / Anti-interference Techniques
• Updated to track changes in Appendix C

7
188-141B Notice 1 Appendix G

• Second Generation Data Link Protocolfor use with
  MIL-STD-188-110B modems
• Now points directly to STANAG 5066Annex A
  Subnetwork Interface SublayerAnnex B Channel
  Access SublayerAnnex C Data Transfer Sublayer

8
NATO HF Radio Ad Hoc Working Group

• Sierra Vista, AZ May 2001
• Koblenz, Germany November 2001
• Livorno, Italy June 2002

9
US NATO Convergence
Protocols
141B w/Notice 1
4538
3G ALE
"Robust"
Yes (5 slots)
Yes (5 slots)
"Fast"
No
Yes
3G ARQ
LDL
Yes
Yes
HDL
Yes
Yes
2G ALE
Yes
-gt 141
2G ARQ
-gt 5066
supports 5066
10
US NATO Convergence
11
HF STANAG Status

• 4415 Robust WF Promulgated Multiple
  implementations
• 4444 EPM Promulgated German prototype
• 4538 ARCS Promulgated US-UK-NL-NO air
  trials chairman stunning results

12
HF STANAG Status (contd)

• 4539 Waveforms only 4 nations ratified, so not
  yet promulgated. multiple implementations
• 5066 Datacomms Promulgated multiple
  implementations
• Planned edition 2 mandatory email
  protocol compliance w/4406 messaging
• Possible edition 3 LAN/WAN operations

13
NC3Board(AC/322D/20)

• By developing a modern, adaptive, and flexible
  HF system, much of NATOs messaging, data, data
  link, facsimile and voice requirements could be
  met within the HF band. This will reduce the
  demand for scarce SATCOM resources to those
  requirements that genuinely need large
  bandwidths.

14
Power-Line Data Communications

• Emerging home networking/broadband access
  technology in Europe
• Operates in HF band may raise noise floor
• Netherlands commencing tests of power-line
  communications interference with HF
• Doesnt appear economically feasible in North
  American power distribution system

15
Other Projects

• Ground Routing Protocol ACP 193
• Initial work on video/image transfer over HF
• Wideband data comms
• ISB modems as in MIL-STD-188-110B App F
• Adaptive use of non-contiguous channel groups
