Gene prediction

1
Gene prediction
2
Finding eukaryotic genes

• Up to 99 DNA is non-coding- long ORFs can exist
  by chance.
• Introns break up ORFs into smaller regions making
  them harder to spot.
• Introns contain information for their own removal
  (splicing) but these sequences may not be well
  enough
  conserved to make
  prediction of these
  accurate.

3
Gene finding using homology

• Extended homology (similarity of sequence) with a
  known gene ? likely to be gene.
• Homology searches can also look for short regions
  of sequence that are conserved between many
  different genes
• Several of these protein motifs encoded by a
  small region of DNA could indicate the presence
  of a gene.

4
Multiple alignment for gene prediction

• Homology detection involves sequence alignment by
  maximizing a similarity score function.
• This can be achieved using the dynamic
  programming algorithm

5
Dynamic programming

• Alignment- work left to right in both sequences
• At each point can have 1) a match of two letters,
  2) a gap in the first sequence matched with a
  letter in the second or 3) a letter in the first
  with a gap in the second
• Eg. Align AIMS with AMOS
• AIM-S
• A-MOS

6
Dynamic programming

• Path matrix Put one sequence on vertical axis
  and one on horizontal.
• Alignment finding best path top-left to
  bottom-right

A I M S

• Gap in vertical sequence horizontal line
• Gap in horizontal sequence vertical line
• Match of two letters diagonal line

7
Dynamic programming

• Search tree

Dynamic programming algorithm for searching tree
for best path only want to find single best
path- black circles
actually same point, so no need to search through
all paths. Difference in score between these
paths are just the differences in score of path
up to that point, so pick the best and prune of
other paths from black circle.
8
Global alignment

• Score function to be optimised is the sum of
  weights at each position of the alignment.
• Weights are defined by a substitution matrix
  among the four nucleotides and also by a gap
  penalty- simple example fixed value for matches
  and mismatches.
• So we can define a score matrix with a value at
  each point in the path matrix
• Where s(i) is the letter in ith position in
  horizontal sequence, t(j) is jth in vertical
  sequence, ws,t is the weight for substituting
  letter s for t and d is the gap penalty.

9
Global alignment

• The initial values of the score matrix are
• Dynamic programming is more efficient than many
  standard tree search algorithms, because most
  branches pruned according to the score function.

10
Local alignment

• Global alignment works when you know where to
  start and end, which is not usually the case for
  gene finding.
• Look instead for short sections of similarity
  (eg. motifs).
• For this we must define the score matrix slightly
  differently to allow the alignment to start
  anywhere

11
Database searches

• When trying to find homology information on a
  sequence of interest, you try to align it with
  thousands of sequences of known genes from a
  database.
• The dynamic programming algorithm which is O(nm)
  takes a huge number of computations to search the
  database for homology
• Recall n, m lengths of target and source
  search strings
• It can be made efficient by parallel processing,
  but faster less rigorous algorithms are often
  employed instead.

12
FASTA and BLAST

• FASTA and BLAST are approximate, but more
  efficient.
• FASTA- do dot matrix plot of two sequences-
  black dots where the nucleotides in vertical
  sequence are the same as those in the horizontal.
• By visual inspection locate regions of similarity
  which show up as diagonal lines (or, if you allow
  for some small gaps, clusters of diagonal
  stretches)

13
FASTA

• Apply dynamic programming to these located
  regions only.
• Located regions are small compared to entire
  matrix, so the algorithm is speeded up a lot.
• Initial search for diagonals is done by hashing-
  which is actually usually done on sextuples of
  nucleotides, instead of single ones.

14
BLAST

• BLAST algorithm uses an alternative approach to
  sequence alignment.
• Query sequence is split up into words, usually
  11 bases long in DNA sequence or 3 amino acids
  long in protein sequence.
• These words are then compared to a list of all
  possible words and a new list is generated,
  containing all words that match at what is
  considered a significant level. (NB some words
  are so common that even a perfect match is not
  considered significant.)

15
BLAST

• A finite state automaton can then be used to find
  any exact matches of these words within a
  sequence database efficiently
• The regions of both target and query sequence
  where words are found to have matched are then
  examined further. This is achieved by extending
  the alignment locally from either side of the
  word until a maximum score is achieved.

16
Gene finding with Hidden Markov Models
17
Modelling sequences as Hidden Markov processes

• Think of the nucleotide sequence in a piece of
  DNA as being a sequence of outputs of a process
  that progresses through a series of discrete
  states, some of which are hidden to the observer.
• Markov assumption is that the state of the system
  at position i1 in the sequence depends only on
  the state at position i and not on other
  positions (usually we will number the sequence in
  the direction of transcription).
• The Markov assumption is of course not true of
  DNA and there are various ways of minimizing the
  impact of this wrong assumption.

18
An example gene finder VEIL

• The Viterbi Exon-Intron Locator (VEIL) was
  developed by John Henderson, Steven Salzberg, and
  Ken Fasman at Johns Hopkins University.
• Gene finder with a modular structure
• Uses a HMM which is made up of sub-HMMs each to
  describe a different bit of the sequence
  upstream noncoding DNA, exon, intron,
• Assumes test data starts and ends with noncoding
  DNA and contains exactly one gene.
• Uses biological knowledge to hardwire part of
  HMM, eg. start stop codons, splice sites.

19
The exon sub-model
20
Other submodels

• The start codon model is very simple
• The splice junctions are also quite simple and
  can be hardwired (here is the 5 splice site)

Upstream
Exon
a
t
g
21
The overall model
Start codon
Stop codon
Downstream
Upstream
Exon
3 splice site
5 polyA site
5 splice site
intron
For more details, see J. Henderson, S.L.
Salzberg, and K. Fasman (1997) Journal of
Computational Biology 42, 127-141.
22
Training

• The (sub-)HMMs can be trained by using the
  Expectation Maximization algorithm.
• The idea is as follows
• You estimate the transition probabilities
  (parameters) of the HMMs by picking those which
  maximise the probability of obtaining the data.
• where are the transition
  probabilities between states and is
  the training set of observed sequences.
• Guaranteed to give locally optimal solution.

23
Analysing new sequences using the trained HMM

• Once the transition probabilities have been
  estimated, the HMM can be fed novel sequences in
  order to try to find genes.
• The task is essentially to parse the sequence
  into intron, exon and noncoding parts.
• The Viterbi algorithm (discussed more later in
  course) essentially looks for the maximum
  likelihood alignment of the test sequence with
  the states of the model, using a dynamic
  programming strategy. It also calculates the
  probability of the model producing the data via
  that path of states.

24
Higher order Markov chains

• Suppose we want to relax the assumption that the
  state at position i1 depends only on the state
  at position i and instead depends on the n
  previous states (an nth order Markov chain)
• This can lead to problems with the training
  algorithms, but we can employ a trick and let
  states of the HMM correspond to n-tuples of
  nucleotides, since
• We in fact get a first order Markov chain between
  the n-tuples

25
Higher order Markov chains

• Eg. suppose we have a sequence of As and Bs
  in which each letter depends on the two previous
  letters, then we can equivalently consider a
  first order Markov chain in (overlapping) pairs
  of letters
• Higher order Markov chains may be more
  appropriate for modelling DNA sequences?

AB
AA
BA
BB
26
Testing-Sensitivity and Specificity

• These are measures of the predictive power of the
  model (HMM).
• They are used to compare different gene finding
  programs.
• SensitivityTP/(TPFN) SpecificityTP/(TPFP)
  (where T/Ftrue/false, eg. T denotes nucleotide
  really is in exon P/Npositive/negative, eg. P
  denotes nucleotide is predicted to be in exon.)
• These test criteria are different from the
  objective functions used to train the HMM
  (objective function is simply the probability of
  data given the model)- this means there is no
  guarantee of even local optimality.

27
Training and Testing VEIL

• Final accuracy of gene finder depends heavily on
  the quality and quantity of the data used to
  train it.
• They used a set of 570 vertebrate sequences from
  different species.
• The data had been filtered for quality control
  reasons- pseudogenes and various other
  non-standard genes or genes which would bias the
  data had been removed.
• They performed 5-fold cross-validation- both with
  and without removal of highly homologous genes
  from the test sets.

28
Training and testing VEIL

• The testing involved calculating sensitivity and
  specificity of both nucleotide labelling (coding/
  noncoding) and exons exactly found. Other
  measures of accuracy were also used.
• The nucleotide sensitivity was roughly 80,
  specificity c. 70
• Getting both ends of the exon right is a much
  harder test and the figures were sensitivity c.
  50, specificity c. 50.
• The authors note that they can improve these
  statistics by combining this de novo gene
  finding method (HMMs) with database search
  (homology) methods.

29
Conclusions on gene finding

• With so much DNA sequence information available,
  it is important to find out how to make sense of
  it- to find the functional bits, which are the
  genes
• This can be achieved using ESTs, but there are
  problems with this method.
• Alternative methods described in this lecture are
  i) database homology searches to find known genes
  similar to the query sequence and ii) de novo
  pattern finding methods such as HMMs
• David Jones will discuss this topic in more
  detail.
