Model Based Testing of Large-Scale Software

1
Model Based Testing of Large-Scale Software
How Can Simple Model Test Complex System

• Victor Kuliamin
• kualimin_at_ispras.ru
• ISP RAS, Moscow

2
Real Software Systems

• They are huge and have a lot of functions
• They have very complex interfaces
• They are developed by hundreds of people
• They are distributed and concurrent

System Year Size
(MLOC) Windows 3.1 1992
3 Windows NT 3.1 1993
6 Windows 95 1995
15 Windows NT 4.0 1996
16,5 Red Hat Linux 5.2 1998
12 Debian Linux 2.0 1998
25 Windows 2000 1999 29 Red
Hat Linux 6.2 2000 17 Sun
StarOffice 5.2 2000 7,6 Debian
Linux 2.2 2000 59 Red Hat
Linux 7.1 2001 30 Windows XP
2001 45 Red Hat Linux 8.0
2002 50 Debian Linux 3.0 2002
105
System Year DevTeam
Size Windows NT 3.1 1993
200 Windows NT 3.5 1994
300 Windows NT 4.0 1996
800 Debian Linux 1.2 1996 120
Debian Linux 2.0 1998 400
Windows 2000 1999
1400 Debian Linux 2.2 2000 450
Debian Linux 3.0 2002 1000
3
Quality of Real Software Systems

• They are tested a lot
• But
• Details of their behavior are not well defined
• And they still do have serious bugs

System Year TestTeam
Size Windows NT 3.1 1993
140 Windows NT 3.5 1994
230 Windows NT 4.0 1996 700
(0.9) Windows 2000 1999 1700
(1.2)
System Test Cases, K MS Word XP
35 Oracle 10i 100 Window
XP gt2000 (?)
4
Model Based Testing a Solution?

• Potential to test very large systems with high
  adequacy
• Parallelization of work on system and its tests
• Google on model based testing case study
  gives
• 630 links on 230 sites
• 60 separate case studies concerned with industry
  since 1990
• Most MBT case studies are small
• lt 10 case studies concerned with systems of size
  gt 30 KLOC
• Most MBT techniques are based on state models and
  hence prone to state explosion problem

?
5
Fighting Complexity

• No simple way to test a complex system adequately
• But manageable way exists use of general
  engineering principles
• Abstraction
• Separation of concerns
• Modularization
• Reuse

6
UniTesK Solutions

• Modularize the system under test contract
  specifications of components
• Modularize the test system flexible test system
  architecture
• Adapters binding test system and SUT
• Contracts Oracles checking SUTs
  behavior
• Test coverage goals based on contracts
• Test data generators for single operation
• Testing models (test scenario) test sequence
  composition
• Abstract contract, more abstract testing model
• Reusability of contracts, testing models,test
  data generators

?
7
Software Contracts
Contracts (preconditions, postconditions, data
integrity constraints) help to describe
components on different abstraction levels
Contract A
Component A
Component C
Contract I
Contract C
Subsystem II
Subsystem I
Contract B
Contract II
Component B
Component D
Contract D
8
Test Coverage Goals

• post
• if ( f(a, b) g(a) )
• else if( h(a, c) !g(b) )
• else

9
Testing Model
parameters
operation domain
2
3
coverage goals
1
states
10
Test Data Generation

• Computation of single call arguments

parameters
Test data generation is based on simple
generators and coverage filtering
2
3
1
states
current state
11
The Whole Picture
Testing Model
Behavior Model
System under Test
Coverage Model
On-the-fly Test Sequence Generation
Single Input Checking
12
Testing Concurrency
11
21
21
s11
s12
11
Target System
r12
r11
12
s21
31
12
22
r22
r21
s31
Time

• Multisequence is used instead of sequence of
  stimuli
• Stimuli and reactions form a partially ordered set

13
Checking Composed Behavior

• Plain concurrency behavior of the system is
  equivalent to some sequence of the actions

Plain concurrency axiom
?
14
(No Transcript)
15
The Case Study

• 1994 1996
• ISP RAS Nortel Networks project on functional
  test suite
• development for Switch Operating System kernel
• Size of the SUT is 250 KLOC
  530 interface operations
• 44 components were determined
• 60 KLOC of specifications40 KLOC test
  scenarios developed in 1.5 year by 6 people

• A lot of bugs found in the SUT, which had been in
  use for 10 yearsSeveral of them cause cold
  restart
• 30 of specifications are used to test other
  components
• 3 versions of the SUT were tested by 2000 (500
  KLOC)Changes in the test suite were lt5

16
Other Case Studies

• IPv6 implementations - 2001-2003
• Microsoft Research
• Mobile IPv6 (in Windows CE 4.1)
• Oktet
• Intel compilers - 2001-2003
• Web-based banking client management system
• Enterprise application development framework
• Billing system
• Components of TinyOS
• http//www.unitesk.com

17
UniTesK Tools

• J_at_T 2001
  Java / NetBeans, Eclipse (plan)
• J_at_T-C Link 2003
• C / NetBeans MS Visual Studio
• CTesK 2002C
  / Visual Studio 6.0, gcc
• Ch_at_se 2003
  C / Visual Studio .NET 7.1
• OTK
  2003Specialized tool for compiler testing

18
References

• V. Kuliamin, A. Petrenko, I. Bourdonov, and A.
  Kossatchev. UniTesK Test Suite Architecture.
  Proc. of FME 2002. LNCS 2391, pp. 77-88,
  Springer-Verlag, 2002.
• V. Kuliamin, A. Petrenko, N. Pakoulin, I.
  Bourdonov, and A. Kossatchev. Integration of
  Functional and Timed Testing of Real-time and
  Concurrent Systems. Proc. of PSI 2003. LNCS 2890,
  pp. 450-461, Springer-Verlag, 2003.
• V. Kuliamin, A. Petrenko. Applying Model Based
  Testing in Different Contexts. Proceedings of
  seminar on Perspectives of Model Based Testing,
  Dagstuhl, Germany, September 2004.
• A. Kossatchev, A. Petrenko, S. Zelenov, S.
  Zelenova. Using Model-Based Approach for
  Automated Testing of Optimizing Compilers. Proc.
  Intl. Workshop on Program Undestanding,
  Gorno-Altaisk, 2003.
• V. Kuliamin, A. Petrenko, A. Kossatchev, and I.
  Burdonov. The UniTesK Approach to Designing Test
  Suites. Programming and Computer Software, Vol.
  29, No. 6 , 2003, pp. 310-322. (Translation from
  Russian)
• S. Zelenov, S. Zelenova, A. Kossatchev, A.
  Petrenko. Test Generation for Compilers and Other
  Formal Text Processors. Programming and Computer
  Software, Vol. 29, No. 2 , 2003, pp. 104-111.
  (Translation from Russian)

19
Contacts

• Victor V. Kuliamin
• kuliamin_at_ispras.ru
• 109004, B. Kommunisticheskaya, 25
• Moscow, Russia
• Web http//www.ispras.ru/groups/rv/rv.html
• Phone [phone]
• Fax [phone]

20
Thank you!
