ADCUS, Inc'

1
ADCUS, Inc.

• Next Generation Embedded Microprocessor Company

Dec. 2003
2
Company Snapshot

• Founded in Sep. 2003
• Pittsburgh/Philadelphia, PA
• Exclusive license of EISC IPs
• from Advanced Digital Chips, Korea
• The only PDG member company with
• embedded microprocessor technology
• Funded by PA government and ADC Korea
• more coming from Korea government soon

3
EISC Architecture

• 16 GPR (General Purpose Register)
• Load-Store Architecture
• Fixed 16-bit long instructions
• Instruction set optimized for high level language
• Fully support conditional branch instructions
• Operand is extended with Extension register and
  Extension Flag
• Protected by 29 Patents

4
(No Transcript)
5
EISC Benefits

• Advantage of both CISC and RISC
• Small Program(Code) Size
• Minimize data bandwidth
• Simple Instruction Set, Simple Hardware
• Lower Gate Count
• Easy to develop at lower cost
• Faster Time-to-Market
• Higher performance than industry majors
• 3040 improvement ( Drhystone 1.1/2.1)

6
EISC Products
Pachinco Machine
Arcade Game Machine
HDTV
Portable Karaoke Machine
Storytelling Book
Robot War SiPAC
VoIP Gateway
7
EISC Community
8
SoC Design Process
Specification Development
RTL Code Development
Functional Verification
Timing Verification
Synthesis
Place and Route
Prototype Build and Test
Deliver to System Integration and SW Test
9
IP List Microprocessors

• 16/32/64 bit Microprocessors
• 64bit SIMD/DSP
• 64bit FPU
• Unified Cache Controller
• Harvard Cache Controller
• Memory Management Unit
• Low Power Cache Controller

10
IP List General Peripherals

• General Timer
• Watch Dog Timer
• Pulse Width Modulation
• Interrupt Controller
• Priority Interrupt Controller
• UART
• IIC Bus Controller
• Inter IC Sound Bus Controller
• SPI Controller
• SIO Controller
• GPIO

• General DMA
• Real Time Clock
• Key Scan Controller
• High-Level Data Link Controller
• IEEE 1284-Host
• IEEE 1284-Device
• LCD Controller(Mono, STN)
• NOR Flash Memory Controller
• NAND Flash Memory Controller
• SDRAM Memory Controller

11
IP List More Peripherals

• Buffered DMA Controller for Ethernet MAC
• DMA Controller for ATM SAR
• CRT Controller
• Bit Block Transfer Controller
• 2D Graphic Engine
• Sound Engine
• ADPCM Decoding Engine(CCITT G.726)

12
ADCUS can help you

• Design your own Customized SoC
• ASSP(Application Specific Standard Platform)
  Co-development
• We can also support your any general
  microprocessor needs

13
Discussion Topics

• IMD/Novocell (Identifi ??)
• Company Background, History, Status etc
• Business Business Model, Customers, Current
  Products/Services, Future Plan etc..
• Technologies Embedded memory, Analog
• Differentiation, Strength and etc
• Foundry related issues
• List of IP Blocks
• Cost Structure
• Design Fee, IP License fee, Running royalty etc
• Mutual benefits
• ADCUS to be a customer of IMD/Novocell
• IMD/Novocell to be a customer of ADCUS
• Co-marketing or bundling towards potential mutual
  customers
