Computeraided Equipment Selection in Assembly Line Design

1
Computer-aided Equipment Selection in Assembly
Line Design

• Pierre De Lit
• CAD/CAM Department
• Université libre de Bruxelles

2
What will we talk about?

• Introduction
• The PROMETHEE II method
• Selection of assembly methods
• Equipment selection
• Conclusions

3
What will we talk about?

• Introduction
• The PROMETHEE II method
• Selection of assembly methods
• Equipment selection
• Conclusions

4
The aim is to design hybrid assembly lines

• Different kinds of stations
• Manual
• Dedicated/Robotic

5
The user can follow a quick or a detailed solving
approach
Quick solving
Detailed solving
6
What will we talk about?

• Introduction
• The PROMETHEE II method
• Selection of assembly methods
• Equipment selection
• Conclusions

7
PROMETHEE is a multicriteria decision-aid method

• PROMETHEE is a method
• allowing the designer to choose the best
  alternative...
• Decision-aid
• by taking different criteria of different kind
  into account
• Multicriteria

8
Choosing a new car is a multicriteria problem

• Criteria
• Price (FB)
• Consumption (l/100km)
• Comfort
• Power
• ...

9
According to the criterion, solutions are better
or worse
10
A preference function is defined for each
criterion
Criterion Power
Ppower(a,b)
Preference threshold 20
2 20
Indifference threshold 2
11
The indifference threshold should depend on
relative variations

• Example
• d f(a) - f(b) 10 CV - 5 CV 5 CV
• d f(a) - f(b) 150 CV - 145 CV 5 CV
• Influence of d should be stronger in the first
  case
• Compute the preference function with respect to
  the relative variation between the evaluations

12
Intermediate evaluation functions are used for
qualitative criteria
Example comfort
13
A PROMETHEE II ranking is computed for each
solution

• Multicriteria preference index p(a,b)

• Multicriteria solution flow

• PROMETHEE II complete ranking

f f - f- net flow
14
The PROMETHEE II method has three main features

• Establishes a complete ranking of the different
  alternatives
• By comparing the relative difference of
  performance of all the solutions criteria by
  criteria
• By taking user preferences into account, by mean
  of criteria weights

15
What will we talk about?

• Introduction
• The PROMETHEE II method
• Selection of assembly methods
• Equipment selection
• Conclusions

16
Quick solving approach
Quick solving
SELEQ (Pre-selection of assembly equipment)
RP (Resource planning)
Detailed logical layout
List offunctional groups
Equipment DB
17
Each operation is decomposed into three primitive
actions

• Feeding
• Picking from the storage, positionning and
  orienting before transfer
• Handling
• Transfer to final position and orientation
• Insertion
• Bringing together with other components

18
Three possible methods are considered for each
sub-operation

• Manual method
• The most flexible
• Robotic method
• Partially flexible
• Dedicated or automated method
• The most specific

The solutions are ranked with PROMETHEE II
19
Common criteria have been classified into four
categories

• General criteria of the line
• cycle time, payback period
• Geometrical features of each part
• dimensions, symmetry, etc.
• Non-geometrical criteria for each part
• fragility, slipperyness, hotness, etc.
• Generic criteria for the operation
• number of part variants, repetitions, etc.

20
Some criteria are specific to each sub-operation

• Specific criteria for feeding
• Part is packed, risk of overlapping, etc.
• Specific criteria for handling
• presence of handling surface, need for optical
  magnification, etc.
• Specific criteria for insertion
• resistance to insertion, limited view, etc.

21
The principal window presents the operations and
their modes
22
The influence of an answer to one question can be
checked
23
The influence of each type of criterion can be
measured
24
The influence of the criteria themselves can be
approciated
25
The weights can be modified and their influence
easily seen
26
The operating mode evaluation influences the line
balancing
- Tc - Prec constraints
Operating modes
Preference constraints
LB
WS1
WS2
WS3
WS4
(manual)
(manual)
(dedicated)
(robotic/ dedicated)
27
The line balancing influences the operating mode
evaluation
First layout
WS 2
Robotic
Second layout
28
What will we talk about?

• Introduction
• The PROMETHEE method
• Selection of assembly methods
• Equipment selection
• Conclusions

29
Detailed solving approach
Rough logical layout
LB (Line balancing)
Operating times
Detailed solving
30
The equipment are stored in the database
according to a tree
31
The aim of the equipment selection is to create
functional groups

• Functional group potential set of equipment used
  for the line design with
• cost
• time (possible to deal with masked times)
• availability
• room occupied
• Several functional groups can be created for one
  operation

32
A functional group creation occurs in three steps
Select a general category
Some combinationsare not allowed (ex RMR)
Select a technical category
Parameters describe the needs - screwing torque -
riveting force - number of axes of a robot -
feeding autonomy
Select the equipment
33
The equipment used is finally chosen by a
resource planner
34
The equipment selection results from a compromise
(PROMETHEE)
35
What will we talk about?

• Introduction
• The PROMETHEE method
• Selection of assembly methods
• Equipment selection
• Conclusions

36
Let us conclude

• New method for equipment selection in three main
  stages
• Operating method selection
• Construction of functional groups
• Selection of the equipment by a resource planner
• Tool is simple to use and interactive
• Designer preferences can be set transparently
• Results are easy to trace
