Pseudowire Edge to Edge Emulation

1
Pseudowire Edge to Edge Emulation

• FROM THE SERVICE PROVIDER POINT OF VIEW
• gilles.deworm_at_ebone.com

2
Drivers For PWE3/L2TPv3 (1)

• Adding to the product portfolio a service that
  emulates circuit-like connections over a single
  or multiple (inter-AS) IP networks for
  Point-To-Point circuits or Point-To-Multipoint
  circuits
• Having a performing and flexible toolbox for
  building customized solutions in the case of
  conflicting routing policies requirements
• open versus closed peering networks
• regional/national vs. hosting vs. international
  transit backbone policies

3
Drivers For PWE3/L2TPv3 (2)

• Interconnecting at high-speed physically disjoint
  network parts by building a network based
  overlay architecture.
• Provide a mean for interconnecting Ethernet
  networks transparently.

4
Service Provider Requirements

• Transparency
• No change to the routing architecture
• No new IP protocol implementation
• Run over plain IP
• High-speed capable
• from T1/E1/E3/T3 to OC48
• High performance
• Hardware assisted (server card) for high BW
• Flexible
• In terms of payload capability
• Layer 2 PPP ,HDLC ,FR ,ATM ,ETHERNET

5
Service Provider Requirements

• Easy and quick service provisioning
• Secure
• Solution Simple Security with Tunnel ID/Key vs.
  IPSec capable
• Scalable
• need for automatically/auto-magically tunnels
  setup
• Minimum overhead
• Tunnel Header 4-12 bytes
• Takes benefit of the statistical multiplexing of
  the IP networks

6
Services Overview IP VLL (1)

• Service 1 IP Virtual Leased Line
• Emulation of HDLC, PPP, FR, ATM, Ethernet
  End-to-End interconnectivity
• Transport of Layer 2 packets End-to-End
• Point-To-Point
• Single Virtual Leased Line/physical interface
• One-to-One mapping 1 tunnel bound to the
  interface

7
Services Overview IP VLL (2)
8
Services Overview IP VLL (3)

• Examples
• Lan To Lan (L2L) interconnection aka. Transparent
  Lan Service (TLS)
• Replacement of clear channel SDH
• Finer granularity in bandwidth (combined with
  existing IP rate-limiting tools)
• Interconnection of 2 disjoint networks at
  high-speed
• Layer 2 backhaul to a remote location
• Virtual presence at IX (no need for expensive
  LL)

9
Services overviewIP MVLL (1)

• Point-To-Multipoint
• Multiple Virtual Leased Lines/physical interface
• Multiple tunnels with DLCI/802.1Q/VPI/VCI
  mapping to the corresponding sub-interface on the
  single physical interconnection

10
Services overviewIP MVLL (2)
11
Services overviewIP MVLL (3)

• L2 PPVPN (Provider Provisioned Virtual Private
  Network).
• Different topologies
• Hub-and-Spoke,Partial/Fully Mesh
• Single Interconnection/site
• Customer manage Routing and QoS
• Tunnels provisioned by the Provider
• Network based tunneling

12
Services overviewIP MVLL (4)
13
Services overviewIP MVLL (5)

• Overlay network
• Goal The network D in the middle does not need
  to know about the routing in the other disjoint
  networks and has a different BGP/routing policy
  (more restricted for instance)
• To scale one transit backbone
• Superset and subset of routes
• Open versus closed peering policy
• Closed User Group (GRX )
• Distributed IX

14
Services overviewIP MVLL (6)
15
Services overviewIP MVLL (7)

• Premium Service
• Goal bundle different services on a single
  interface.
• Examples
• a) Transit connectivity multiple direct
  connectivity to regional peering
• b) L2PPVPN Internet Break-out Managed
  Hosting/Housing Services

16
Services overviewIP MVLL (8)
17
Other Services (1)

• Metro TLS (Transparent LAN Services)
• Interconnection of LANs in the Metro Area
• Break-out to remote MANs, Internet, CUG
  (intranet/extranet), etc.

18
Other Services (2)
19
Other Services (3)

• Multi-services devices
• On same the router, connect
• L2 PPVPN customers
• L2 Backhaul service
• IP transit
• Inter-Connectivity to different networks
  (regional/national) with different routing
  policies
• Premium service with different QoS requirements
• VLAN rewriting/stripping

20
VLAN rewriting/stripping
21
Future (1)

• Control plane for the forwarding plane
• Enhanced security
• Automatically tunnel setup
• L2/L3 (dissimilar endpoints framing)
• L3/L3 (similar to GRE)
• Tips
• MTU at endpoint interconnections lt Maximum core
  MTU (20 bytes for IP Header) 4 to 12 bytes
  for Tunnel Header (in todays implementation -gt
  no support for fragmentation)
• ISIS hello padding ? disable it or set correct
  MTU at the edge
• Conclusion
• PWE3/L2TPv3 is a high performance transparent
  encapsulation protocol optimized for the
  encapsulation of one protocol (L2L3)over IP. No
  change to the network is required (runs over
  IPv4).

22
Conclusion

• PWE3/L2TPv3 is a high performance
• transparent encapsulation protocol optimized for
  the encapsulation of one protocol (L2L3)over IP.
  No change to the network is required (runs over
  IPv4).
