Product Presentation June 2007
The hard-line response to all challenges !
2
Product Presentation - Pebble4

• GENERAL OVERVIEW / PRODUCT POSITIONNING
• THE BRAND NEW PEBBLE4 GENERATION
• MAIN FEATURES AND BENEFITS
• ENCODING OPTIONS
• PEBBLE4 SWEET SPOTS
• SPECIFICATIONS
• ACCESSORIES
• COMPETITIVE ANALYSIS
• THE MOST COST EFFECTIVE CHOICE !
• REFERENCES WORLDWIDE APPLICATIONS

3
General Overview / Product Positionning

• The Pebble range
• The benchmark for card personalization COLOR
  printing ENCODING
• No compromise on PERFORMANCE and QUALITY
• USER ORIENTED simple intuitive, Pebble4 is
  easy to install, monitor and operate
• Compact, light and aesthetic
• A TURNKEY solution
• Highly VERSATILE to match all requirements in
  terms of connectivity and encoding
• Ideal for small and medium series.
• Perfectly adapted to applications such as
  Identification, Leisure, Transit

4
The brand new Pebble4 Generation
NEW FEATURES DESIGN FOR HIGHER PERFORMANCES
AND USER-ORIENTATION

• New CPU and printhead for higher performance
• New warranty conditions, the best one in the
  market
• New options Ethernet, encoding capabilities
• New powerful and modern colors Ocean Blue, Fire
  Red, Jungle Green
• New driver even easier to set up and monitor
• Compatible with the latest OS Windows 2003, XP
  Vista, Mac Linux

5
Main Features and Benefits (I)

• ERGONOMIC AND USER-ORIENTED
• Driver installation is simple and requires no
  training while basic configuration is easily
  performed.
• Enhanced interactivity thanks to a Print
  Manager function and an intuitive 4-LED
  information panel.
• A market-proven concept of Clamshell opening for
  an easy access to all parts. - the user
  operates by himself the daily maintenance
• - the printer is perfectly fit to minimize
  downtime
• VERSATILE AND SCALABLE
• Optional Ethernet port for LAN connection
• Manual feeder option for over-the-counter
  applications
• Additional 100-card feeder
• Multiple encoding technologies available (MAG /
  SMART / RFID)

6
Main Features And Benefits (II)

• PREMIUM PERFORMANCES
• Up to 150 cards/hour (color) and 1000 cards/hour
  (monochrome)
• An exclusive  Color Profile  to fine-tune
  color matching
• 16 MB RAM for optimal printer monitoring
• PLUG PRINT SOLUTION
• A full package printer, cleaning kit, cables
  card design software.
• eMedia Card Designer is delivered standard. A
  truly professional solution !
• Personalization and design of badges using an
  Excel database and
• the data Import/Export feature is possible from
  the first time.
• Pebble4 supports latest OS (Windows, Mac
  Linux)
• QUALITY AND RELIABILITY
• Strict selection of components, advanced quality
  testings and high quality finish
• A pioneering 3-year warranty. Evolis products
  keep its users satisfied for years.

7
Encoding Options
A full range of advanced encoding technologies
are available and can be combined.

• Magnetic stripe encoder
• ISO 7811 or JIS2 - HiCo/ LoCo
• Smart contact station
• ISO 7816-2
• Smart contact station and encoding unit
• PC/SC, EMV 2000-1
• Contactless encoding unit
• ISO 14443A, B, ISO 15693, Mifare, DesFire, HID
  iCLASS,
• HID Prox, Calypso
• Other types upon request

8
Pebble4 sweet spots

• Markets
• Identification, Leisure, Education, Transit,
  Banking
• From the simple Visual Identification to the
  most sophisticated Smart Cards
• Applications
• Small to medium runs, up to 100K cards per year
• Bulk or Over-the-counter card personalization
• Characteristics
• Single-sided
• Color or Monochrome
• Magnetic stripe, Smart contact RFID encoding

9
Specifications
Feeder 100 cards or manual card feeder (optional)
Smart card contact station
Card Type ISO CR80 (ISO CR79 optional) From
0,25mm (10 mil) to 1mm (40mil)
Contactless encoding station
Printing unit Single-sided Mono 1000 cards /
h colour 150 cards / h Ribbon saver
Magnetic stripe encoding station ISO or JIS2
Clamshell opening sytem
4-LED panel
Hopper 50 cards
Drivers Windows XP, 2003, Vista Mac OS X
v10.2, 10.3 et 10.4 Linux
All our equipment is shipped with the eMedia Card
Designer software
10
Accessories

• 100-card feeder.
• Available in Ocean Blue, Fire Red and Jungle
  Green
• Manual Card Feeder
• Available in Ocean Blue, Fire Red and Jungle
  Green
• Travel Case
• Travel Bag

11
Competitive analysis (I)

• Evolis global approach
• Offer a full package and the most cost-effective
  solution
• The positionning of Pebble4
• One of the most performant solution for card
  color printing encoding
• An exclusive 3 year warranty
• A professional card design software included
  standard
• The best cost per card ratio in the market

12
Competitive analysisPebble, the most
comprehensive offer
High End
Entry Level
Feeders capacity and offer / Encoding type
offer YMCKO cost per card / Warranty warranty
conditions
13
The Most Cost Effective Choice !

• THE ALL IN 1 SOLUTION
• Top-of-the-range performances (graphics, image
  definition and throughput)
• A compact light design. A choice between 3
  modern and alluring colors.
• Market-proven, innovative user-friendly
  concepts
• (PushTwist printhead, clamshell cover,
  detachable card feeder, port monitor)
• A Plug Print solution . All included standard
  !
• An exclusive 3-year warranty
• A comprehensive ribbon offering and a
  cost-saving approach (ribbon saver,
  half-panel color ribbon).
• The best cost per card ratio in the market !

14
References Worldwide Applications

• RATP Transportation System, City of Paris,
  France
• The Intermarché Group Retail Stores, France
• Club Med Gyms in France
• NACF Bank, IBK Bank, Woori Bank, Pusan Bank and
  Jeju Bank, Korea
