Open Source Databases

1
Open Source Databases

• Zeger W. Hendrikse

2
Content

• Purpose
• Survey of available open source databases and
  tools
• Strong emphasis on HSqlDb and MySQL
• Feature comparison
• Content
• SQL, JDBC basics (optional)
• Open Source databases
• Introduction (Java non-Java)
• Access and administration tools
• Demo

3
SQL

• DDL (Data Definition Language)
• create, alter, drop
• DML (Data Manipulation Language)
• CRUD (select, insert, update, delete)
• DCL (Data Control Language)
• connect, grant, revoke

4
JDBC drivers

• Type 1 JDBC to ODBC bridge
• Usually slow, meant as transient solution
• Early drivers designed to leverage existing ODBC
  drivers
• Type 2 Java wrappers around native DB interfaces
• No longer very common
• Using JNI
• Type 3 Pure Java drivers
• Use middleware component to translate JDBC-calls
  to a DB-generic communication protocol
• Type 4 Native Java drivers
• Driver designed specifically to interact with the
  DB
• The most common

5
JDBC connections

• DriverManager
• Introduced in JDBC 1.0 API
• Connection retrieved with hard-coded URL
• DataSource
• Introduced in the JDBC 2.0 Optional Package API
• Preferred method
• Underlying DataSource transparent to the
  application
• ConnectionPoolDataSource
• XADataSource

6
JDBC connections DriverManager

• public class DbConnector
• private static String driver
  "oracle.jdbc.driver.OracleDriver"
• private static String url "jdbcoraclethin_at_A
  MISNT151521LUDO"
• private static Connection connection null
• private static void createConnection
• try
• if (connection null
  connection.isClosed())
• Class.forName(driver).newInstance()
• connection
• DriverManager.getConnection(url,adf6,
  adf6)
• catch (Exception e) // omitted here

7
JDBC connections DataSource

• A DataSource
• a factory to create database connections
• centralizes database connection-related data
• implementation of javax.sql.DataSource
• three implementations available
• Standard implementation
• Connection pooling implementation
• Distributed transaction implementation

8
JDBC JNDI pooling

• DataSources JNDI
• DataSources are designed for use with JNDI
• Configured within JNDI provider bound to JNDI
  nameContext context new InitialContext()Data
  Source ds (DataSource)
  context.lookup(jdbc/TestDataSource)Connection
  con ds.getConnection(sa, )Program only
  knows about username and password!
• Usage in Servlets
• Get connections in doGet() en doPost()
• Get DataSource in init() ? provides connections
  from pool

9
JDBC pooling

• A pooled DataSource stores connections in a pool
• Pool cache, BUT pool is prepopulated with a
  of cons
• If all connections are used1. May fail2. May
  add more connections to pool
• Purpose increase in performance

10
JDBC 1.0 ? 2.0

• Scrollable result sets
• Batch updates (multiple insert/update/delete in 1
  request)
• Advanced data types (BLOB, CLOB)
• Rowsets, for JavaBeans (rowset set of rows
  bean)
• JNDI for obtaining connection
• Connection pooling
• Distributed transaction support
• Two-phase commit used by the JTS API.
• Additional minor additions/improvements

11
JDBC 2.0 ? 3.0

• Savepoint support
• Reuse of prepared statements by connection pools
• Connection pool configuration
• Retrieval of parameter metadata
• Retrieval of auto-generated keys
• Ability to have multiple open ResultSet objects
• Passing parameters to CallableStatement objects
  by name
• Holdable cursor support
• Boolean data type
• Making internal updates to data in BLOB en CLOB
  objects

12
JDBC 2.0 ? 3.0 (cont.)

• Retrieving and updating the object referenced by
  a Ref object
• Updating of columns containing BLOB, CLOB, ARRAY
  and REF types
• DATALINK/URL data type
• Transform groups and type mapping
• Relationship between the JDBC SPI (Service
  Provider Interface) and the Connector
  architecture
• DatabaseMetadata APIs

13
Enterprise demands on databases

• A JDBC Compliant driver must support SQL-92 at
  the entry level ? entry level SQL-92 is a must
• Transaction support
• may also be handled in business tier
• JDBC driver that is JDBC gt 2.0 compliant
• Includes support for DataSources
• necessary for pooling ? critical for scaling
  performance
• Preferred JDBC gt 3.0 compliant
• Triggers, views and stored procedures
• BLOB, CLOB
• Support, user-base

14
Development models
15
Development models
16
Java databases
17
Java vs. non-Java databases
Java
Java
non-Java

• Platform independent
• Small ? so may be embedded in application e.g. as
  part of a .war
• Small ? but can handle large databases
• Some versions allow memory-based tables
• Easy to set-up, configure, maintain.
• HSqlDb, Derby (Apache), Axion, McKoi and
  Xindice.

• Better scalability
• Better support for very large applications
• Firebird, GNU SQL, MySQL, PostGreSQL, Max DB (
  SAP DB), Ingres, Berkely DB

18
Java databases Axion

• Product of Tigris.org (known from GEF)
• Embedded Java DB with file- or memory-based
  tables
• Currently no server mode
• Nov. 2003 The Apache DB Project has accepted
  Axion's proposal to become a part of the Apache
  Software Foundation.
• Features http//axion.tigris.org/features.html

19
Java databases HSqlDb

• Continuation of Thomas Muellers Hypersonic DB
• Yet another example of successful OS project
• Basically Axion ?
• Same functionality many useful advanced
  features
• JDBC gt 2.0, full transaction support
• Additional DDL commands alter table create
  view
• Additional DML commands outer join, group by ,
  grant/revoke
• Standard DB with JBoss AS
• License BSD-based
• Default in-memory table regenerated from SQL
  script
• transaction log of SQL statements (executed at
  startup)

20
Java databases HSqlDb (cont.)

• Features
• In-memory and disk-based tables
• Transaction support
• JDBC 2.0 (partly 3.0)
• Five modes
• embedded (in-memory mode)
• standalone
• servlet
• server
• HTTP server

21
Java databases HSqlDb (cont.)

• If URL is jdbchsqldbc/path/databaseName
• ? creation of database databaseName in c/path
• If URL is jdbchsqldb.
• ? database not saved to disk!
• Behaviour of in-memory tables rebuilt with logs
  can be changed on a per-table basis
• CREATE MEMORY CACHED TEMP TEXT TABLE
  name
• Memory ? persistent in-memory table
• Cache ? disk based table with cache
• Text ? table saved as CSV-based file
• Temp ? non-persistent in-memory table

22
Java databases HSqlDb (cont.)

• Drawback no keyword for modification of this
  kind of storage type limits script portability
• HSqlDb comes with nice manager application, which
  may be used with other JDBC-supported databases
• Tool available from the JBoss management page!
• Personal remark ZWH
• Sometimes it seems confusing to me (with respect
  to the storage types) if the JBoss EJB container
  has added data as expected there seems to be a
  mismatch what the tool shows you and what is
  actually in the (in-memory) database.

23
Java databases HSqlDb (cont.)

• Demo Hypersonic SQL!

24
Java databases Derby

• Formerly IBMs Cloudscape
• At incubation at ASF http//incubator.apache.org/
  derby/
• Features
• Easy to use
• Small footprint
• Standards based
• SQL syntax, transaction management, concurrency,
  triggers, and online backups.
• Secure
• Secure data management appropriate to environment
  the engine is executing in
• Both as embedded database engine and network
  server

25
Java databases McKoi

• License GPL and maintained by individual
  developer
• Home _at_ http//mckoi.com/database/
• Features
• Transaction support
• both embedded and client/server mode
• Full JDBC 3.0 support
• Comparison
• More traditional than HSqlDb and more features
  than Axion
• Stores data files on disk and caches in memory
  like HSqlDb
• License (including JDBC driver) GPL
• Results in incompatibility with Apache
  license/products!!!

26
Java databases Xindice

• Native XML DB, stores compressed XML documents
• Donated to ASF by former xmlDB team
• XPath is query language and APIs support DOM
  SAX
• No DTD or Schema support for documents in DB yet!
• Why not relational?
• O/R impedance mismatch (would need Castor XML or
  similar)!
• Why not object DB?
• Object DB is application bound

27
Evaluation Java databases

• McKoi and HSqlDb richer feature set compared to
  Axion
• Derby is in incubation at ASF
• McKois GPL license is limiting
• HSqlDb is the Java database of choice
• JBoss database
• Largest Java-database community
• Xindice is a native XML database
• comes with pros and cons of native XML DB
• Well suited for document-style oriented data
• No need to map from relational DB to XML
• Less flexible queries

28
non-Java databases
29
Non-Java databases GNU SQL

• Seems to be dead (latest news from 28-09-1998)

30
Non-Java databases Firebird

• Code base of Borlands Interbase, OSS since 2000
• Forked off ? Interbase and Firebird
• Well documented

31
Non-Java databases MySQL

• Most common open source database (from NASA to
  Yahoo)
• Back-up by Swedish company MySQL AB
• Version 3.2x still widely used, 4.1.x now
  available and stable
• Stored procedures and triggers expected for 5.0
• JDBC driver
• Used to be MM.MySQL ? Connector/J, available form
  MySQL site

32
Non-Java databases MySQL (cont.)

• MySQL API choose your engine!
• ISAM MyISAM, no transaction nor foreign key
  support
• ISAM
• fast for reads gtgt updates, but not fault-tolerant
  nor transaction support
• MyISAM
• ISAM (table locking), but requires more
  maintenance
• HEAP
• In-memory, fast but volatile
• InnoDB Berkely BDB, transaction foreign key
  support, but slower!
• Implement your own ?
• Suggestion for rainy Sunday afternoon implement
  native XML engine!

33
Non-Java databases MySQL (cont.)

• Example
• CREATE TABLE tblMyISAM (
•        id INT NOT NULL AUTO_INCREMENT,
•        PRIMARY KEY (id),
•        value_a TINYINT
• ) TYPEMyISAM
• CREATE TABLE tblISAM (
•        id INT NOT NULL AUTO_INCREMENT,
•        PRIMARY KEY (id),
•        value_a TINYINT
• ) TYPEISAM
• CREATE TABLE tblHeap (
•        id INT NOT NULL AUTO_INCREMENT,
•        PRIMARY KEY (id),
•        value_a TINYINT
• ) TYPEHeap
• You can also use the ALTER TABLE command
• ALTER TABLE tblMyISAM CHANGE TYPEInnoDB

34
Non-Java databases PostGreSQL

• Evolved from database research at UC Berkeley
• Actively being developed/supported
• NO server version for windows platform available

35
Non-Java databases MaxDB

• Code base from SAP (ERP software)
• Back-up by Swedish company MySQL AB (!!!)
• Can be configured to support Oracle (v.7) SQL and
  DB2 (v.2)
• Fear skeptical of going open source motivation
• Remains to be seen how this (huge) project is
  picked up by OS community

36
Non-Java databases Ingres

• Recently went Open Source,
• License (CA-TOSL) to be OSI approved (CPL
  derived)
• http//opensource.ca.com/projects/ingres
• Strengthened relations with JBoss organization
• Ingres will be the default DB delivered with
  JBoss
• CA will coordinate development efforts
• Like MySQL AB for MySQL and MaxDB databases
• Industrial strength database
• Questions
• Remains to be seen if an OS community will
  emerge
• What will the prices be for support

37
Non-Java databases Berkely DB

• Embedded database for servers, networking
  hardware, handhelds,
• Supporting company Sleepycat
• Three products
• Berkely DB, embedded, accessible via API (Perl,
  Python, )
• Berkeley DB XML, native XML database
• Berkeley DB JE, for pure Java solutions
• License free for open source projects

38
Evaluation non-Java databases

• Requirement analysis (examples of valid
  considerations)
• Server has to run on windows ? No PostgreSQL
• Requirement for triggers and stored procedures ?
  No MySQL
• Porting app. from DB2 or Oracle ? MaxDB
• is able to understand different SQL dialects
• Support user base ? MySQL
• Licensing issues
• MySQL AB/Sleepycat only free for OS projects
• GPL might be restrictive
• Availability of supporting/admin tools
• There may be many requirements-satisfying
  candidates

39
Evaluation non-Java databases (cont.)

• Quick through the corner ? (snel door de
  bocht)
• PostgreSQL
• implementing most of the ANSI standard
• transactions, triggers, views, subselects and
  user-defined types.
• Stored procedures (many languages), sophisticated
  locking.
• Client libraries for all of your favorite
  programming languages.
• MySQL
• high-traffic applications where speed is more
  important than data integrity.
• lacks support for transactions, views, stored
  procedures, and subselects.
• Oracle
• Not free
• Most popular and powerful relational database on
  the market
• Applications, functions, and stored procedures
  (PL/SQL language)

40
Evaluation non-Java databases (cont.)

• Generally less features than commercial
  alternatives, but covers 80 of applications
  requirements
• Finally we havent exhaustively examined all
  open source databases here!

41
TOOLS
42
Tools MySQL Control Centre

• GUI for MySQL database
• GPL, for Windows and Linux platforms
• Download http//www.mysql.com/products/mysqlcc/

43
Tools MySQL admin tools

• MySQL Administrator
• by MySQL AB (free)
• http//www.mysql.com/products/administrator/
• MySQL manager
• by EMS (commercial)
• http//ems-hitech.com/mymanager/
• NOT SHOWN!

44
Tools MySQL Query Browser
45
Tools Squirrel

• Relational database access tool
• Purely Java and JDBC-based (license LPGL)
• http//squirrel-sql.sourceforge.net/
• Various plug-ins available
• Adds Oracle specific functionality
• Adds MySQL specific functionality
• Support to validate SQL against ISO SQL standard
• Look-and-feel
• Write scripts to file

46
Tools Squirrel (cont.)

• Demo!

47
Tools HSQL db-manager from jmx-console

• From JBoss management console
• HSQL db-manager
• Demo!

48
Tools Eclipse plug-ins
49
Tools Eclipse plug-ins

• IBMs WSAD
• JfaceDb from http//www.pratocity.com/index.jsp
  (commercial!!)

50
Integration with application servers

• Integration with Tomcat
• JDBC Drivers in CATALINA_HOME/common/lib
• Configure JNDI
• Use Tomcat Admin tool/page
• Adapt the server.xml
• Configure
• Class name of JDBC driver (e.g. jdbc/DefaultDS)
• Connection URL (e.g. com.mysql.jdbc.driver or
  org.hsqldb.jdbcDriver)
• Username passwd (tomcat welkom123)
• Integration with JBoss
• Demo!

51
Conclusions

• Open source databases scratch your own itch
• Suffices for most cases though!
• If PostgreSQL or MySQL is not enough
• Look at former commercial alternatives, such as
  Firebird
• No support argument does not hold anymore
• Look at which license suits you
• More candidates may satisfy your needs!
