Implementable Efficient Trajectory Design for
an Autonomous Underwater Vehicle.

• Monique Chyba
• Thomas Haberkorn
• Ryan N. Smith
• George R. Wilkens
• Song K. Choi
• University of Hawaii at Manoa

2
Research Goal

• Given two configurations at rest, we wish to
  design controllers which produce implementable
  trajectories for autonomous underwater vehicles.

3
Motivation

• Merge theory and application
• Interesting problem from any viewpoint
• AUVs are becoming more prevalent in research
• Optimal control of underwater vehicles is
  presently incomplete
• Efficient and versatile underwater vehicle
• Different from torpedo shape AUV
• Exploit all degrees of freedom

4
Interdiciplinary Research Team

• Monique Chyba
• Optimal Control Theory
• Thomas Haberkorn
• Numerical Analysis
• George Wilkens
• Differential Geometry
• Song Choi
• Mechanical Engineering
• Ryan Smith
• Ocean Engineering
• ODIN
• Omni-Directional Intelligent Navigator
• Test-bed AUV

5
Project Components

• Geometric Control Theory
• Vehicle Model
• Control Strategy
• Numerical Computations Modeling
• Experiments
• Repeat...Update...Repeat...Update...

6
Model

• Complex and highly nonlinear
• Model based on ODIN
• Good understanding of forces and geometry
• Experiments keep updating the model
• Viewed from a differential geometry point of view

7
Equations of Motion
Configuration space is the Lie Group
SE(3). Velocities belong to the lie algebra se(3).
Kinetic Energy
Translation
Rotation
8

• Second order forced affine-connection control
  system on Q SE(3).
• ? is the Levi-Civita affine connection
• Unique connection for the Riemannian metric (G)
  induced by the kinetic energy of the system
• View below as Acceleration Force/mass

9
Ideal Fluid
Real Fluid
Forced Affine-Connection Control System on SE(3)
Affine-Connection Control System on SE(3)
2nd order
First order system on TSE(3)
First order system on TSE(3)
10
Control Strategy

• Efficiency
• In computation time and duration along the
  trajectory
• Implementability
• Both trajectory and algorithm implementable on an
  AUV
• Understand physical constraints
• Thrusters have limited power
• Optimize cost(s) along trajectories
• Time or energy consumption or BOTH
• Begin with time minimization
• Extend previous results
• Real fluid characterization

11
Time Optimal Trajectory

• Apply Pontryagins Maximum Principle
• Optimal strategy is a concatenation of bang-bang
  control and singular arcs
• Leads to chattering
• Complicated control strategy
• No optimal synthesis analytically
• Must consider numerical methods

12
Numerical Techniques

• Direct methods
• Full discretization of state and control
• Very fine discretization and long solving time
• Always works
• Indirect methods
• Very sensitive to initialization
• Require a priori knowledge of the control
  structure
• Fast and accurate IF it converges

13
Time Optimal Strategy
?f (6,4,1,0,0,0) and tf 23.21s
14
Numerical Algorithm

• Use actuator switching times as additional
  unknowns of the optimal control problem
• Concatenation of constant thrust arcs
• Connected by a linear junction to avoid
  instantaneous switching of actuators
• Eliminates singular arcs and controls the number
  of switching times

15
Omni-Directional Intelligent Navigator (ODIN)

• 65 cm spherical body
• 8 thrusters
• 4 horizontal
• 4 vertical
• Weight 127 kg
• bouyant by 0.3 kg
• Full 6 DOF motion
• Max depth 100m
• Max speed 3 m/s
• Tuned to our needs
• CG location
• Buoyancy
• Robust
• Remedied many issues
• Thrusters
• Grounding
• Batteries
• Tether
• Positioning

16
Detailed Parameters

• CB (0,0,-1) cm
• Mif 70 kg
• Jif 0 kg.m2
• Ix 5.46, Iy 5.29, Iz 5.72 kg.m2
• D?11 35.8, D?21 35.8, D?31 31.2
• D?12 36.8, D?22 36.8, D?32 34.8
• DO11 18.9, DO21 18.9, DO31 16.9
• DO12 35.4, DO22 34.4, DO32 31.5
• All parameters were first empirically tested and
  are continually updated

17
Experiments

• Weekly testing
• Test-bed AUV is ODIN
• Test control strategies and trajectory design
• Update the model
• Observe practical constraints not visible in the
  theory
• Thrusters
• Environment

ODIN from the 10m platform
18
Pure Motion Thrust Strategy
?f (6,4,1,0,0,0) and tf 72.77s
19
Pure Motion Evolution
b2 (m)
?f (6,4,1,0,0,0) and tf 72.77s
20
STPP1 Strategy Evolution
?f (6,4,1,0,0,0) and tf 35.9s
21
STPP2 Thrust Strategy
?f (6,4,1,0,0,0) and tf 25.29
22
STPP2 Evolution
?f (6,4,1,0,0,0) and tf 25.29
23
Conclusion

• We are able to design a control strategy which
  gives implementable trajectories which are both
  efficient to compute and are efficient with
  respect to time and/or energy.
• Demonstrated time efficiency. Energy consumption
  will be approached through similar analysis and
  is under investigation.

24
Kinematic Reduction

• Ideal fluid case - no external forces
• .
• System on TQ
• .
• Driftless system on Q
• ?kin is a KINEMATIC REDUCTION of ?dyn if
• X is of locally constant rank
• For every controlled trajectory (?,ukin) for ?kin
  there exists dynamic controls such that (?,udyn)
  is a controlled trajectory for ?dyn

X (resp. Y) denotes the distributions generated
by X (resp. Y )
25
Decoupling Vector Fields

• Kinematic reductions of rank one
• Vector field whose integral curves can be
  followed by a trajectory of the dynamic system
• X is decoupling for ?dyn iff X, ?XX ? G8(Y)

26
Further Research

• Characterize a kinematic reduction for the forced
  affine-connection control system
• Identify decoupling vector fields under this
  characterization
• Find the simple motions for the forced system
• Use these motions in place of the piecewise
  continuous arcs in the numerical algorithm
