Ester Hydrolysis Reactor

1
Ester Hydrolysis Reactor

• Emily Brennan
• Justin Hewitt
• Fiona Rask

2
Purpose of Unit

• Takes output from anion exchanger
• Converts insulin ester into pure insulin
• Output to HPLC for final purification steps

3
Hydrolysis Reaction

• Cleaves a methyl group from insulin precursor
  using acid catalyst (HCl)
• Allows folding into active conformation

4
Neutralization Reaction

• Residual sodium hydroxide from anion exchanger is
  neutralized
• Use hydrochloric acid
• NaOH HCl ? H2O NaCl

5
Reactor Selection

• Continuous reactor selected
• Operated in lots to ensure quality assurance
  requirements are met
• Higher productivity than batch
• Smaller volume required for same conversion

VS
6
Reactor Configuration

• 3 reactors in parallel
• One reactor running continually to process an
  upstream lot
• Other reactors cleaned/maintained during
  operation

7
Design Assumptions

• 96 reaction extent for hydrolysis
• 100 reaction extent for neutralization
• Operation time 330 days/year
• Production of insulin crystal 4065 kg/year

8
Design Specifications

• Acid inlet 15.8 L/h
• Upstream process inlet 19.7 L/h
• Residence time estimate 2 hours
• Volume required 71 L
• Volume with 10 head space 80 L
• Well mixed reactor
• Material Stainless Steel

9
Additional Process Considerations

• Product sensitive to reactor conditions
• Reaction is exothermic and high temperatures can
  denature insulin
• HCl input into reactor and pH extremes can also
  denature insulin

10
Control Schemes
T set point 40oC
11
Cost Estimate

• Reactor Suppliers
• Perry Videx
• Walker Engineered Products
• New Brunswick Scientific
• Controller supplier
• Aspen Technology Inc.

12
Cost of Process

• Capital Cost 240,000
• Reactors (3)
• Controllers
• Operating Cost 4000/yr
• HCl (72 per ton)
• Utilities (0.06 per kWh)

13

• Thank you
