Biocatalysis and Enzyme Stability in Ionic Liquids

1
Biocatalysis and Enzyme Stability in Ionic
Liquids

• Jason Berberich, Joel Kaar, Anita Mesiano, Markus
  Erbeldinger, Alan Russell
• University of Pittsburgh
• McGowan Institute for Regenerative Medicine,
• Department of Bioengineering

2
Outline

• Ionic Liquids for Biocatalysis
• Structure
• Physical Properties
• Biocatalytic Synthesis of Acrylates
• Biocatalytic Polyester Synthesis
• Conclusions

3
Hydrophilic Ionic Liquids Physical Properties

• Hydrophobic ionic liquids
• Water immiscible
• BMIMPF6
• Hydrophilic ionic liquids
• Water miscible
• Good solvents for very polar substrates
• Sugars

4
Structures of the Ionic Liquids Used in this Study
Cations
Anions
5
Solvatochromatic Characterization of Solvent
Polarity

• Reichardts dye
• Normalized scale
• 0 nonpolar solvent (tetramethylsilane)
• 1 polar solvent (water)

6
Interpretation of Biocompatibility
Octanol-Water Partition Coefficient
7
Log P for Ionic Liquids

• Log P determined using the shake flask method
• Concentration determined using UV spectroscopy
• Ionic liquids have very low log P values

8
Physical Characterization -Conclusion

• Solvatochromatic characterization suggests that
  ionic liquids have polarity similar to ethanol
• The very low log P values for the ionic liquids
  suggests that these solvents are very hydrophilic
  and may compete with the enzyme for water

9
Biocatalytic Synthesis of Acrylates
100 mM Methylmethacrylate 100 mM
2-Ethyl-1-hexanol 20 mg/ml Candida rugosa
Lipase Temperature 30oC Agitation 300 rpm
10
Effect of Solvent on Lipase Activity

• Lipase activity is higher in BMIMPF6 than in
  hexane
• No activity in polar organic solvents
• No activity in hydrophilic ionic liquids
• Lipase dissolves in some ionic liquids

C. rugosa lipase
11
Can We Stabilize Lipase for use in Hydrophilic
Ionic Liquids?

• Methods investigated to stabilize lipase for use
  in hydrophilic ionic liquids
• Lipase adsorbed on acrylic support
• Novozyme 435 (Candida antarctica lipase)
• PEG-modified lipase
• PEG-NCO and Candida rugosa lipase
• Lipase-immobilized polyurethane foam
• Hypol 3000 and Candida rugosa lipase

12
Results Immobilized Lipase
mM/hr-mg

• No activity was detected in hydrophilic ionic
  liquids with immobilized lipases

13
Biocatalytic Polyester Synthesis
14
Monomer Solubilities in BMIMPF6 (50C)

• Monomers of interest show appreciable solubility
  in the ionic liquid

15
Polymerization Studies
Reaction DVA BD Conditions 50C, 24 hours,
2 Novozym 435 Results Mw Mn PD
I 2887 2401 1.20 Polymer precipitates out
of ionic liquid
16
Polyester results
Reaction DVA HFPD DVA
OFOD Conditions 50C, 24 hours,
2 Novozym 435 Results Mw Mn PDI HFPD 1254 1
113 1.13 OFOD 962 866 1.11
17
Stability of Novozyme 435in BMIMPF6
Incubate Enzyme in Ionic Liquid
Remove Enzyme from Ionic Liquid
Assay Enzyme Activity in Buffer
Olive Oil
Fatty Acids Diglycerides
18
Stability of Novozym 435 at 50C
BMIMPF6
THF
19
Stability of Novozym 435 at 50Cin the presence
of Substrates
BMIMPF6
THF
20
Stability of Novozym 435 at 70C
21
Conclusions

• Solvatochromatic characterization and
• log P measurements indicate that these solvents
  are polar and hydrophilic.
• Enzymatic synthesis of
  2-ethylhexylmethacrylate occurred
  efficiently in BMIMPF6 and hexane.
• Lipase dissolves in hydrophilic ionic liquids.
• Standard methods of stabilization were not
  affective in protecting the lipase from
  deactivation in hydrophilic ionic liquids.

22
Conclusions

• The enzymatic polymerization of DVA and
  1,4-butanediol has been achieved in BMIMPF6.
• Enzymes of interest show enhanced stability in
  the BMIMPF6 when compared to a traditional
  organic solvent.

23
Acknowledgements

• Sachem USA, Inc.
• Environmental Protection Agency
• (Grant R-82813101-0)

24
Stability of Novozyme 435 in Various Ionic Liquids
BMIMAcetate
MMEPAcetate
MMEPCH3SO3
BMIMPF6
MMEPNO3
BMIMNO3
25
Stability of Novozyme 435 in Conventional Solvents
Hexane
THF
ACN
DMSO
Butanol
