Remote Sensing

1
Remote Sensing
2
Satellites

• Provide gross Temperature, Humidity soundings
• Provide images of clouds
• We havent missed a Hurricane since satellites
  went on-line
• For the most part passive digital cameras

3
Satellite Retrievals

• Both low orbiters and geosynchronous satellite
  instruments scan and report number of photons at
  energies

4
Satellite Retrievals

• Footprint is larger at ends of scans than it is
  at nadir so corrections must be made
• Corrections needed as spacecraft wobbles and
  nutates
• In some cases rubber sheeting is needed to
  match cities with their image counterparts.
• May be done on board or done on the ground and
  relayed back to the satellite for distribution

5
WSR-88D Radar

• Very useful for finding out where precip is and
  how storms are moving
• Now gives velocity of movement towards or away
  from radar site

6
(No Transcript)
7
(No Transcript)
8
Surface Based Radar Basics

• Reasonably simple transmitter sends out a
  pulse, the EM wave is reflected or scattered back
  to the antenna and the time it takes to get back
  gives the distance away

9
WSR-88D Transmission Cone
10
WSR-88D Beam Elevations
11
Problems with knowing where data are taken
12
(No Transcript)
13
Profilers

• Upward looking radar units
• Measure three components of the wind at various
  elevations
• Potential for measuring particle size
  distributions from fall speed distributions

14
404 mHz Profiler Antenna
15
449 mHz Profiler Antenna
16
Profilers do need to be kept clean of snow
17
Antenna electronic configuration
18
64 mHz Profiler
19
S Band Profiler
20
Various Radar Bands
21
The Future of Remote Sensing
