Beam Dump Line

1
Beam Dump Line
Hervé SAVAJOLS (GANIL/TRIUMF)
2
Beam dump concept
? Q-poles carriage rail ? Retractable beam line ?
Diagnostic box

• Angular acceptance of 30 mrad
• Dp/p 15 (FWHM)
• Beam spot lt 5 cm
• Brmax 1.7 Tm (11Li3 _at_ 10MeV/n)

3
ISAC II experimental hall
Standalone Configuration (April 2005)
Tempory Configuration (Fall 2006)
4
Zero degree beam line

• No momentum dispersion
• Beam spot 3mm for 6? mm.mrad
• E 1.5 MeV./n
• Beam spot ?mittance0.5

5
Zero degree beam line Instrumented beam dump
6
Standalone beam dump

• Map (done)
• ? No mirror plate is needeed
• (2.3 G _at_ 500A)
• Fabricate install adapter
• Old loads motion can be recycled
• Power supplies
• Determine what beams will be dumped
• ? Radiation safety (beam shielding)
• Installation

7
Beam dump Identify / select reaction products

• Double focussing device
• Angular acceptance 30mrad
• Energy acceptance 30

• Increase the solid angle
• Selectivity

• Solenoid
• Acts as a lens generating an image of the target
  downstream with
• different focal length depending for beam
  particles and reaction
• products
• Increase easilly the angular acceptance up to
  10º
• Fill the Solenoid with gas (He) ? charge state
  equilibration
• Transport reaction products to a small area for
  identification

• Deep inelastic
• Symetric fusion evaporation
• Fusion-fission

8
Solenoid spectrometer to study direct reactions
J.Schiffer (ANL)

• Solenoid device
• Superconducting solenoid
• (0.5m bore, 1.5m long and 5 T)
• Two Si arrays
• (?z1mm, ?t 2ns, ?E100keV)
• Target
• Recoil detector (Z)

light particles follow helical cyclotron
trajectories in B
Z

• Identification ? TOF (cyclotron period is
  independent of energy or scattering angle)
• Angle resolution ? Zpos position
• Energy resolution ? Same Zpos, ?E ? ?ECM

9
Solenoid spectrometer to study direct reactions
J.Schiffer (ANL)
10
Solenoid spectrometer to study direct reactions
J.Schiffer (ANL)
11
Zero degree beam line Instrumented beam dump
12
Gas Filled Solenoid
DEEP INELASTIC

• Very neutron-rich RIBs
• (E/A5-10MeV/u, A40-200,
• 106-109 pps)
• Collisions on heavy targets
• Ni, Sn, Pb, Th, U
• Solenoid _at_ grazing angle
• Z A identification of residues
• Accessible exotic species down
• to 110 mb production cross sections

? N50 toward 78Ni ? Deformed N60 region etc
D.Verney IPN Orsay
13
Gas Filled Solenoid
DEEP INELASTIC _at_ TRIUMF
ISAC II yield for 1mA of p beam inpinging 1g/cm2
production target
N50 Ga Z31
N60 Rb Z37

• 97Rb U _at_ 5MeV/u (15 above de Coulomb Barrier,
  Grazing angle _at_ 60)
• TOF 2 SeD _at_ 2m dt 250ps (FWHM) Position
  measurement
• Energy Loss IC (3 resolution) / Energy Si
  detector
• ? Mass resolution 1/200
• ? Z resolution 1/70

14
The superconductiong solenoid rare isotope
beamline
15
 As standalone device, we plan to use the
solenoid for rare isotope search and for fusion
evaporation studies in gas-filled mode
16
(No Transcript)
17
Gas Filled Solenoid
FUSION EVAPORATION
SOLITAIRE _at_ ANU (Australia)
Precise measurements of evaporation residue and
fission yields Beam particles are stopped in FC
(0.5º) ? 58Ni 58Ni 32S 89Y
