Describing Copulas and Testing Fits

1
Describing Copulas and Testing Fits
Gary Venter Guy Carpenter Instrat
2
Architecture

• Review copulas
• Methods for describing copulas
• Comparing empirical and fitted copulas
• Goodness-of-fit examples
• Absolute and relative versions

3
1. Review Copulas

• Convenient way to build joint distribution from
  individual distributions
• Insurance dependency often stronger in large
  events
• Can model this by copula methods
• Quantifying dependency
• Degree of dependency
• Parts of distribution most strongly related

4
Modeling via Copulas

• Specify joint distribution of probabilities
• Copula of distribution of probabilities is joint
  distribution of losses
• Can specify where in the probability range
  relationship is strongest
• Conditional distribution easily expressed
• Simulation readily available

5
Formal Rules Bivariate

• F(x,y) C(FX(x),FY(y))
• Joint distribution is copula evaluated at the
  marginal distributions
• C(u,v) F(FX-1(u),FY-1(v))
• u and v are unit uniforms, C maps I2 to I
• Any joint distribution expressed via a copula
• FYX(yx) C1(FX(x),FY(y))
• Conditional distribution is derivative of copula
• E.g., C(u,v) uv
• F(x,y) FX(x)FY(y), so independence copula
• C1(u,v) v Pr(VltvUu)

6
Correlation

• Kendall tau and rank correlation depend only on
  copula, not marginals
• Not true for linear correlation
• Can calculate tau as 4EC(u,v) 1 .
  4??I2C(u,v)c(u,v)dudv ¼ and rho as
  12??I2C(u,v)dudv ¼
• Tau generalizes to multivariate ???cC
  2-n/½ 2-n. Indep ???2-n,max ½
• Looks like 3???C 2-n/½ 2-n for rho.

triples excess over ¼
7
Rho and Tau Are Related(for continuous copulas,
from Nelsen)
8
Example C(u,v) Functions

• Frank -a-1ln1 gugv/g1, with gz e-az 1
• t(a) 1 4/a 4/a2?0a t/(et-1)dt
• Gumbel exp- (- ln u)a (- ln v)a1/a, a ? 1
• t(a) 1 1/a
• HRT u v 1(1 u)-1/a (1 v)-1/a 1-a
• t(a) 1/(2a 1)
• Normal C(u,v) B(p(u),p(v)a) i.e., bivariate
  normal applied to normal percentiles of u and v,
  correlation a
• t(a) 2arcsin(a)/p

9
Archimedean Copulas

• Defined by generator function f
• C(u,v) f-1f(u)f(v)
• Gumbel and Frank are examples
• A fairly easy way to create a copula
• Some calculations also easier

10
2. Describing Copulas

• Correlation coefficients tell you more about
  parameter than about copula
• Tail coefficients tell more about copula
• For many copulas this is zero for all parameters
  e.g., normal copula
• For others it is always positive how positive
  depending on correlation
• Contours of joint distribution illuminating

11
Copulas Differ in Tail EffectsLight Tailed
Copulas Joint Unit Lognormal
12
Copulas Differ in Tail EffectsHeavy Tailed
Copulas Joint Unit Lognormal
13
Descriptive Functions

• Correlation and tail coefficients are scalar
  descriptors
• Descriptive functions are univariate functions
  mapping 0,1 ? 0,1 that describe features of
  the copula
• Usually z?0,1 indicates a region of the unit
  square (or cube or hypercube, )
• E.g., ultz, or u,vltz or C(u,v)ltz
• Function(z) calculates a scalar on this region
  often an integral over region

14
Copula on Diagonal I(z) C(z,z)
15
Copula Distribution Function

• K(z) ??C(u,v)ltzc(u,v)dudv
• Compare to I(z) ??u,vltzc(u,v)dudv
• Genest and Rivest JASA 1993
• Can be interpreted as PrC(u,v) lt z
• Archimedean copulas K(z) z f(z)/f(z)
• f(z) exp?yz dt/t K(t) for y?(0,1)
• All copulas are Archimedian
• K looks similar for many copulas but the density
  k looks less so

16
Two Copulas Fit to Same Data
17
Tail Concentration FunctionsVenter PCAS 2002

• L(z) Pr(UltzVltz) Pr(Ultz Vltz)/z
• R(z) Pr(UgtzVgtz) Pr(Ugtz Vgtz)/(1 z)
• L(z) C(z,z)/z I(z)/z
• R(z) 1 2z C(z,z)/(1 z)
• L(1) 1 R(0)
• Action is in R(z) near 1 and L(z) near 0
• lim R(z), z-gt1 is R, and lim L(z), z-gt0 is L
• Generalizes L(z) Pr(Ultz Vltz Wltz)/z

18
LR Function (L below ½, R above)
19
Other Descriptive Functions

• Tau can be calculated by
  -14?01?01C(u,v)c(u,v)dvdu.
• Cumulative tau using u,vltz
  J-(z) z24?0z?0z
  C(u,v)c(u,v)dvdu/C(z,z).
• J(z) z24?z1?z1 C(u,v)c(u,v)dvdu/C(z,z)
• Expected value of V given Ultz M(z)
  E(VUltz) ?0z?01 vc(u,v)dvdu/z.
• Basially bivariate, but could condition on all
  other variables ltz

20
More

• Cumulative tau could use just ultz
• Q correlation given u,v lt z or ultz really rank
  correlation since done on probabilities
• Q-(z) E(UVU,Vltz) E(UU,Vltz)E(VU,Vltz)
  /Var(UU,Vltz)Var(VU,Vltz)½
• Similar to Malevergne Sornette 2002 Review of
  Financial Studies and Charpentier 2003 ASTIN C
• Generalize to multi Q-(z) E(UVWU,V,Wltz)
  E(UU,V,Wltz)E(VU,V,Wltz)E(WU,V,Wltz)/
  Var(UU,V,Wltz)Var(VU,V,Wltz)Var(VU,V,Wltz)½

21
3. Compare Empirical and Fitted Copulas

• Compare descriptive functions for empirical and
  fitted copulas
• Empirical copula at each point counts number of
  points it in each element
• Eyeball tests of relative fit
• Look for functions that best show fit
• Clearly distinguish bad fit from good fit
• Show difference between good fit and pretty good
  fit

22
Can Also Do PP-Plots

• Fitted copulas at each sample point vs. empirical

• Also compute fitted conditional distributions at
  each sample point, sort, and compare to uniform
• PP-plots go from lt0,0gt to lt1,1gt and stay near
  diagonal so sometimes hard to identify good fit
• Subtracting YX makes them horizontal and then
  scale can be magnified
• PP-error plots

23
4. Goodness-of-Fit Examples

• Motor and property losses in French windstorms
• Monthly changes in exchange rate against the US
  dollar for Yen, Swedish Krona, and Canadian
  dollar

24
Auto and Property Claims in French Windstorms
25
MLE Estimates of Copulas
26
F/X Data

• Japan, Sweden and Canada currencies monthly
  change in U rate from 1971
• Correlations
• SJ 50
• SC 25
• JC 10
• Fit t-copula
• Takes correlation matrix
• Dof parameter n expresses tail strength
• This is gt in pairs with higher correlation

27
F/X Fits

• MLE dof n 19.7
• Take n 1 as a bad fit
• Fit already close to normal copula but use n500
  to represent pretty good fit
• Reduces ln L by about 1
• Extra parameter for t vs. normal worth it by
  Akaike but not by other information criteria
• Can look pairwise and all together

28
PP, I, K Functions

• Constrained to go from 0,0 to 1,1
• Makes it hard to see differences
• Subtracting empirical flattens out and shows
  differences better

29
Frank clearly worse fit HRT best on left HRT vs.
Gumbel hard to tell on right
30
Differences show up more clearly
31
K differences are hard to read
32
K errors show better but still hard to choose
normal vs. n 20
33
PP Plot AP Empirical vs Fits
Cant tell much
34
Frank shows up as clearly worse and HRT generally
best
35
Bad fitting n1 shows but cant tell normal from
n20
36
Bad fitting n1 shows but cant tell normal from
n20
37
Harder to tell anything in regular PP-plot, but
n1 still looks off
38
Hard to tell much from I(z) but differ-ences show
up well
39
Again readily shows bad fit but hard to tell good
from pretty good PP, K and I work better as
errors and can tell HRT from Gumbel but not n500
from n20. All three give pretty much the same
story
40
Tail Functions

• Important in insurance because usually sum of
  variables is taken
• If large losses are highly correlated this can
  impact sum
• Though different story is told, resolution is
  similar to that of PP, I, K
• Empirical L R noisy in tails

41
Frank clearly worse fit HRT clearly best L(z) HRT
probably best R(z)
42
R and L functions also distinguish n1 but not
normal from n20
43
M (conditional mean) has two empiricals
conditioning on U or V lt z Even bad fit does not
always show up as bad here
44
Frank clearly worse fit HRT best on left HRT vs.
Gumbel hard to tell on right
Two empirical conditional means
45
Conditional and Partial Correlations

• J is build up of tau
• Q is conditional rank correlation
• Could try the other way also
• Both appear more sensitive to how good the fit is

46
Quite noisy on left HRT better on right but not
great
Conditional rank correlation U,V lt z
47
Not quite as noisy on left HRT still better on
right but still not great
Conditional rank correlation U lt z
48
HRT generally better than others
Cumulative Tau U,V lt z
49
Conditional rank correlation (here on Ultz) does
show some difference between normal and t with n
20
50
Similar for conditioning on U, V lt z
51
For cumulative tau (here conditioned on U, V lt
z), normal vs n20 can be discerned
For SJ a somewhat lower value of n may have
worked better compromise of only one tail
parameter
52
5. Absolute Tests of Fit

• Compare empirical descriptive functions to
  confidence intervals based on best fitting copula
• Get confidence intervals by drawing from copula
  samples of the same size as original sample
• Look at percentiles of the descriptive functions
  at each z

53
L and R shown with 50 and 80 confidence bands
from HRT generally good fit
54
K errors also generally reasonable but more
outside 80
55
Partial correlations show potential problems with
fit
56
(No Transcript)
57
SJ and JC ok but less than ideal. Suggests need
for more parameter copulas
58
Conclusions

• For I, K and PP plots, error plots show fit
  quality better than standard plots
• Cumulative and conditional correlations appear to
  show fit differences best
• L and R are important for insurance applications
  but empiricals are noisy making judging fits
  harder
• M (conditional mean) differentiates less
