Software Design

1
Software Design

• Dr Z He
• University of Ulster

2
Lecture 4 Software Design

• Objectives
• What is Software Design?
• Data design, architectural design, interface
  design and component level design
• Translating the analysis model into a software
  design
• Software Design Concepts
• abstraction, modularity, information hiding
• Software Architectural Design
• what is software architecture?
• Mapping requirements into software architecture
• transform flow, transaction flow,
  transform/transaction mapping
• transform mapping
• JSD
• User Interface Design
• what is it?,steps, golden rules
• Component-level Design
• what is it?, notations (flowchart, decision
  table, PDL))

3
What is Software Design?

• Software design
• sits at the technical kernel of software
  engineering
• begins once software requirements have been
  analysed and specified
• is the first of the three technical activities
  design, coding, testing

4
Software Design

• Data design
• transforms the information domain model into data
  structure required to implement the software
• also performed in architectural design and
  component level design
• Architectural design
• defines the relationship between major structural
  elements of the software
• defines the design patterns that can be used to
  achieve the requirements
• defines the constraints that affect the way in
  which architectural design patterns can be
  applied
• Interface design
• describes how the software communicates within
  itself, to systems that interoperate with it, and
  with humans who use it
• Component-level design
• transforms structural elements of the software
  architecture into a procedural description of
  software components

5
Software Design
State transition diagram
Component- level Design
Process Specification
Data Flow Diagram
Interface Design
Entity-relationship Diagram
Architectural Design
Data Design
Data Dictionary
Transforming the analysis model into a software
design
6
Software Design Concepts Abstraction

• Design Considerations
• 1. Abstraction
• Ignore the details that are not relevant at this
  stage
• 2 types
• procedural abstraction
• data abstraction
• Procedural abstraction
• decompose the problem into sub-problems,
  decompose these into further sub-problems etc.
• This top down approach leads to modules which
  are easy to program
• sub-problems are ordered logically

7
Software Design Concepts Abstraction

• Data Abstraction
• consider the data only to the level required
• e.g. paragraph, sentence, word ... in text
  processing.
• One example of data abstraction is data
  encapsulation.
• e.g. job queue in a compiler. At the top level we
  know there is a queue and that it has the
  functions initialise queue, add to the queue
  and delete from the queue. At a lower level we
  might consider how the queue is implemented, as
  records or arrays.
• (see later under object oriented design)

8
Software Design Concepts Modularity

• 2. Modularity
• What is module? - a grouping of sections of code.
• Pascal - procedure
• C - function
• Fortran - subroutine
• BASIC - subroutine
• Cobol - subprogram
• Ada - procedure or package
• Advantages
• Easier to design small modules
• Easier to find bugs
• Easier to maintain
• facilitates independent development
• allows for reuse

9
Software Design Concepts Modularity

• How big should a module be?
• How complex should a module be?
• How can we minimise the interactions between
  modules?

OR
10
Software Design Concepts Modularity

• What about global data?
• Global data is harmful!
• To understand A we must know about B C because
  of the global data
• To change 1 of the modules, if we need to change
  the data
• Local data is better because
• easier to read study
• easier to remove a procedure
• maintenance is easier
• reusability

Global data shared
A
B
C
11
Software Design Concepts Modularity

• Modularity - Cohesion and Coupling
• (ref Bell et al ch. 5)
• Cohesion - the degree of interaction within a
  module
• Coupling - the degree of interaction between
  modules
• COHESION
• Coincidental Cohesion - tasks which are unrelated
• difficult to maintain (no advantage in
  modularization)
• no reusability
• Logical Cohesion - tasks in a module are
  logically related
• e.g. all the tasks are to do with input.
• interface is difficult to understand
• difficult to maintain if code for individual
  tasks is related

12
Software Design Concepts Modularity

• Temporal Cohesion - tasks in a module are related
  by the fact they are done at the same time
• e.g. initialisation module
• tasks are not related and so if changes are to be
  made in this module, other parts will have to be
  changed also.
• modules name may not adequately describe its
  purpose
• Procedural Cohesion - tasks are related because
  they are done in a sequence.
• e.g. read item price, calculate amount due,
  update stock file
• better than temporal since actions are related
• but still module is likely not to be reusable
  since this relation is weak
• since all parts of the module do not deal with
  the same data, it may be difficult to find
  associated pieces

13
Software Design Concepts Modularity

• Communicational Cohesion - tasks are related
  procedurally but also are on the same data.
• e.g. read item price, calculate amount due, print
  total
• better than procedural cohesion
• still not very reusable
• Sequential Cohesion - output of one component of
  the module forms input for the next.
• e.g. read transaction file, update master file
  (pipe-lined tasks!)
• not reusable
• Functional Cohesion - All components contribute
  to a single function of the module.
• e.g. calculate VAT (one verb and one noun)
• reusable
• easily maintained

14
Software Design Concepts Modularity

• Summary of Cohesion Types (He, Z. Nov. 1999)

15
Software Design Concepts Modularity
Compute average daily temperatures at various
sites

• Example

coincidental
functional
coincidental
functional
initialise sums and open files
create new temperature record
store temperature record
close files and print average temperatures
logical
functional
read in site, time, and temperature
store record for specific site
logical
edit site, time or temperature field
16
Software Design Concepts Modularity

• COUPLING
• Content Coupling - One module directly affects
  the working of another. Calling module can modify
  the called module or refer to an internally
  defined data element.
• e.g. GOTO.
• makes maintenance very difficult as program will
  be difficult to understand.
• never allow this type of coupling!
• Common Coupling - Two modules accesses the same
  global data.
• E.g. Data division in COBOL
• resulting code is difficult to read
• side affects e.g has another module changed a
  variable?
• programs are costly to maintain as a change to a
  global variable means the whole program has to be
  searched to find its affect
• reusability is poor
• security problems. A module has access to more
  data than it needs

17
Software Design Concepts Modularity

• Control Coupling - One module passes information
  (e.g. flag) which will affect the logic of the
  other module.
• modules are not independent and so reuse is
  limited
• violates principle of information hiding (see
  later)
• calling module must know how the called module
  works

Remove the flag by having two modules, one for
increasing stock level, the other for decreasing
stock levels
18
Software Design Concepts Modularity

• Stamp Coupling - complete data structures are
  passed from one module to another, with the data
  structure being defined in both but not all
  components of the data structure are changed
• more data than is necessary is passed
• Data Coupling - data required by a module is
  passed from another (parameters)

Desirable - HIGH COHESION (functional cohesion)
LOW COUPLING (data coupling)
19
Software Design Concepts Information Hiding

• Information hiding
• Each module has information which other modules
  have no access to
• Hence a change to this cannot affect any other
  module
• increases cohesion, since the information hide
  binds the components of the module together
• design decisions that may change at a later date
  should be hidden from other modules. In this
  maintainability is increased since only that
  module needs to know about the change

20
Software Architectural Design

• What is software architecture?
• The software architecture of a program or
  computing system is the structure or structures
  of the system, which comprise software
  components, the externally visible properties of
  those components, and the relationships among
  them.
• At the architectural level, internal properties
  (e.g. details of an algorithm) are not specified
• Architectural Styles
• Data centred architecture, data flow
  architecture, call and return architecture,
  object-oriented architecture, layered
  architecture
• See, Pressmans book for more

21
Software Architectural Design

• Mapping requirements into a software architecture
• Transform Flow
• information enter software from external world
• external information converted into internal
  forms (incoming flow)
• incoming data are transform (transform centre)
• processed data converted for external use
  (outgoing flow)
• information exit software to external world
• Transaction Flow
• similar to transform flow, but an incoming flow
  will reach a transaction centre, where one of
  many paths will be taken.
• Transaction flow is characterized by data moving
  along an incoming path that converts external
  world information into a transaction. The
  transaction is evaluated and based on its value,
  flow along one of many action paths is initiated.

22
Software Architectural Design

• Mapping requirements into a software architecture
• Transform Mapping
• also called transform analysis
• set of design steps that allows a DFD with
  transform flow characteristics to be mapped into
  a specific architectural design
• you need to identify a transform centre in a DFD
• Transaction Mapping
• also called transaction analysis
• set of design steps that allows a DFD with
  transaction flow characteristics to be mapped
  into a specific architectural design
• you need to identify a transaction centre in a
  DFD
• In this lecture
• we will discuss transform mapping (design method)
• also Jackson Structured Development (JSD) (design
  method)

23
Transform Mapping

• Transform Mapping (Bell et al, ch 8)
• input is a set of DFDs
• Each DFDs represents the transformation of input
  to output
• Input becomes internal data and, later, output
• Thus - three modules
• INPUT
• TRANSFORM
• OUTPUT
• Each of these is then further decomposed.
• This process continues until the module performs
  a single task (high cohesion)

24
Transform Mapping

• Steps
• Identify the central transformations
• Draw a top level structure of the module
• Factor lower levels

25
Transform Mapping
Example
Customer File
transform
output
input
Obtain account number
check identity of customer
extract account details
Calculate balance
Format Balance
Display Balance
account details
balance
a/c no.
valid a/c no.
formatted balance
Account file
Data Flow diagram for a balance enquiry system
26
Transform Mapping
Controlling Module
Input Module
Output Module
Transform Module
Standard format for transform analysis
27
Transform Mapping
Obtain Balance Details
bal details
account details
a/c details
bal details
Calculate Balance
Obtain Account Details
Display Balance
28
Transform Mapping
Obtain Balance Details
check flag
bal details
account details
a/c details
bal details
Calculate Balance
Obtain Account Details
Display Balance
a/c details
a/c no
formatted balance
balance
a/c no (val)
formatted balance
a/c no
a/c no (val)
Obtain account number
Check customer identity
Extract account details
Format Balance
Display Balance
29
Jackson Structured Development

• See Bell et al ch 7
• Data oriented
• 3 constructs
• sequence
• iteration and
• selection

30
Jackson Structured Development
SEQUENCE ITERATION SELECTION
A
A
A
B
B
C
D
BO
BO
BO
Pseudocode A seq B C D A end
A itr B A end
A sel B A alt C A alt D A end
31
Jackson Structured Development

• Example 1
• suppose we want a program to produce the output
  as shown

Top-half
Bottom-half
Middle
Line
Line
32
Jackson Structured Development

• Next, define elementary operations

1. Write n asterisks 4. Increment s 7. Decrement
n 2. Write a blank line 5. Decrement s 8.
Initialise n s 3. Write s spaces 6. Increment n

• Add operations to the diagram

8
2
1
5
1
4
3
6
3
7
33
Jackson Structured Development

• Transform into pseudocode
• initialise n and s
• while more lines
• do
• write s spaces
• write n asterisks
• decrement s
• increment n
• end while
• write blank line
• initialise n and s
• while more lines
• do
• write s spaces
• write n asterisks
• decrement n
• increment s

34
Jackson Structured Development

• Summary of steps
• Draw a diagram showing the structure of the data
• Derive the corresponding program structure chart
• Write down the elementary operations
• Place the operations on the program structure
  diagram
• Derive the schematic logic of the program

35
Jackson Structured Development

• Example 2
• Design a program to input and add up any number
  of numbers ending with a negative number

Steps 1. Read number 2. Add number to sum 3.
Initialise sum 4. Print sum
Process Numbers
sum0 read number while number gt 0 do add
number to sum read number end while print sum
Process Body
Process Negative Number
3
1
Process Number
2
4
36
Jackson Structured Development

• Example 3
• Suppose we have a stock control system that has a
  menu

STOCK CONTROL 1. Issue stock 2. Receive stock 3.
Create item 4. Delete item 5. Query item 6.
Exit Please enter choice_
Dialogue
Screen
Heading
Choices
Prompt
Response
Invalid
Valid
Wrong
1 o
2 o
Etc.
Junk
Error msg
37
Jackson Structured Development
While usr choice not end do clear screen
display heading display choices display
prompt accept user choice while user
choice is wrong do display error msg
accept user choice end while case user
choice 1 call issue procedure .
. 5 call query procedure end
case end while

• Elementary operations
• clear screen
• display heading
• display choices
• display user prompt
• accept user response
• display error message
• call issue procedure
• call receive procedure
• call create procedure
• call delete procedure
• call query procedure

38
User Interface Design

• User Interface Design
• creates an effective communication medium between
  a human and a computer
• identifies interface objects and actions and then
  creates a screen layout that forms the basis for
  an user interface prototype
• an iterative process
• Steps
• identify user, task and environmental
  requirements
• create scenarios which are then analysed to
  define a set of interface objects and actions
• create screen layout (graphics, text, menus, etc)
• prototype the design
• evaluate for quality

39
User Interface Design

• Golden Rules
• Place the user in control
• define interaction modes in a way that does not
  force a user into unnecessary or undesired
  actions
• provide for flexible interaction
• allow user interaction to be interruptible and
  undoable
• streamline interaction as skill levels advance
  and allow the interaction to be customised
• hide technical internals from the casual user
• design for direct interaction with objects that
  appear on the screen

40
User Interface Design

• Golden Rules
• Reduce the users memory load
• reduce demand on short-term memory
• establish meaningful defaults
• define shortcuts that are intuitive
• the visual layout of the interface should be
  based on a real world metaphor
• disclose information in a progressive fashion
• Make the interface consistent
• maintain consistency across a family of
  applications
• do not change past interactive models unless
  there is compelling reason to do so

41
Component-level Design

• Component-level Design
• also called procedural design
• occurs after data, architectural, and interface
  designs
• represents the design at a level of abstraction
  that is close to code
• establishes the algorithm detail required to
• manipulate data structures, effect communication
  between software components via their interfaces,

• and implement the processing algorithms allocated
  to each component
• Component-level design notations
• Flowchart (based on structured programming,
  Dijkstra, 1960s)
• Decision table
• Program Design Language (PDL)

42
Component-level Design

• Flowchart (sequence, if-then-else, switch,
  do-while, repeat-until)

43
Component-level Design

• Decision Table
• CONDITIONS 1 2 3
  4 5
• fixed rate account T T F F F
• variable rate account F F T T F
• consumptionlt100kwh T F T F
• consumptiongt100kwh F T F T
• ACTIONS
• min. monthly charge X
• schedule A billing X X
• schedule B billing X
• other treatment X

44
Component-level Design

• Program Design Language (PDL)
• also called structured English, or pseudocode
• looks like programming language, but
• use narrative text embedded directly into a
  syntactical structure
• cannot be compiled
• could be translated into a programming language
  skeleton or a graphical representation(e.g.
  flowchart) of design
