Proposed CoGeneration and Photovoltaic Project

1
Proposed CoGeneration and Photovoltaic Project

• Presented to Board of Trustees
• 1/5/04

2
Overarching Goal

• Continuous improvement in our energy management
  performance.
• Supports Statewide Energy Management Program
  (SEMP) AB29X, 4/11/01
• the use of renewable or other distributed energy
  systems

3
Electricity Consumption
4
Project Goal

• Two CoGeneration plants capable of producing 240
  kW each.
• Two Photovoltaic installations rated at 388 kW

5
What is CoGen?

• Also known as Combined Heat Power or (CHP).
• Series of micro-turbines that are powered by
  natural gas to produce electricity. The waste
  heat is captured and used to heat the swimming
  pool water.

6
Typical InstallationCal State Northridge
7
Proposed CoGen Installation

• Four 60kW microturbines located near the pool
  mechanical rooms on each campus.
• Sufficient heat produced to meet pool demand
  during certain times of year. (One engineer was
  concerned that too much heat would be produced.)

8
Photovoltaics?

• Composite glass panels that convert sunlight to
  electrical energy.

9
PV Technology Fundamentals
10
Foothill PV Installation

• Cover 60 parking places in Lot 2
• 8,540 square feet
• Annual production 158,400 kWH

11
The is the largest PV carport in the world,
providing 1,000 KW to the Naval Base in Coronado
Island (by the PowerLight Corporation)
12
Typical Car Port Installation
13
DeAnza PV Installation

• Located on top of Lot C Parking Structure
• Covers 120 parking spaces
• Annual production 408,000 kWH
• Tracking system allows panels to follow sun to
  maximize production.

14
Typical Tracker Installation
15

16
Value to District?

• Project will produce 63,000,000 kWH over 15 year
  period or about 24 of total use.
• District used 17,500,000 kWH in 2002-03
• Environmentally sound solution
• CoGen is very efficient
• Photovoltaics cleanest way to produce electricity

17
Why we should do this!

• Promotes environmental stewardship
• Generates goodwill in the community
• Generates visibility for the District
• Provides opportunities for education and outreach
• Places District in competitive position for
  future rate fluctuations.

18
Electricity Rates
19
(No Transcript)
20
Performance ContractingAuthorized by Govt Code
4217

• Anticipated cost to the public agency for
  conservation services will be less than the
  anticipated marginal cost of the energy that
  would have been consumed by the public agency.
• District successfully completed 7.5 million
  performance contract with Viron Energy Services
  in 1998-99.

21
Proposed Contract

• Viron purchased by ChevronTexaco now known as
  Chevron Energy Services
• Total contract 5,146,000
• State Federal incentives 1,990,000
• District to provide utility bldgs for CoGen at
  estimated cost of 400,000 source is funds
  earmarked for energy conservation.

22
Proforma Fifteen Years

• Annual Savings - 10,664,000
• Operating cost - 5,478,000
• Loan payments - 4,410,000
• Net savings 776,000
• Based on investment of 3,556,000
