Title: AspectJ - Java based AOP System


1
AspectJ - Java based AOP System
2
AspectJ - basic features
  • Compatible extension to Java
  • Upward Compatibility - all legal Java programs
    are legal AspectJ programs
  • Platform Compatibility - all legal AspectJ
    programs run on all standard Java VM
  • Tool Compatibility - existing tools can be
    extended to support AspectJ in a natural way
    IDEs, documentation and design tools
  • Programmer Compatibility - Programming with
    AspectJ must feel like a natural extension to
    programming with Java

3
AspectJ - basic features (contd.)
  • AspectJ program structure
  • Classes - like in Java
  • Aspects - for concerns that crosscut class
    structure
  • AspectJ crosscutting implementation
  • Dynamic - define additional implementation to run
    at certain point of program execution
  • Static - define new operation on existing types
    (introduction)

4
AspectJ - language overview
  • Basic concepts
  • Joinpoint - certain points in a programs
    execution (for example - a call to a class
    method
  • Pointcut - Program constructs to designate
    joinpoints and to collect specific context at
    these points
  • Advice - Code that runs upon meeting certain
    conditions
  • Aspect - class like crosscutting unit, where
    advice and pointcuts form weaving rules

5
Joinpoints
  • certain points in a programs execution
  • have context associated with them (for example a
    method call joinpoint can have the target object
    as a part of the context
  • in AspectJ, available joinpoints are limited to
    the following
  • Method call and execution
  • Constructor call and execution
  • Read/Write access to field
  • Exception handler execution
  • Object and class Initialization execution

6
Pointcut designators
  • Program constructs to designate Joinpoints
  • set of Joinpoints and (optionally) some values
    from their execution context
  • AspectJ provides primitive pointcut designators
    which can be used to compose named/anonymous user
    defined pointcuts

7
Pointcut designators (contd.)
  • primitive pointcut designators
  • calls(signature) / receptions(signature) /
    executions(signature) - matches
    call/reception/execution join points at which the
    method/constructor called matches signature
    method signature ResultTypeName
    RecvrTypeName.meth_id (params) constructor
    signature NewObjectTypeName.new (params)
  • gets(signature) / gets(signature) val /
    sets(signature) / sets(signature) oldVal /
    sets(signature) oldVal newVal - matches get /
    set join points where the field accessed matches
    signature
    field signature FieldTypeName
    ObjectTypeName.field_id

8
Pointcut designators (contd.)
  • primitive pointcut designators (contd)
  • handles(ThrowableType) - matches exception
    handler execution join point of the specified
    type
  • instanceof(CurrentlyExecutingObjectType) - this
    is of specified type
  • within(ClassName) / withincode(signature) -the
    executing code is contained within ClassName /
    within the specified method
  • cflow(pointcut_designator) - for example ltcflow
    (call ( MyClass.myMethod (..))gt - all joint
    points in control flow of call to the method

9
Pointcut designators (contd.)
  • primitive pointcut designators (contd)
    context collecting pointcuts
  • this(object) - all the join points where this
    is the object specified
  • target(object) - the method is called on
    specified object
  • args(arg1, ..) - the join points where the
    arguments are as specified
  • named / unnamed pointcuts (like named / unnamed
    classes)
  • use , , !, .., , to compose pointcuts

10
Advices
  • Associate code with a specific pointcut
  • Advice types available before, after (after
    returning / after throwing), around
  • the context is passed to advice by the pointcut
  • example pointcut move (Line l)
    receptions (void l.MoveXY (int, int)) after
    (Line l) move (l) /print msg/

11
Advices (contd.)
  • Order of advice execution
  • any around advise (most specific first) the
    invocation of proceed () invokes next most
    specific around advise
  • any before advice, most specific first
  • the computation itself
  • all after advice, less specific first
  • return value from step (3) is returned to the
    innermost call to proceed () and that piece of
    around advice continues running
  • when the innermost around advice finishes, the
    surrounding around advice continues running
  • once the outermost piece of around advice
    returns, control continues back from the join
    point

12
Advices (contd.)
  • Aspect precedence (for two pieces of advice a1,a2
    defined in aspects A1,A2 respectively)
  • if A1 A2, the advice that appears first in the
    aspects declaration body is more specific
  • A1 extends A2 --gt a1 is more specific
  • declaration of A1 includes a dominates modifier
    that mentions A2 --gt a1 is more specific than a2

13
Aspects
  • Modular units of crosscutting implementation
  • declaration - similar to class declaration
  • include pointcut declarations, advice
    declarations and declarations permitted in class
    declaration
  • aspect inheritance, abstract aspects are supported

14
Example1 - thread pooling
  • Thread pooling - more effective and resource
    saving approach to thread managenment
  • AOP implementation in a modular fashion - source
    code need not be modified
  • original code - simple multithreaded Server

15
The server source code
// UppercaseServer.javaimport java.io.import
java.net.public class UppercaseServer
public static void main(String args) throws
Exception if (args.length ! 1)
System.out.println("Usage java
UppercaseServer ")
System.exit(1) int portNum
Integer.parseInt(args0) ServerSocket
serverSocket new ServerSocket(portNum)
while(true) Socket requestSocket
serverSocket.accept() Thread
serverThread new Thread(new UppercaseWorker(requ
estSocket)) serverThread.start()

16
class UppercaseWorker implements Runnable
private Socket _requestSocket public
UppercaseWorker(Socket requestSocket) throws
IOException System.out.println("Creating
new worker") _requestSocket
requestSocket public void run()
BufferedReader requestReader null
Writer responseWriter null try
requestReader new BufferedReader(new
InputStreamReader(_requestSocket.getInputStr
eam())) responseWriter new
OutputStreamWriter(_requestSocket.getOutputStream(
))
17
while(true) String requestString
requestReader.readLine() if (requestString
null) break System.out.println("Got request
" requestString) responseWriter.write(requestS
tring.toUpperCase() "\n") responseWriter.flush
() catch(IOException ex)
finally try if (responseWriter !
null) responseWriter.close() if
(requestReader ! null) requestReader.close()
_requestSocket.close() catch
(IOException ex2) System.out.println("Ending
the session")
18
// ThreadPool.java - simple class that acts
like stack for available threadsimport
java.util. public class ThreadPool List
_waitingThread new Vector() public void
put(DelegatingThread thread) System.out.printl
n("Putting back " thread) _waitingThread.add
(thread) public DelegatingThread get()
if (_waitingThread.size() ! 0)
DelegatingThread availableThread
(DelegatingThread)_waitingThread.remove(0)
System.out.println("Providi
ng for work " availableThread)
return availableThread
return null static class
DelegatingThread extends Thread private
Runnable _delegatee public void
setDelegatee(Runnable delegatee)
_delegatee delegatee public void
run() _delegatee.run()
19
Adding thread pooling
// ThreadPooling.javapublic aspect ThreadPooling
ThreadPool pool new ThreadPool()
//
// Thread creation
//
pointcut
threadCreation(Runnable runnable)
call(Thread.new(Runnable)) args(runnable)
Thread around(Runnable runnable)
threadCreation(runnable)
ThreadPool.DelegatingThread availableThread
pool.get() If (availableThread null)
availableThread new ThreadPool.DelegatingThre
ad() availableThread.setDelegatee(r
unnable) return availableThread
20
Adding thread pooling (contd.)
//
// Session
//
pointcut
session(ThreadPool.DelegatingThread thread)
execution(void ThreadPool.DelegatingThread.run())
this(thread)void around(ThreadPool.Delegatin
gThread thread) session(thread)
while(true) proceed(thread)
pool.put(thread) synchronized(thread)
try thread.wait()
catch(InterruptedException ex)

21
Adding thread pooling (contd.)
//
// Thread start //
pointcut
threadStart(ThreadPool.DelegatingThread thread)
call(void Thread.start())
target(thread)void around(Thread thread)
threadStart(thread) if (thread.isAlive())
// wake it up synchronized(thread)
thread.notifyAll()
else proceed(thread)
22
The implementation in details
  • threadCreation() captures the creating a new
    thread object taking a Runnable object as the
    argument.
  • Advise the threadCreation() pointcut to first
    check the thread pool for available threads. If
    no thread is available, create a new one. Set the
    delegatee to the Runnable object passed in and
    return that object. No proceed() so the actual
    operation is not executed
  • session() captures the run() method's execution
    of any ThreadPool.DelegatingThread objects.

23
The implementation in details (contd.)
  • By putting session() inside a while(true) loop,
    you advise session() to never finish the
    servicing. That ensures a thread, once created,
    never dies. Once a request is processed, you put
    the thread back into thread pool and put the
    thread into waiting state.
  • threadStart() captures a call to the
    Thread.start() method. It uses isAlive() to check
    if the thread previously started (thread obtained
    from a pool and now in a waiting state) Wake up
    the thread by notifying it. If the thread had not
    started yet, proceed with starting the thread.

24
Example 2 - Enforcement modularization
  • Implement policy enforcement to ensure no
    duplicate listener are added to the models, and
    listeners do not loiter around when the view they
    represent become usable.
  • Policy enforcement implementation in more useful
    and easy way - no documentation,code reviews and
    so on.

25
Problems with listeners
  • let you add a listener object more than once,
    which leads to duplicate work if an
    event-notification method carries an expensive
    operation.
  • Easy to forget to remove listeners before
    destroying a view - cause the listener to
    consuming memory.

26
aspect structural view
  • need to implement 2 concerns
  • uniqueness concern
  • no loitering-views concern

27
Base aspect EventListenerManagement
  • This aspect contains an addListenerCall()
    pointcut that captures calls to methods adding a
    listener.
  • // EventListenerManagement.javaimport
    java.util.public abstract aspect
    EventListenerManagement pointcut
    addListenerCall(Object model, EventListener
    listener) call(void .addListener(EventListene
    r)) target(model) args(listener)
    modelAndListenerTypeMatch()abstract pointcut
    modelAndListenerTypeMatch()

28
Implement the uniqueness concern
  • checks whether that listener was previously
    added. If that listener is already present, the
    operation does not proceed otherwise, it adds
    the listener
  • advises the addListenerCall() pointcut to check
    for the listener's uniqueness by looking in a
    list obtained by invoking getCurrentListeners().
    It proceeds with adding the listener only if the
    list doesn't include a listener

29
Implement the uniqueness concern - contd.
  • // EventListenerUniqueness.javaimport
    java.util.import javax.swing.import
    javax.swing.event.import javax.swing.table.
    public abstract aspect EventListenerUniqueness
    extends EventListenerManagement void
    around(Object model, EventListener listener)
    addListenerCall(model, listener)

30
Implement the uniqueness concern - contd.
  • EventListener listeners getCurrentListeners(mo
    del)if (!Utils.isInArray(listeners, listener))
    System.out.println("Accepting "
    listener)proceed(model, listener) else
    System.out.println("Already listening "
    listener)public abstract EventListener
    getCurrentListeners(Object model)

31
Implement the uniqueness concern - contd.
  • the concrete aspect TableModelListenerUniqueness
    extends EventListenerUniqueness to apply the
    aspect to TableModel and related classes. It
    provides an implementation for the
    modelAndListenerTypeMatch() pointcut to restrict
    the model type to AbstractTableModel and the
    listener type to TableModelListener.

32
Implement the uniqueness concern - contd.
  • // TableModelListenerUniqueness.javaimport
    java.util.EventListenerimport
    javax.swing.event.TableModelListenerimport
    javax.swing.table.aspect TableModelListenerUni
    queness extends EventListenerUniqueness
    pointcut modelAndListenerTypeMatch()
    target(AbstractTableModel) args(TableModelListe
    ner)public EventListener getCurrentListeners(
    Object model) return ((AbstractTableModel)model)
    .getListeners(TableModelListener.class)

33
Implement a no loitering-views concern
  • ensuring that no view loiters after its
    destruction.
  • It advises addListenerCall() to proceed with the
    listener obtained by calling the
    getWeakListener() method.

34
Implement a no loitering-views concern - contd.
  • // EventListenerWeakening.javaimport
    java.lang.ref.import java.util.import
    javax.swing.event.public abstract aspect
    EventListenerWeakening extends
    EventListenerManagement dominates
    EventListenerUniqueness void around(Object
    model, EventListener listener)
    addListenerCall(model, listener) proceed(model,
    getWeakListener(listener))public abstract
    EventListener getWeakListener(EventListener
    listener)

35
Implement a no loitering-views concern - contd.
  • The TableModelListenerWeakening aspect handles
    table-related listeners. It uses a specialized
    WeakEventListener that implements
    TableModelListener by delegating to the referent
    object.

36
Implement a no loitering-views concern - contd.
  • // TableModelListenerWeakening.javaimport
    java.util.import javax.swing.event.import
    javax.swing.table.public aspect
    TableModelListenerWeakening extends
    EventListenerWeakening pointcut
    modelAndListenerTypeMatch() target(AbstractTabl
    eModel) args(TableModelListener)public
    EventListener getWeakListener(EventListener
    listener) System.out.println("Weakening "
    listener)return new WeakTableModelListener((Tabl
    eModelListener)listener)

37
Implement a no loitering-views concern - contd.
  • public class WeakTableModelListener extends
    WeakEventListener implements TableModelListener
    public WeakTableModelListener(TableModelListene
    r delegatee) super(delegatee)public void
    tableChanged(TableModelEvent e)
    TableModelListener listener
    (TableModelListener)getDelegatee()listener.table
    Changed(e)

38
Implement a no loitering-views concern - contd.
  • static aspect TableRemoveGarbageCollectedListener
    s extends WeakEventListener.RemoveGarbageCollecte
    dListeners pointcut lexicalScopeMatch()
    within(WeakTableModelListener)public void
    removeListener(EventObject event, EventListener
    listener) ((TableModel)event.getSource()).remov
    eTableModelListener((TableModelListener)listener)

39
Example 3 Characteristic-based implementation
modularization
  • Operations with the same characteristics should
    typically implement common behaviors. for example
    you may need to authenticate access to all
    security-critical data.

40
Characteristic-based implementation modularization
  • declare the aspect adding characteristic-based
    crosscutting behavior as an abstract aspect.
  • declare an abstract pointcut for methods with
    characteristics under consideration.
  • write an advice performing the required
    implementation.

41
SlowMethodAspect's implementation
  • abstract slowMethods() pointcut and advises it to
    first put a wait cursor, proceed with the
    original operation, and finally restore the
    original cursor.

42
SlowMethodAspect's implementation - contd.
  • // SlowMethodAspect.javaimport
    java.util.import java.awt.import
    java.awt.event.public abstract aspect
    SlowMethodAspect abstract pointcut
    slowMethods(Component uiComp)void
    around(Component uiComp) slowMethods(uiComp)
    Cursor originalCursor uiComp.getCursor()Curs
    or waitCursor Cursor.getPredefinedCursor(Cursor.
    WAIT_CURSOR)uiComp.setCursor(waitCursor)

43
SlowMethodAspect's implementation - contd.
  • try proceed(uiComp) finally
    uiComp.setCursor(originalCursor)

44
SlowMethodAspect's implementation - contd.
  • Two test components, GUIComp1 and GUIComp2, nest
    a concrete implementation of the aspect.
  • public static aspect SlowMethodsParticipant
    extends SlowMethodAspect pointcut
    slowMethods(Component uiComp) execution(void
    GUIComp1.performOperation1()) this(uiComp)

45
SlowMethodAspect's implementation - contd.
  • public static aspect SlowMethodsParticipant
    extends SlowMethodAspect pointcut
    slowMethods(Component uiComp) (execution(void
    GUIComp2.performOperation1()) execution(void
    GUIComp2.performOperation2()))
    this(uiComp)
Write a Comment
User Comments (0)
About PowerShow.com
