Ontario School Boards

1
Ontario School Boards Insurance Exchange2008
Risk Management Seminar
It Isnt Easy
Being Green
Mark Blank - FM Global November 6, 2008
2
Ontario School Boards Insurance Exchange2008
Risk Management Seminar
It Isnt Easy
Being Green
3
It Isnt Easy Being Green
Objectives

• Going Green Overview.

• The Property Hazards of Green Technologies.

• How can FM Global Help You Today?

• Whats Next?

4
It Isnt Easy Being Green
RENEWABLE
LEED Leadership in Energy and Environmental
Design
SUSTAINABLE
5
It Isnt Easy Being Green
Education Going Green
2006 - The first LEED Silver certified elementary
school in Canada, Thomas L. Wells Scarborough
Ontario, is the first of a new generation of high
performance 'green-schools' in Toronto. The
school is designed to create a stimulating
environment that is conducive to learning, with
plenty of natural light, and a sense of community
for students and local residents.
6
It Isnt Easy Being Green
7
It Isnt Easy Being Green
Wind Power Farms
City College Plymouth, UK
8
It Isnt Easy Being Green
Solar Photo Voltaic Panels
Solar Hot Water Systems
9
It Isnt Easy Being Green
Solar Photo Voltaic Panels
Karen Tapia-Andersen / Los Angeles Times Spring
2008 Solar power panels are placed atop a parking
lot at East Los Angeles College in Monterey Park.
The photovoltaic farm is expected to last at
least 40 years and is currently producing about
45 of the colleges energy, or 1.9 million
kilowatts annually for a yearly savings of
270,000.
10
It Isnt Easy Being Green
GREEN ROOFS

• 2007 - Tarkington School of Excellence is the
  first school in Chicago IL to be built under
  guidelines for Leadership in Energy and
  Environmental Design (LEED) certification. Green
  roofs can offer a range of benefits including
• Reduced storm water runoff and improved storm
  water quality.
• Extended life span of roofing system
• Reduced sewer costs.
• Improved air quality and reduced heat island
  effect.
• Reduced noise levels.
• Improved aesthetics for building occupants and
  neighbors

11
It Isnt Easy Being Green
GREEN WALLS
Exterior Insulation Finishing System (EIFS) on
One Park Tower condominium project in
Mississauga, Ontario.
12
It Isnt Easy Being Green
GREEN WALLS
High Rise Hotel with brick/block cavity wall
construction.
13
It Isnt Easy Being Green
Water Conservation
Testing of Water Based Fire Protection System?
14
It Isnt Easy Being Green
Energy Conservation
Harvesting Natural Sunlight - Plastic Roof Lights
15
It Isnt Easy Being Green
Renewable Fuels

• Hydrogen Fuel Cells
• Bio-Mass
• Ethanol/Biodiesel

16
It Isnt Easy Being Green
SO WHAT IS THE HAZARD?
Beware of the Dark Side of Green Technologies
17
It Isnt Easy Being Green
Government Actions
On March 10, 2008, the Government announced
further details of the greenhouse gas emissions
regulations of the Turning the Corner plan
putting into place one of the toughest regulatory
regimes in the world to meet its target of
reducing greenhouse gases an absolute 20 from
2006 by 2020.
18
It Isnt Easy Being Green
Wind Power

• Windstorm Hazards -
• Mechanical Over-speed Hazards
• Fire Hazards

19
It Isnt Easy Being Green
Solar Power

• Windstorm Hazards
• Collapse Hazards
• Hail Damage Hazards
• Wind Blown Debris

20
It Isnt Easy Being Green
Green Construction Roofs/Walls

• Not FM Approved
• Windstorm Hazards/ Wind-Borne Debris
• Hail Damage Hazards
• Collapse Hazards Ponding - Earthquake

21
It Isnt Easy Being Green
Green Construction Roofs/Walls

• FM Approved roof systems are validated to
  withstand worst case geographic wind forces and
  hail exposure which maintains the building shell
  intact during storm conditions and eliminates
  wind-borne debris from the roof system.
• FM Data Sheets provide specific guidance for
  proper installation of roof systems.

22
It Isnt Easy Being Green
Green Construction Roofs/Walls

• Exterior Fire Hazards
• Vegetated Roofs
• EIFS
• Interior Fire Hazards
• EIFS and Cavity Wall Construction

23
It Isnt Easy Being Green
Green Construction Roofs/Walls

• FM Approved roof coverings are Class 1 rated or
  Non-Combustible for both protection against
  external and internal roof system fire hazards.
• FM Approved Exterior Wall Constructions, Plastic
  Building Panels, and Insulated Core Walls are
  Class 1 rated. FM Approved Exterior Wall
  Constructions also have wind load ratings
  applicable to specific geographic areas

24
It Isnt Easy Being Green
Green Construction Walls
Cavity Wall Fire on High Rise Hotel 2007
EIFS Fire on High Rise Hotel - 2008
25
It Isnt Easy Being Green
Fire Protection Water Conservation

• Requirements in California to de-chlorinate fire
  protection water discharge to storm sewer systems
  (fire pump testing).

• U.S. State EPA Departments requiring designated
  permits to discharge non-potable water from
  sprinkler systems or fixed water supplies onto
  the ground or into storm water systems.

• Australian Fire Protection Testing Standards.

26
It Isnt Easy Being Green
Energy Conservation Skylights FM Global Concerns

• Plastic skylights can represent both an interior
  and exterior fire hazard (Acrylic and Fiberglass
  Reinforced Plastic). Tempered glass or
  polycarbonate skylights are recommended.
• All skylights subject to damage from wind driven
  debris.
• Plastic skylights subject to deterioration from
  sunlight UV exposure.

27
It Isnt Easy Being Green
Energy Conservation Plastic Roof Lights

• Fireworks Ignites FRP Skylight
• Fireworks ignited the FRP (Fiberglass Reinforced
  Plastic) roof mounted skylight at this warehouse
  causing the fire to spread into the building.
  Automatic sprinklers below the skylight
  controlled the fire.
• 850,000 Physical Damage -0- Lost Business
• Roofing Contractor Causes Skylight Fire
• Roofing contractors working on a medical products
  warehouse ignited the roof covering which spread
  the fire to an acrylic skylight. Automatic
  sprinklers and employee action prevented the fire
  from spreading to the warehouse storage.
• 450,000 Physical Damage -0- Lost Business

28
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Hydrogen

• Hydrogen - No NRTL testing/certification
  protocol
• Fuel tanks fixed to equipment which can be metal
  or composite (plastic).
• High pressure operation (gt1000 psi).
• Represent fire and explosion hazards.

29
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biomass

• Combustible dust hazards.
• Solid fuel transfer system fire hazards (rubber
  belt conveyors).
• Potential incompatibility of some biomass fuels
  with heating design (switch-grass and stoker
  boilers).
• Introduces industrial process hazards into
  non-industrial facilities

30
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biomass

• Biomass New Technology for Non-Industrial
  Locations - Two small hospitals in northern
  Quebec (La Sarre and Macamic), modified their
  multi-fuel steam boilers to accept solid fuels
  (wood chips). The solid fuel is located 30-ft
  below grade to prevent freezing.
• New Hazards - Dust Hazards Fuel Burner Control
  Hazards Fuel Transfer System Hazards.

31
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biodiesel

• Long Term Storage Technology Not Developed.
• Possible fuel corrosion issues.
• Biodiesel is a flammable liquid ( FM Global
  definition of flammable liquid is any liquid with
  a Fire Point.)

32
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biodiesel
Biodiesel production in High schools???????
This is a chemical plant operation.
33
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biodiesel
Personal Biodiesel Production
Industrial Biodiesel Pilot Plant
34
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biodiesel
North Dakota plant destroyed by fire posted Sept.
8, 2008 at 314 p.m. CST A recent fire at
All-American Biodiesel's plant in York, N.D.,
destroyed a quarter of the business and has
brought to light a dangerous situation that could
be repeated in rural communities throughout the
United States. About three years ago, the
towns former school house was purchased by
All-American Biodiesel with the intent of
converting it to a 5 MMgy soy/canola-based
biodiesel production facility. Randy Silliman,
mayor of York, saw the potential hazards and
argued for the plants location to be denied. I
just thought that it needed to be farther than 50
feet from businesses and residents. Silliman
said the state fire code allows industrial
businesses to operate just 50 feet from private
residences. Unless towns pass zoning regulations
or ordinances, there is nothing preventing
businesses that use hazardous chemicals from
operating within city limits. According to
Silliman, most small towns, including York, dont
have regulations because we trust everybody.
35
It Isnt Easy Being Green
Renewable (Opportunity) Fuels - Biodiesel

• Biodiesel and methanol are flammable liquids and
  need to be protected as such.
• Basic flammable liquid protection includes
• Detached structure - Minimum 1-hour rated cutoff
  construction and full room floor liquid
  containment.
• Wet pipe automatic sprinkler protection.
• Steel piping systems/fittings for flammable
  liquid transfer.
• Automatic fire actuated shutoff systems.
• Positive displacement pumps.
• Steel tanks to API or U.L. Requirements.
• Proper Ventilation, Electrical,
  Bonding/Grounding.
• Design to FM Global Standards.

36
It Isnt Easy Being Green
EIFS Gives Green Building a Boost
Dryvit Outsulation Systems - As Green as it Gets
SAVING ENERGY OUTWEIGHS ALL OTHER MEASURES OF
GREEN BUILDING. EIFS SAVE MORE ENERGY THAN BRICK,
STUCCO, CONCRETE BLOCK FIBER CEMENT
SIDING. EIFS INDUSTRY MEMBERS ASSOCIATION
37
It Isnt Easy Being Green
38
It Isnt Easy Being Green
How can FM Global Help You Today?
39
It Isnt Easy Being Green
Managing Green Technologies
MANAGING CHANGE
Involve FM Global in the Idea Stage
40
It Isnt Easy Being Green
Managing Green Technologies
Built to Code vs. Built to Last
41
It Isnt Easy Being Green
FM Global has Built to Last Standards
Available Free On-Line at http//www.fmglobal.com/
42
It Isnt Easy Being Green
FM Global has In-House Resources
Research
FM Approvals
Engineering Standards
Field Engineering
43
It Isnt Easy Being Green
FM Global is Actively Involved with Industry
International Codes Standards Group
Participation in NFPA Committees
Membership in Professional Organizations SFPE,
ASME, TAPPI, National Board
44
It Isnt Easy Being Green
Whats Next?

• Probably more Government Environmental
  Regulations (Emissions Water Conservation)

• Likely more recycled plastics in construction

• Likely more Renewable Fuel Sources

• New Green Building designs

45
It Isnt Easy Being Green
Whats Next?
Coming in 2009 - This green roof will be the
largest in Canada when complete. It's the roof of
the Vancouver Convention and Exhibition Centre.
Besides the multi-hectare intensive green roof,
it will have energy efficient lighting and
electrical systems, an on-site desalinization
system, and a grey-water treatment that will
provide irrigation for the green roof. The
footings for the load-bearing piles have been
designed to support marine life.
Vancouver Convention and Exhibition Center
46
It Isnt Easy Being Green
Whats Next?
http//www.dynamicarchitecture.net/home.html

• Dynamic Architecture Designs Wind Power High Rise

47
It Isnt Easy Being Green
Whats Next?
The Continued Commitment by FM Global to Find
Solutions and Options for our Clients.
48
It Isnt Easy Being Green
QUESTIONS?
