A View of the Cell

1
Chapter 8

• A View of the Cell

2
Cell History

• The microscope was invented in the 17th century
• Using a microscope, Robert Hooke discovered cells
  in 1665
• All living things are made of cells (cell theory)

3
Cell Theory

• All cells come from preexisting cells
• The cell is the basic unit of organization of
  organisms.
• All organisms are made up of one or more cells.

4

• The light microscope enables us to see the
  overall shape and structure of a cell

Image seen by viewer
Eyepiece
Ocularlens
Objective lens
Specimen
Condenser lens
Light source
5

• Electron microscopes were invented in the 1950s

• They use a beam of electrons instead of light
• The greater resolving power of electron
  microscopes
• allows greater magnification
• reveals cellular details

6

• Scanning electron microscope (SEM)

• Scanning electron micrograph of cilia

7

• Transmission electron microscope (TEM)

• Transmission electron micrograph of cilia

8
Cell sizes vary with their function

• Below is a list of the most common units of
  length biologists use (metric)

9

• Cell size and shape relate to function

10
Cell Types

• There are two kinds of cells prokaryotic and
  eukaryotic
• Prokaryotic cells are small, relatively simple
  cells
• They do not have a nucleus

11

• A prokaryotic cell is enclosed by a plasma
  membrane and is usually encased in a rigid cell
  wall

• The cell wall may be covered by a sticky capsule

Prokaryoticflagella
Ribosomes
Capsule
Cell wall
Plasma membrane

• Inside the cell are its DNA and other parts

Nucleoid region(DNA)
Pili
12
Eukaryotic cells are partitioned into functional
compartments

• All other life forms are made up of one or more
  eukaryotic cells
• These are larger and more complex than
  prokaryotic cells
• Eukaryotes are distinguished by the presence of a
  true nucleus

13

• An animal cell

Smooth endoplasmicreticulum
Nucleus
Roughendoplasmicreticulum
Flagellum
Not in most plant cells
Lysosome
Centriole
Ribosomes
Peroxisome
Golgiapparatus
Microtubule
Plasma membrane
Cytoskeleton
Intermediatefilament
Mitochondrion
Microfilament
14

• The plasma membrane controls the cells contact
  with the environment

• The cytoplasm contains organelles
• Many organelles have membranes as boundaries
• These compartmentalize the interior of the cell
• This allows the cell to carry out a variety of
  activities simultaneously

15

• A plant cell has some structures that an animal
  cell lacks

• Chloroplasts
• A rigid cell wall

16
Roughendoplasmicreticulum
Nucleus
Ribosomes
Smoothendoplasmicreticulum
Golgiapparatus
Microtubule
Centralvacuole
Not inanimalcells
Cytoskeleton
Intermediatefilament
Chloroplast
Microfilament
Cell wall
Mitochondrion
Peroxisome
Plasma membrane
17
The nucleus is the cells genetic control center

• The largest organelle is usually the nucleus
• The nucleus is separated from the cytoplasm by
  the nuclear envelope
• The nucleus is the cellular control center
• It contains the DNA that directs the cells
  activities

18
NUCLEUS
Chromatin
Two membranesof nuclearenvelope
Nucleolus
Pore
ROUGHENDOPLASMICRETICULUM
Ribosomes
19

• The endomembrane system is a collection of
  membranous organelles
• These organelles manufacture and distribute cell
  products
• The endomembrane system divides the cell into
  compartments
• Endoplasmic reticulum (ER) is part of the
  endomembrane system

20
Rough endoplasmic reticulum makes membrane and
proteins

• The rough ER manufactures membranes
• Ribosomes on its surface produce proteins

21

• Smooth ER synthesizes lipids
• In some cells, it regulates carbohydrate
  metabolism and breaks down toxins and drugs

22
SMOOTH ER
ROUGHER
Nuclearenvelope
Ribosomes
SMOOTH ER
ROUGH ER
23

• The Golgi apparatus consists of stacks of
  membranous sacs
• These receive and modify ER products, then send
  them on to other organelles or to the cell
  membrane

24

• The Golgi apparatus

Golgi apparatus
Golgiapparatus
Receiving side ofGolgi apparatus
Transportvesiclefrom ER
Newvesicleforming
Shippingside of Golgiapparatus
Transport vesiclefrom the Golgi
25
Lysosomes digest the cells food and wastes
LYSOSOME

• Lysosomes are sacs of digestive enzymes budded
  off the Golgi

Nucleus
26

• Lysosomal enzymes

• digest food
• destroy bacteria
• recycle damaged organelles
• function in embryonic development in animals

27
Rough ER
Transport vesicle(containing inactivehydrolytic
enzymes)
Plasmamembrane
Golgiapparatus
Engulfmentof particle
Lysosomeengulfingdamagedorganelle
Food
LYSOSOMES
Digestion
Foodvacuole
28

• Plant cells contain a large central vacuole
• The vacuole has lysosomal and storage functions

Centralvacuole
Nucleus
29

• Protists may have contractile vacuoles

• These pump out excess water

30
ENERGY-CONVERTING ORGANELLES

• Chloroplasts are found in plants and some
  protists
• Chloroplasts convert solar energy to chemical
  energy in sugars

Chloroplast
Stroma
Inner and outer membranes
Granum
Intermembranespace
31

• Mitochondria carry out cellular respiration

MITOCHONDRION
Outermembrane
Intermembranespace

• This process uses the chemical energy in food to
  make ATP for cellular work

Innermembrane
Cristae
Matrix

32
THE CYTOSKELETON AND RELATED STRUCTURES
The cells internal skeleton helps organize its
structure and activities

• A network of protein fibers makes up the
  cytoskeleton

33

• Microfilaments of actin enable cells to change
  shape and move

• Intermediate filaments reinforce the cell and
  anchor certain organelles
• Microtubules
• give the cell rigidity
• provide anchors for organelles
• act as tracks for organelle movement
