Temple University

1
Temple University CIS Dept. CIS661 Principles
of Data Management

• V. Megalooikonomou
• Query Optimization
• (based on slides by C. Faloutsos at CMU)

2
General Overview - rel. model

• Relational model - SQL
• Functional Dependencies Normalization
• Physical Design
• Indexing
• Query optimization
• Transaction processing

3
Overview of a DBMS
casual user
Naïve user
DBA
DML parser
DDL parser
DML precomp.
trans. mgr
buffer mgr
4
Overview - detailed

• Why q-opt?
• Equivalence of expressions
• Cost estimation
• Cost of indices
• Join strategies

5
Why Q-opt?

• SQL declarative
• good q-opt -gt big difference
• eg., seq. Scan vs B-tree index, on P1,000 pages

6
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alternative plans
• estimate cost pick best

7
Q-opt - example
Canonical form
p
select name from STUDENT, TAKES where
c-idCIS661 and STUDENT.ssnTAKES.ssn
s
STUDENT
TAKES
8
Q-opt - example
Hash join merge join nested loops
Index seq. scan
9
Overview - detailed

• Why q-opt?
• Equivalence of expressions
• Cost estimation
• Cost of indices
• Join strategies

10
Equivalence of expressions

• A.k.a. syntactic q-opt
• In short perform selections and projections
  early
• More details
• see transformation rules in text

11
Equivalence of expressions

• Q How to prove a transformation rule?
• A use TRC, to show that LHS RHS, e.g.

12
Equivalence of expressions
13
Equivalence of expressions
14
Equivalence of expressions

• Q how to disprove a rule??

15
Equivalence of expressions

• Selections
• perform them early
• break a complex predicate, and push
• simplify a complex predicate
• (XY and Y3) -gt X3 and Y3

16
Equivalence of expressions

• Projections
• perform them early (but carefully)
• Smaller tuples
• Fewer tuples (if duplicates are eliminated)
• project out all attributes except the ones
  requested or required (e.g., joining attr.)

17
Equivalence of expressions

• Joins
• Commutative , associative
• Q n-way join - how many diff. orderings?
  Exhaustive enumeration too slow

18
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• estimate cost pick best

19
Cost estimation

• Eg., find ssns of students with an A in CIS661
  (using seq. scanning)
• How long will a query take?
• CPU (but small cost decreasing tough to
  estimate)
• Disk (mainly, block transfers)
• How many tuples will qualify?
• (what statistics do we need to keep?)

20
Cost estimation

• Statistics for each relation r we keep
• nr tuples
• Sr size of tuple in bytes

21
Cost estimation
Sr

• Statistics for each relation r we keep
• V(A,r) number of distinct values of attr. A
• (recently, histograms, too)

1
2
3

nr
22
Derivable statistics

• fr blocking factor max records/block (??
  )
• br blocks (?? )
• SC(A,r) selection cardinality avg of records
  with Agiven (?? )

23
Derivable statistics

• fr blocking factor max records/block ( B/Sr
  B block size in bytes)
• br blocks ( nr / fr )

24
Derivable statistics

• SC(A,r) selection cardinality avg of records
  with Agiven ( nr / V(A,r) ) (assumes
  uniformity...) eg 30,000 students, 10 colleges
  how many students in CST?

25
Additional quantities we need

• For index i
• fi average fanout - degree (50-100)
• HTi levels of index i (2-3)
• log(entries)/log(fi)
• LBi blocks at leaf level

HTi
26
Statistics

• Where do we store them?
• How often do we update them?

27
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections sorting projections
• joins
• estimate cost pick best

28
Cost estimation plan generation

• Selections eg.,
• select
• from TAKES
• where grade A
• Plans?

29
Cost estimation plan generation

• Plans?
• seq. scan
• binary search
• (if sorted consecutive)
• index search
• if an index exists

30
Cost estimation plan generation

• seq. scan cost?
• br (worst case)
• br/2 (average, if we search for primary key)

31
Cost estimation plan generation

• binary search cost?
• if sorted and consecutive
• log(br)
• SC(A,r)/fr (blocks spanned by qualified tuples)
• -1

32
Cost estimation plan generation

• estimation of selection cardinalities SC(A,r)
• non-trivial details later

33
Cost estimation plan generation

• method3 index cost?
• levels of index
• blocks w/ qual. tuples

...
case1 primary key case2 sec. key clustering
index case3 sec. key non-clust. index
34
Cost estimation plan generation

• method3 index cost?
• levels of index
• blocks w/ qual. tuples

..
case1 primary key cost HTi 1
35
Cost estimation plan generation
Sr

• method3 index - cost?
• levels of index
• blocks w/ qual. tuples

1
fr
2
case2 sec. key clustering index OR prim.
index on non-key retrieve multiple records HTi
SC(A,r)/fr

br
36
Cost estimation plan generation

• method3 index cost?
• levels of index
• blocks w/ qual. tuples

...
case3 sec. key non-clust. index HTi
SC(A,r) (actually, pessimistic...)
37
Cost estimation arithmetic examples

• find accounts with branch-name Perryridge
• account(branch-name, balance, ...)

38
Arithm. examples contd

• n-account 10,000 tuples
• f-account 20 tuples/block
• V(balance, account) 500 distinct values
• V(branch-name, account) 50 distinct values
• for branch-index fanout fi 20

39
Arithm. examples

• Q1 cost of seq. scan?
• A1 500 disk accesses
• Q2 assume a clustering index on branch-name
  cost?

40
Cost estimation plan generation
Sr

• method3 index cost?
• levels of index
• blocks w/ qual. tuples

1
fr
2
case2 sec. key clustering index HTi
SC(A,r)/fr

br
41
Arithm. examples

• A2
• HTi
• SC(branch-name, account)/f-account
• HTi 50 values, with index fanout 20 -gt HT2
  levels (log(50)/log(20) 1)
• SC(..) qualified records
• nr/V(A,r) 10,000/50 200 tuples
• SC/f spanning 200/20 blocks 10 blocks

42
Arithm. examples

• A2 final answer 210 12 block accesses
• (vs. 500 block accesses of seq. scan)
• footnote in all fairness
• seq. disk accesses 2msec or less
• random disk accesses 10msec

43
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alternative plans
• selections sorting projections
• joins
• estimate cost pick best

44
Examples

• (selection) find student record with ssn123

45
Reminder our Mini-U db
46
DML - nested subqueries

• Drill find the ssn of the student with the
  highest GPA

47
File organization

• Eg., Student records how would you store them
  on disk?

48
General Overview - rel. model

• Relational model - SQL
• Functional Dependencies Normalization
• Physical Design
• Indexing
• Query optimization
• Transaction processing

49
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections (simple complex predicates)
• sorting projections
• joins
• estimate cost pick best

50
Reminder statistics

• for each relation r we keep
• nr tuples
• Sr size of tuple in bytes
• V(A,r) number of distinct values of attr. A
• fr blocking factor
• br number of blocks
• SC(A,r) selection cardinality (avg. of records
  with Agiven)

51
Selections

• we saw simple predicates (Aconstant eg.,
  nameSmith)
• how about more complex predicates, like
• salary gt 10K
• age 30 and job-codeanalyst
• what is their selectivity?

52
Selections complex predicates

• selectivity sel(P) of predicate P
• fraction of tuples that qualify
• sel(P) SC(P) nr

53
Selections complex predicates

• eg., assume that V(grade, TAKES)5 distinct
  values
• simple predicate P Aconstant
• sel(Aconstant) 1/V(A,r)
• eg., sel(gradeB) 1/5
• (what if V(A,r) is unknown??)

54
Selections complex predicates

• range query sel( grade gt C)
• sel(Agta) (Amax a) / (Amax Amin)

55
Selections - complex predicates

• negation sel( grade ! C)
• sel( not P) 1 sel(P)
• (Observation selectivity probability)

P
56
Selections complex predicates

• conjunction
• sel( grade C and course CIS661)
• sel(P1 and P2) sel(P1) sel(P2)
• INDEPENDENCE ASSUMPTION

57
Selections complex predicates

• disjunction
• sel( grade C or course CIS661)
• sel(P1 or P2) sel(P1) sel(P2) sel(P1 and
  P2)
• sel(P1) sel(P2) sel(P1)sel(P2)
• INDEPENDENCE ASSUMPTION, again

58
Selections complex predicates

• disjunction in general
• sel(P1 or P2 or Pn)
• 1 - (1- sel(P1) ) (1 - sel(P2) ) (1 -
  sel(Pn))

59
Selections summary

• sel(Aconstant) 1/V(A,r)
• sel( Agta) (Amax a) / (Amax Amin)
• sel(not P) 1 sel(P)
• sel(P1 and P2) sel(P1) sel(P2)
• sel(P1 or P2) sel(P1) sel(P2)
  sel(P1)sel(P2)
• UNIFORMITY and INDEPENDENCE ASSUMPTIONS

60
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections (simple complex predicates)
• sorting projections
• joins
• estimate cost pick best

61
Sorting

• Assume br blocks of rel. r, and
• only M (ltbr) buffers in main memory
• Q1 how to sort (external sorting)?
• Q2 cost?

62
Sorting

• Q1 how to sort (external sorting)?
• A1
• create sorted runs of size M
• merge

63
Sorting

• create sorted runs of size M (how many?)
• merge them (how?)

M
...
...
64
Sorting

• create sorted runs of size M
• merge first M-1 runs into a sorted run of
• (M-1) M, ...

M
..
...
...
65
Sorting

• How many steps we need to do?
• i, where M(M-1)i gt br
• How many reads/writes per step? brbr
• (each step reads every block once and writes it
  once)

M
..
...
...
66
Sorting

• In short, excluding the final write, we need
• ceil(log(br/M) / log(M-1)) 2 br br

M
..
...
...
67
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections (simple complex predicates)
• sorting projections, aggregations
• joins
• estimate cost pick best

68
Projection - dupl. elimination

• eg.,
• select distinct c-id
• from TAKES
• How?
• Pros and cons?

69
Set operations

• eg.,
• select from REGULAR-STUDENT
• union
• select from SPECIAL-STUDENT
• How?
• Pros and cons?

70
Aggregations

• eg.,
• select ssn, avg(grade)
• from TAKES
• How?

71
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections sorting projections, aggregations
• joins
• 2-way joins
• n-way joins
• estimate cost pick best

72
2-way joins

• output size estimation r JOIN s
• nr, ns tuples each
• case1 cartesian product (R, S have no common
  attribute)
• of output tuples??

73
2-way joins

• output size estimation r JOIN s
• case2 r(A,B), s(A,C,D), A is cand. key for r
• of output tuples??

ltns
r(A, ...)
s(A, ......)
nr
ns
74
2-way joins

• output size estimation r JOIN s
• case3 r(A,B), s(A,C,D), A is cand. key for
  neither (is it possible??)
• of output tuples??

r(A, ...)
s(A, ......)
nr
ns
75
2-way joins

• of output tuples
• nr ns/V(A,s) or ns nr/V(A,r)
• (whichever is less)

76
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections sorting projections, aggregations
• joins
• 2-way joins - output size estimation algorithms
• n-way joins
• estimate cost pick best

77
2-way joins

• algorithm(s) for r JOIN s?
• nr, ns tuples each

78
2-way joins

• Algorithm 0 (naive) nested loop (SLOW!)
• for each tuple tr of r
• for each tuple ts of s
• print, if they match

79
2-way joins

• Algorithm 0 why is it bad?
• how many disk accesses (br and bs are the
  number of blocks for r and s)?

nrbs br
80
2-way joins

• Algorithm 1 Blocked nested-loop join
• read in a block of r
• read in a block of s
• print matching tuples

cost br br bs
r(A, ...)
s(A, ......)
nr, br
ns records, bs blocks
81
2-way joins

• Arithmetic example
• nr 10,000 tuples, br 1,000 blocks
• ns 1,000 tuples, bs 200 blocks

alg0 2,001,000 d.a. alg1 201,000 d.a.
r(A, ...)
s(A, ......)
10,000 1,000
1,000 records, 200 blocks
82
2-way joins

• Observation1 Algo1 asymmetric
• cost br br bs - reverse roles
• cost bs bsbr
• Best choice?

smallest relation in outer loop
r(A, ...)
s(A, ......)
nr, br
ns records, bs blocks
83
2-way joins

• Observation2 NOT IN BOOK
• what if we have k buffers available?

read in k-1 blocks of r read in a block
of s print matching tuples
r(A, ...)
s(A, ......)
nr, br
ns records, bs blocks
84
2-way joins

• Cost?

br br/(k-1) bs
read in k-1 blocks of r read in a block
of s print matching tuples
what if brk-1? what if we assign k-1 blocks to
inner?)
r(A, ...)
s(A, ......)
nr, br
ns records, bs blocks
85
2-way joins

• Observation3 can we get rid of the br term?
• cost br br bs

A read the inner relation backwards half of the
times! Q cons?
r(A, ...)
s(A, ......)
nr, br
ns records, bs blocks
86
2-way joins

• Other algorithm(s) for r JOIN s?
• nr, ns tuples each

87
2-way joins - other algos

• sort-merge
• sort r sort s merge sorted versions
• (good, if one or both are already sorted)

88
2-way joins - other algos

• sort-merge - cost
• 2 br log(br) 2 bs log(bs) br bs
• needs temporary space (for sorted versions)
• gives output in sorted order

89
2-way joins - other algos

• use an existing index, or even build one on the
  fly
• cost br nr c (c look-up cost)

r(A, ...)
nr
90
2-way joins - other algos

• hash join
• hash r into (0, 1, ..., max) buckets
• hash s into buckets (same hash function)
• join each pair of matching buckets

r(A, ...)
0
1
max
91
2-way joins - hash join details

• how to join each pair of partitions Hr-i, Hs-i ?
• A build another hash table for Hs-i, and probe
  (look up) it with each tuple of Hr-i

Hr-0
Hs-0
r(A, ...)
0
1
max
92
2-way joins - hash join details

• what if Hs-i is too large to fit in main-memory?
• A recursive partitioning
• more details (overflows, hybrid hash joins) in
  book
• cost of hash join? (under certain assumptions)
• 2(br bs) (br bs) 4 max

93
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections sorting projections, aggregations
• joins
• 2-way joins - output size estimation algorithms
• n-way joins
• estimate cost pick best

94
n-way joins

• r1 JOIN r2 JOIN ... JOIN rn
• typically, break problem into 2-way joins

95
Structure of query optimizers

• System R
• break query in query blocks
• simple queries (ie., no joins) look at stats
• n-way joins left-deep join trees ie., only one
  intermediate result at a time
• pros smaller search space pipelining
• cons may miss optimal
• 2-way joins nested-loop and sort-merge

96
Structure of query optimizers

• More heuristics by Oracle, Sybase and Starburst
  (-gt DB2) in book
• In general q-opt is very important for large
  databases.
• (explain select ltsql-statementgt gives plan)

97
Q-opt steps

• bring query in internal form (eg., parse tree)
• into canonical form (syntactic q-opt)
• generate alt. plans
• selections (simple complex predicates)
• sorting projections
• joins
• estimate cost pick best
