Cellular Metabolism

1
Lecture 3

• Cellular Metabolism
• Kinetics

2
Please join the UT BME Department for the
worldwide movie premiere of the BME377
Internship Documentary

• Come celebrate the achievements of our
  spectacular BME undergraduates - the stars of
  this years summer internship at The Texas
  Medical Center!

Date Sept. 15, 2004 Place ACES room 2.302
Time 5 oclock
Come see how a summer can change your life!
Be among the first to screen the BME 377
documentary! Enjoy BME377 student posters. A
reception will follow the screening. Refreshments
provided. More info and the movie (after 9/15)
are available at http//www.engr.utexas.edu/bme
/faculty/richards-kortum/BME377/mission/mission.ht
m
3
Review of Lecture 2

• Introduction to Modeling
• Review of Electric Circuits

4
Outline

• Biochemical reactions
• Enzymes and enzyme kinetics
• Cell metabolism and ATP production
• Synthetic pathways

5
Outline

• Biochemical reactions
• Equilibrium concentrations
• Biochemical energetics
• ATP
• Oxidation-Reduction reactions
• Enzymes and enzyme kinetics
• Cell metabolism and ATP production
• Synthetic pathways

6
Biochemical Reactions

• Metabolism
• Collection of chemical reactions in the body
• These reactions
• Extract energy from nutrient biomolecules
• Synthesize or break down molecules
• Catabolism
• Produce energy by breaking down large
  biomolecules
• Anabolism
• Consume energy by synthesizing large biomolecules

7
Fig 4.4 Exergonic and endergonic
reactions Silverthorn 2nd Ed
8
Metabolism

• Highly coordinated process
• Consists of a series of pathways
• Each step in the pathway is an enzymatically
  controlled reaction
• Many metabolic pathways couple
• exergonic reactions that release energy
• with endergonic reactions that consume energy

9
Fig 4.21 Overview of aerobic pathways for ATP
production Silverthorn 2nd Ed
10
Equilibrium Concentrations

• Law of mass action
• Rate of reaction
• rate of product formation
• dC/dt
• Rx rate collisions between reactants per
  unit time x probability that collision is
  energetic enough to overcome activation energy
• dC/dt ABk
• Useful model much like Ohms law

11
Mass Action

• Reaction can proceed in both directions
• dA/dt k-C - kAB
• At equilibrium
• dA/dt 0
• Ceq (k/k-)AeqBeq
• Ceq (1/Keq)AeqBeq

12
Mass Action

• If no other reactions are taking place
• A C Ao constant
• At equilibrium
• Ceq (1/Keq)AeqBeq
• Ceq AoBeq/(KeqBeq)

13
Biochemical Energetics

• ATP
• ATP serves as carrier of energy
• Complex biomolecules serve as energy reservoirs
• ATP H20 ? ADP Pi H energy
• 3 phosphates have negative charge
• Requires energy to overcome Coulombic repulsion
• 7-12 kCal/mole of ATP

14
Biochemical Energetics

• Oxidation Reduction reactions
• NADH H 1/2O2 ? NAD H20 energy
• Reduced form ? Oxidized form energy
• 52 kCal/mole
• FADH2 1/2O2 ? FAD2 H20 energy
• Reduced form ? Oxidized form energy

15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Control of Metabolism

• Five ways cells regulate metabolism
• Control enzyme concentration
• Produce allosteric and covalent modulators
• Use two different enzymes to catalyze reversible
  reactions
• Isolate enzymes within intracellular organelles
• Maintain an optimum ratio of ATP to ADP

19
Outline

• Biochemical reactions
• Enzymes and enzyme kinetics
• Enzymes as catalysts
• Enzyme kinetics
• Enzyme inhibition
• Cell metabolism and ATP production
• Synthetic pathways

20
Enzymes

• Biological catalysts
• Speed up reaction rate, but are not changed in
  reaction
• Enzyme increases rate by decreasing activation
  energy
• Reaction rate
• 1 molecule/100s without enzyme
• 106 molecules/s with enzyme

21
Fig 4.7 Enzymes lower the activation energy of
reactions Silverthorn 2nd Ed
22
Enzymes

• Most enzymes are
• large proteins
• complex 3D shapes
• Small region known as active site
• binds substrates
• brings them close enough to react

23
Fig 4.8 Enzymes bind substrate at the binding
site Silverthorn 2nd Ed
24
Enzymes

• Nomenclature
• Most have ase at the end
• Prefix refers to type of reaction or substrate
• Factors affecting enzyme activity
• Some must be activated
• Some require cofactor binding
• Modulators alter enzyme activity
• Competitive inhibitors
• Allosteric modulators

25
Fig 4.9 Silverthorn 2nd Ed
26
Fig 4.10 Silverthorn 2nd Ed
27
Fig 4.13 Competitive inhibition Silverthorn
2nd Ed
28
Fig 4.14 Allosteric inhibition Silverthorn
2nd Ed
29
Enzyme Kinetics

• Law of mass action
• One step reactions
• Most enzymatically catalyzed rxs dont follow
• Michaelis Menten kinetics
• Multi-step reaction
• Substrate and enzyme form complex? breaks down
  into product and enzyme

30
Michaelis Menten Kinetics

• Equilibrium approximation
• Substrate is in instantaneous equilibrium with
  complex
• Reaction rate
• Linear at low substrate concentrations
• Saturates at high concentrations
• VmaxeoK2, Rx limited by amount of enzyme and K2

31
Briggs Haldane Kinetics

• Quasi- steady state approximation
• Rates of formation and breakdown of complex are
  equal at all times (except at very beginning)
• Reaction rate
• Same form as Michaelis Menten
• VmaxeoK2, Rx limited by amount of enzyme and K2

32
Michaelis Menten Eq. App.
33
Enzymatic Control of Reactions

• Cofactor activation
• Cofactor binding required for enzyme to be active
• Competitive Inhibition
• Reaction stops when inhibitor binds to enzyme
• Allosteric Inhibition
• Inhibitor binds at an allosteric site
• Decreases maximal reaction rate

34
Fig 4.10 Silverthorn 2nd Ed
35
Fig 4.13 Competitive inhibition Silverthorn
2nd Ed
36
Competitive Inhibition
37
Fig 4.14 Allosteric inhibition Silverthorn
2nd Ed
38
Outline

• Biochemical reactions
• Enzymes and enzyme kinetics
• Cell metabolism and ATP production
• Glycolysis
• Energy yield per glucose molecule
• Synthetic pathways

39
ATP Production

• ATP transfers energy between rxs
• Characterize a metabolic pathway in terms of net
  yield of ATP
• ATP Production
• Aerobic pathways
• Require oxygen
• Yields most ATP
• Anaerobic pathways
• Dont require oxygen
• Yield less ATP

40
Aerobic Pathways

• Input
• Carbohydrates (eg glucose)
• Proteins (amino acids)
• Lipids (Fatty acids)
• Output
• High energy electrons carried by NADH, FADH2
• ATP
• Overall
• C6H12O6 6O2 ? 6 CO2 6 H2O energy
• 30-32 ATP/glucose
• Common steps
• Glycolysis (occurs in cytosol)
• Citric acid cycle (occurs in mitochondria)
• Electron transport (mitochondria)

41
Fig 4.21 Overview of aerobic pathways for ATP
production Silverthorn 2nd Ed
42
Glycolysis

• Summary
• Glucose 2NAD 2ADP 2Pi ? 2 pyruvate 2 ATP
  2 NADH 2H 2 H2O
• Does not require oxygen
• Yields pyruvate in anaerobic process
• Then
• If low oxygen converts to lactate
• If sufficient oxygen pyruvate enters citric
  acid cycle

43
Fig 4.22 - Glycolysis Silverthorn 2nd Ed
44
Citric Acid Cycle

• Summary
• Pyruvate transported from cytosol to mitochondria
• Pyruvate converted to acetyl coA which enters
  citric acid cycle
• Yield
• 1 ATP
• 3 NADH, 1 FADH2 ? transfer their high energy
  electrons to ATP in electron transfer chain

45
Fig 4.23 Pyruvate metabolism Silverthorn
2nd Ed
46
Fig 4.24 The citric acid cycle Silverthorn
2nd Ed
47
Electron Transport Chain

• Oxidative phosphorylation
• Occurs in mitochondrial membrane
• Facilitated by mitochondrial proteins
• High energy electrons pass through e- transport
  chain
• Their energy is used to transport H from
  mitochondrial matrix to intermembrane space
• Energy stored in concentration gradient, then
  transferred to ATP as H moves back across
  membrane

48
Fig 4.25 The electron transport system and ATP
synthesis Silverthorn 2nd Ed
49
Net Energetics
50
Outline

• Biochemical reactions
• Enzymes and enzyme kinetics
• Cell metabolism and ATP production
• Synthetic pathways
• Lipid synthesis
• Protein synthesis

51
Fig 4.21 Overview of aerobic pathways for ATP
production Silverthorn 2nd Ed
52
Fig 4.26 Glycogen catabolism Silverthorn
2nd Ed
53
Fig 4.27 Protein catabolism Silverthorn 2nd
Ed
54
Fig 4.28 - Lipolysis Silverthorn 2nd Ed
55
Summary

• Biochemical reactions
• Enzymes and enzyme kinetics
• Cell metabolism and ATP production
• Synthetic pathways

56
Poem of the Day

• Billy Collins
• Former US Poet Laureate (2001-03)
• New York State Poet Laureate (2004-06)
• Professor of English, Lehman College, CCNY
• Another Reason Why I Dont Keep a Gun in the
  House

57
Due Dates

• Tuesday, September 7th
• Homework 2
