CMAQ Chemical Transport Modeling System CCTM

1
CMAQ Chemical Transport Modeling System (CCTM)

• Gail Tonnesen, Zion Wang
• UCR Regional Modeling Center Training
• January 17, 2002

2
CCTM Overview

• CMAQ is a one atmosphere model
• Simulates O3, PM, Haze, acid deposition.
• Chemical Tracer Model (CCTM) simulates the
  following processes
• Advection, diffusion, and deposition,
• Gas phase chemistry,
• Particle dynamics, chemistry, and visibility,
• Plume-in-grid (PinG) modeling,
• Cloud processes,
• Photolysis rates, and
• Analysis tools.

3
CCTM - Coming Attractions

• Additional major extensions are planned
• A version of the SAPRC-97 gas phase mechanism
• A new emissions processor called the Sparse
  Matrix Operator Kernel Emissions modeling system
  (SMOKE)
• an advanced surface-PBL linked system
• optional meteorological processors such as the
  Regional Atmospheric Modeling System (RAMS)
• an advanced 4-D photolysis rates processor

4
CCTM Governing Equations

• Chemistry N coupled PDEs
• ?Cj ??t v.?Cj ? D?2Cj P ?LCj Ej ?Dj , j1,N
• Operator Splitting
• ?Cj ??t ? v.?Cj
• ?Cj ??t ??2Cj Ej ? Dj
• dCj ?dt P ? L Cj j1,N
• Gear solver is the gold standard for stiff ODEs

5

• Advective Transport ?Cj ??t ? v.?Cj
• ?Cj ??t ?vx ?Cj ??x
• ?Cj ??t ?vy ?Cj ??y
• ?Cj ??t ?vz ?Cj ??z
• Horizontal Diffusion ?Cj ??t ??2Cj
• ?Cj ??t ?x ?2Cj ??x2
• ?Cj ??t ? y ?2Cj ??y2

6
Operator Splitting (cont.)

• Vertical Dispersion with emissions
• ?Cj ??t ?z ?2Cj ??z2 Ej ? Dj
• Chemistry with emissions
• dCj ?dt P ? L Cj Emisj j1,N
• Example of loss frequency (L) for XYL
• L kOHXYL OH
• Loss Rate LXYL

7
Symmetrical Operator Splitting

• Attempt to Minimize operator splitting errors by
  using a symmetrical solution.
• For a Ten Minute Simulation Period
• Solve Transport and Dispersion terms for
  beginning 5 minutes.
• Solve Chemistry for 10 minutes.
• Solve Transport and Dispersion terms for ending
  5 minutes.

8
CCTM Modules

• Currently, nine science modules are included
• DRIVER controls model data flows and synchronizes
  fractional time steps
• HADV computes the effects of horizontal
  advection
• VADV computes the effects of vertical advection
• ADJCON adjusts mixing ratio conservation property
  of advection processes
• HDIFF computes the effects of horizontal
  diffusion
• VDIFF computes the effects of vertical diffusion
  and deposition

9
CCTM Science Modules (cont.)

• CHEM computes the effects of gas-phase chemical
  reactions
• CLOUD computes the effects of aqueous-phase
  reactions and cloud mixing
• AERO computes aerosol dynamics and size
  distributions and
• PING computes the effects of plume chemistry.

10
CCTM Science Module Choices
11
CCTM Science Module Choices (cont.)
12
CCTM Science Module Choices (cont.)
13
CCTM Driver Module and Science Processor Call
Sequence
14
CCTM - Nesting

• At present, CCTM allows only static grid nesting
• finer grids (FGs) are placed (i.e., nested)
  inside coarser grids (CGs)
• The resolution and the extent of each grid is
  determined a priori and remain fixed throughout
  the CTM simulation
• Static grid nesting conserves mass and preserves
  transport characteristics at the interfaces of
  grids with different resolutions
• It allows for effective interaction between
  different scales with efficient use of computing
  resources.

15
CCTM Nesting

• One-way nesting versus two-way nesting.

16
CCTM Multi-level Nesting
17
How to run CCTM?

• Verify that the CMAQ distribution tar file is
  downloaded from the RMC website
  httpwww.cert.ucr.edu/rmc/download
• Gunzip and untar the tar file.
• Go to the CCTM run scripts directory, modify and
  execute the bldit and run job scripts.
• bldit script users choose the compilation
  options and compiling the code.
• run script users modify the run-time options
  and executing the CCTM processor

18
How to run CCTM (cont.)

• Check the log file for possible compile and
  runtime errors.
• Sample error messages and solutions are included
  in the Users Guide under Why didnt CCTM work
  section.

19
Practice Session
