Chapter 4 Fundamentals Semantics of Programming Languages

1
Chapter 4Fundamentals (Semantics of
Programming Languages)
2
Outline

• Compilers A review
• Syntax specification
• BNF (EBNF)
• Semantics specification
• Static semantics
• Attribute grammar
• Dynamic semantics
• Operational semantics
• Denotational semantics
• Axiomatic semantics
• Lambda Calculus

3
References

• Concepts in Programming Languages by J. Mitchel
  textbook Chapter 4
• Programming Languages Principles and Paradigms
  by Allan Tucker and R. Noonan, Chapter 3
  Handout
• Concepts of Programming Languages by R.
  Sebesta, 6th Edition, Chapter 3.

4
Denotational Semantics

• Denotational semantics of a language defines the
  meanings of abstract language elements as a
  collection of environment- and state-transforming
  functions
• M Class ? ? ? ?
• ? Is the set of all program states ?
• Environment of a program is the set of objects
  and types that are active at each step during its
  execution
• State of a program is the set of all active
  objects and their current values.

5
Denotational Semantics

• Denotational semantics defines the meaning of a
  program as a series of state transformations
  resulting from the application of a series of
  functions M
• State-transforming functions individually define
  the meaning of every class of element that can
  occur in the programs abstract syntax tree like
  program, block, assignment, expression,
  conditional, loop, and others
• State-transforming functions are necessarily
  partial functions

6
Denotational Semantics

• Denotational semantics
• The meaning or denotation is associated with
  each program or program phrase like expression,
  statement, declaration, etc.
• Describe meaning of programs by specifying the
  mathematical
• Function
• Function on functions
• Value, such as natural numbers or strings
• defined for each construct

7
Motivation

• Precision
• Use mathematics instead of English
• Avoid details of specific machines
• Aim to capture pure meaning apart from
  implementation details
• Basis for program analysis
• Justify program proof methods
• Soundness of type system, control flow analysis
• Proof of compiler correctness
• Language comparisons

8
Basic Principle of Denotational Semantics

• Compositionality
• The meaning of a compound program must be
  defined from the meanings of its parts (not the
  syntax of its parts).
• Example
• P Q
• composition of two functions, state ?
  state
• Object language and metalanguage

9
Trivial Example Binary Numbers

• Syntax
• b ? 0 1
• n ? b nb
• e ? n ee
• Semantics value function E exp -gt numbers
• E 0 0
• E 1 1
• E nb 2E n E b
• E e1e2 E e1 E e2
• Obvious, but different from compiler evaluation
  using registers, etc.
• This is a simple machine-independent
  characterization ...

10
Second Example Expressions w/vars

• Syntax
• d ? 0 1 2 9
• n ? d nd
• e ? x n e e
• Semantics value E exp ? state ? numbers
• state s vars ?
  numbers
• E x s s(x)
• E 0 s 0
• E 1 s 1
• E nd s 10E n s E d s
• E e1 e2 s E e1 s E e2 s

11
Semantics of Imperative Programs

• Syntax
• P xe if B then P else P PP
  while B do P
• Semantics
• C Programs (State ? State)
• State (Variables ? Values)
• would be locations ? values if we wanted to
  model aliasing

Every imperative program can be translated into a
functional program in a relatively simple,
syntax-directed way.
12
Semantics of Assignment

• C x e
• is a function states ? states
• C x e s s
• where s variables ? values is identical to s
  except
• s(x) E e s gives the value of e in
  state s

13
Semantics of Conditional

• C if B then P else Q
• is a function states ? states
• C if B then P else Q s
• C P s if E B s is true
• C Q s if E B s is false
• Simplification assume B cannot diverge or have
  side effects

14
Semantics of Iteration

• C while B do P
• is a function states ? states
• C while B do P
• the function f such that
• f(s) s if E B s
  is false
• f(s) f( C P (s) ) if E B s
  is true

15
Denotational Semantics

• Using denotational semantics, the meaning of a
  program can be defined as
• M Program ? ?
• M (Program p) M (P.body, ltv1, undefgt, ltv2,
  undef gt, ltvn, undef gt
• Normally abstract definition of a program
  consists of two parts declaration and body
• Denotational semantics is straight forward to
  implement

16
Denotational Semantics

• State M (Program p)
• return M (p.body,initialState(p.decpart))
• State initialState (Declarations d)
• State sigma new State()
• Value undef new Value()
• for (int i 0 i lt d.size() i)
• sigma.put(((Declaration)(d.elementAt(i))).v,
  undef)
• return sigma

17
Denotational Semantics

• Some state-transforming functions
• Expression
• M expression ? state ? value
• M (expression e, state ?)
• e if e is a value
• ?(e) if e is a variable
• ApplyBinary (e.op, M(e.term1, ?), M(e.term2,
  ?) ) if e is a binary

18
Denotational Semantics

• Some state-transforming functions
• Conditional
• M conditional ? state ? state
• M (conditional c, state ?)
• M (c.thenpart, ?) if M (c.test, ?) is true
• M (c.elsepart, ?) if M (c.test, ?) is false

19
Operational vs Denotational Semantics

• The difference between denotational and
  operational semantics
• In operational semantics, the state changes are
  defined by coded algorithms
• In denotational semantics, they are defined by
  rigorous mathematical functions

20
Denotational Semantics of Expressions

• Me(ltexprgt, s) ?
• case ltexprgt of
• ltdec_numgt gt Mdec(ltdec_numgt, s)
• ltvargt gt
• if VARMAP(ltvargt, s) undef
• then error
• else VARMAP(ltvargt, s)
• ltbinary_exprgt gt
• if (Me(ltbinary_exprgt.ltleft_exprgt, s)
  undef
• OR Me(ltbinary_exprgt.ltright_exprgt,
  s)
• undef)
• then error
• else
• if (ltbinary_exprgt.ltoperatorgt then
• Me(ltbinary_exprgt.ltleft_exprgt, s)
• Me(ltbinary_exprgt.ltright_exprgt, s)
• else Me(ltbinary_exprgt.ltleft_exprgt, s)
• Me(ltbinary_exprgt.ltright_exprgt, s)
• ...

21
Denotational Semantics of Assignment Statement

• Assignment Statements
• Maps state sets to state sets
• Ma(x E, s) ?
• if Me(E, s) error
• then error
• else s lti1,v1gt,lti2,v2gt,...,ltin,vn
  gt,
• where for j 1, 2, ..., n,
• vj VARMAP(ij, s) if ij ltgt x
• Me(E, s) if ij x

22
Denotational Semantics of Loops

• Logical Pretest Loops
• Maps state sets to state sets
• Ml(while B do L, s) ?
• if Mb(B, s) undef
• then error
• else if Mb(B, s) false
• then s
• else if Msl(L, s) error
• then error
• else Ml(while B do L, Msl(L, s))

23
Denotational Semantics of Loops

• The meaning of the loop is the value of the
  program variables after the statements in the
  loop have been executed the prescribed number of
  times, assuming there have been no errors
• In essence, the loop has been converted from
  iteration to recursion, where the recursive
  control is mathematically defined by other
  recursive state mapping functions
• Recursion, when compared to iteration, is easier
  to describe with mathematical rigor

24
Evaluation of Denotational Semantics

• Evaluation of denotational semantics
• Can be used to prove the correctness of programs
• Provides a rigorous way to think about programs
• Can be an aid to language design
• Has been used in compiler generation systems
• Because of its complexity, they are of little use
  to language users
