Unix System Kernel

1
Unix System Kernel
Instructors Fu-Chiung Cheng (???) Associate
Professor Computer Science Engineering Tatung
Institute of Technology
2
Unix Introduction

• Operating System a system that manages the
  resources
• of a computer.
• Resources CPUs, Memory, I/O devices, Network
• Kernel the memory resident portion of Unix
  system
• File system and process control system are two
  major
• components of Unix Kernel.

3
Architecture of Unix System
emacs

• OS interacts directly with
• the hardware
• Such OS is called
• system kernel

sh
who
date
kernel
cpp
hardware
ed
as
cc
wc
ld
grep
nroff
Other apps
4
Unix System Kernel

• Three major tasks of kernel
• Process Management
• Device Management
• File Management
• Three additional Services for Kernel
• Virtual Memory
• Networking
• Network File Systems
• Experimental Kernel Features
• Multiprocessor support
• Lightweight process (thread) support

5
Block Diagram of System Kernel
User Programs
Libraries
User Level
Kernel Level
System Call Interface
File Subsystem
Inter-process communication
Process control subsystem
Scheduler
Device drivers
Memory management
hardware control
hardware
Hardware Level
6
Process Control Subsystem

• Process Synchronization
• Interprocess communication
• Memory management
• Scheduler process scheduling
• (allocate CPU to Processes)

7
File subsystem

• A file system is a collection of files and
  directories on
• a disk or tape in standard UNIX file system
  format.
• Kernels file sybsystem regulates data flow
  between
• the kernel and secondary storage devices.

8
Hardware Control

• Hardware control is responsible for handling
  interrupts
• and for communicating with the machine.
• Devices such as disks or terminals may interrupt
  the
• CPU while a process is executing.
• The kernel may resume execution of the
  interrupted
• process after servicing the interrupt.

9
Processes

• A program is an executable file.
• A process is an instance of the program in
  execution.
• For example create two active processes

emacs emacs ps PID TTY TIME
CMD 12893 pts/4 000 tcsh 12581 pts/4 001
emacs 12582 pts/4 001 emacs
10
Processes

• A process has
• text machine instructions
• (may be shared by other processes)
• data
• stack
• Process may execute either in user mode and in
  kernel
• mode.
• Process information are stored in two places
• Process table
• User table

11
User mode and Kernel mode

• At any given instant a computer running the Unix
  system
• is either executing a process or the kernel
  itself is running
• The computer is in user mode when it is
  executing
• instructions in a user process and it is in
  kernel mode
• when it is executing instructions in the
  kernel.
• Executing System call gt User mode to Kernel
  mode
• perform I/O operations
• system clock interrupt

12
Process Table

• Process table an entry in process table has the
  following
• information
• process state
• A. running in user mode or kernel mode
• B. Ready in memory or Ready but swapped
• C. Sleep in memory or sleep and swapped
• PID process id
• UID user id
• scheduling information
• signals that is sent to the process but not yet
  handled
• a pointer to per-process-region table
• There is a single process table for the entire
  system

13
User Table (u area)

• Each process has only one private user table.
• User table contains information that must be
  accessible
• while the process is in execution.
• A pointer to the process table slot
• parameters of the current system call, return
  values
• error codes
• file descriptors for all open files
• current directory and current root
• process and file size limits.
• User table is an extension of the process table.

14
Process table
Kernel address space
user address space
Active process
resident
swappable
Region table
text
u area
data
stack
Per-process region table
15
Shared Program Text and Software Libraries

• Many programs, such as shell, are often being
• executed by several users simultaneously.
• The text (program) part can be shared.
• In order to be shared, a program must be
  compiled using
• a special option that arranges the process
  image so that
• the variable part(data and stack) and the
  fixed part (text)
• are cleanly separated.
• An extension to the idea of sharing text is
  sharing
• libraries.
• Without shared libraries, all the executing
  programs
• contain their own copies.

16
Region table
Process table
text
data
stack
Active process
Reference count 2
text
data
stack
Per-process region table
17
System Call

• A process accesses system resources through
  system call.
• System call for
• Process Control
• fork create a new process
• wait allow a parent process to synchronize
  its
• execution with the exit of a child process.
• exec invoke a new program.
• exit terminate process execution
• File system
• File open, read, write, lseek, close
• inode chdir, chown chmod, stat fstat
• others pipe dup, mount, unmount, link,
  unlink

18
System call fork()

• fork the only way for a user to create a
  process in Unix
• operating system.
• The process that invokes fork is called parent
  process
• and the newly created process is called child
  process.
• The syntax of fork system call
• newpid fork()
• On return from fork system call, the two
  processes have
• identical copies of their user-level context
  except for the
• return value pid.
• In parent process, newpid child process id
• In child process, newpid 0

19
cc forkEx1.c -o forkEx1 forkEx1 Before
forking ... Child Process fpid0 After forking
fpid0 Parent Process fpid14707 After forking
fpid14707
/ forkEx1.c / include ltstdio.hgt main()
int fpid printf("Before forking ...\n")
fpid fork() if (fpid 0)
printf("Child Process fpidd\n", fpid)
else printf("Parent Process fpidd\n",
fpid) printf("After forking fpidd\n",
fpid)
20
forkEx2 Before forking ... PID TTY TIME
CMD 14759 pts/9 000 tcsh 14778 pts/9
000 sh 14777 pts/9 000 forkEx2 PID TTY
TIME CMD 14781 pts/9 000 sh 14759 pts/9
000 tcsh 14782 pts/9 000 sh 14780 pts/9
000 forkEx2 14777 pts/9 000 forkEx2 After
forking fpid14780 PID TTY TIME CMD
14781 pts/9 000 sh 14759 pts/9 000 tcsh
14780 pts/9 000 forkEx2 After forking fpid0
/ forkEx2.c / include ltstdio.hgt main()
int fpid printf("Before forking ...\n")
system("ps") fpid fork() system("ps")
printf("After forking fpidd\n", fpid)
ps PID TTY TIME CMD 14759 pts/9
000 tcsh
21
System Call getpid() getppid()

• Each process has a unique process id (PID).
• PID is an integer, typically in the range 0
  through 30000.
• Kernel assigns the PID when a new process is
  created.
• Processes can obtain their PID by calling
  getpid().
• Each process has a parent process and a
  corresponding
• parent process ID.
• Processes can obtain their parents PID by
  calling
• getppid().

22
/ pid.c / include ltstdio.hgt include
ltsys/types.hgt include ltunistd.hgt main()
printf("pidd ppidd\n",getpid(), getppid())
cc pid.c -o pid pid pid14935 ppid14759
23
/ forkEx3.c / include ltstdio.hgt include
ltsys/types.hgt include ltunistd.hgt main() int
fpid printf("Before forking ...\n") fpid
fork() if (fpid 0) printf("Child
Process fpidd pidd ppidd\n", fpid,
getpid(), getppid()) else
printf("Parent Process fpidd pidd ppidd\n",
fpid, getpid(), getppid())
printf("After forking fpidd pidd ppidd\n",
fpid, getpid(), getppid())
24
cc forkEx3.c -o forkEx3 forkEx3 Before
forking ... Parent Process fpid14942 pid14941
ppid14759 After forking fpid14942 pid14941
ppid14759 Child Process fpid0 pid14942
ppid1 After forking fpid0 pid14942 ppid1
ps PID TTY TIME CMD 14759 pts/9 000
tcsh
25
System Call wait()

• wait system call allows a parent process to wait
• for the demise of a child process.
• See forkEx4.c

26
include ltstdio.hgt include ltsys/types.hgt include
ltunistd.hgt main() int fpid, status
printf("Before forking ...\n") fpid
fork() if (fpid 0) printf("Child
Process fpidd pidd ppidd\n", fpid,
getpid(), getppid()) else
printf("Parent Process fpidd pidd ppidd\n",
fpid, getpid(), getppid())
wait(status) printf("After forking fpidd
pidd ppidd\n", fpid, getpid(),
getppid())
27
cc forkEx4.c -o forkEx4 forkEx4 Before
forking ... Parent Process fpid14980 pid14979
ppid14759 Child Process fpid0 pid14980
ppid14979 After forking fpid0 pid14980
ppid14979 After forking fpid14980 pid14979
ppid14759
28
System Call exec()

• exec() system call invokes another program by
  replacing
• the current process
• No new process table entry is created for exec()
  program.
• Thus, the total number of processes in the
  system isnt
• changed.
• Six different exec functions
• execlp, execvp, execl, execv, execle, execve,
• (see man page for more detail.)
• exec system call allows a process to choose its
  successor.

29
/ execEx1.c / include ltstdio.hgt include
ltunistd.hgt main() printf("Before execing
...\n") execl("/bin/date", "date", 0)
printf("After exec\n")
execEx1 Before execing ... Sun May 9 163917
CST 1999
30
/ execEx2.c / include ltsys/types.hgt include
ltunistd.hgt include ltstdio.hgt main() int
fpid printf("Before execing ...\n") fpid
fork() if (fpid 0)
execl("/bin/date", "date", 0)
printf("After exec and fpidd\n",fpid)
execEx2 Before execing ... After exec and
fpid14903 Sun May 9 164708 CST 1999
31
Handling Signal

• A signal is a message from one process to
  another.
• Signal are sometime called software interrupt
• Signals usually occur asynchronously.
• Signals can be sent
• A. by one process to anther (or to itself)
• B. by the kernel to a process.
• Unix signals are content-free. That is the only
  thing that
• can be said about a signal is it has arrived
  or not

32
Handling Signal

• Most signals have predefined meanings
• A. sighup (HangUp) when a terminal is closed,
  the
• hangup signal is sent to every process in
  control terminal.
• B. sigint (interrupt) ask politely a process
  to terminate.
• C. sigquit (quit) ask a process to terminate
  and produce a
• codedump.
• D. sigkill (kill) force a process to
  terminate.
• See signEx1.c

33
include ltstdio.hgt include ltsys/types.hgt include
ltunistd.hgt main() int fpid, status
printf("Before forking ...\n") fpid
fork() if (fpid 0) printf("Child
Process fpidd pidd ppidd\n", fpid,
getpid(), getppid()) for() / loop
forever / else printf("Parent
Process fpidd pidd ppidd\n", fpid,
getpid(), getppid()) wait(status) /
wait for child process / printf("After
forking fpidd pidd ppidd\n", fpid,
getpid(), getppid())
34
cc sigEx1.c -o sigEx1 sigEx1 Before forking
... Parent Process fpid14989 pid14988
ppid14759 Child Process fpid0 pid14989
ppid14988 ps PID TTY TIME CMD 14988
pts/9 000 sigEx1 14759 pts/9 001 tcsh
14989 pts/9 009 sigEx1 kill -9 14989 ps
...
35
Scheduling Processes

• On a time sharing system, the kernel allocates
  the CPU to
• a process for a period of time (time slice or
  time quantum)
• preempts the process and schedules another one
  when
• time slice expired, and reschedules the
  process to continue
• execution at a later time.
• The scheduler use round-robin with multilevel
  feedback
• algorithm to choose which process to be
  executed
• A. Kernel allocates the CPU to a process for a
  time slice.
• B. preempts a process that exceeds its time
  slice.
• C. feeds it back into one of the several
  priority queues.

36
Process Priority
Processes
Priority Levels
swapper
wait for Disk IO
wait for buffer
wait for inode
...
Kernel Mode
wait for child exit
User Mode
User level 0
User level 1
...
User level n
37
Process Scheduling (Unix System V)

• There are 3 processes A, B, C under the
  following
• assumptions
• A. they are created simultaneously with
  initial priority 60.
• B. the clock interrupt the system 60 times per
  second.
• C. these processes make no system call.
• D. No other process are ready to run
• E. CPU usage calculation CPU decay(CPU)
  CPU/2
• F. Process priority calculation priority
  CPU/2 60.
• G. Rescheduling Calculation is done once per
  second.

38
Process A Priority CPU count
Process B Priority CPU count
Process C Priority CPU count
0
60 0 60 75 30 67 15
63 7 67 76 33
60 0 60 0 60 75 30 67
15 63 7 ...
60 0 60 0 60 0
60 75 30 67 15
1
2
3
4
39
Unix System Kernel
Instructors Fu-Chiung Cheng (???) Associate
Professor Computer Science Engineering Tatung
Institute of Technology
40
Booting

• When the computer is powered on or rebooted, a
  short
• built-in program (maybe store in ROM) reads
  the first
• block or two of the disk into memory. These
  blocks
• contain a loader program, which was placed on
  the disk
• when disk is formatted.
• The loader is started. The loader searches the
  root
• directory for /unix or /root/unix and load the
  file into
• memory
• The kernel starts to execute.

41
The first processes

• The kernel initializes its internal data
  structures
• it constructs linked list of free inodes,
  regions, page table
• The kernel creates u area and initializes slot 0
  of process
• table
• Process 0 is created
• Process 0 forks, invoking the fork algorithm
  directly
• from the Kernel. Process 1 is created.
• In kernel mode, Process 1 creates user-level
  context
• (regions) and copy code (/etc/init) to the
  new region.
• Process 1 calls exec (executes init).

42
init process

• The init process is a process dispatcherspawning

• processes, allow users to login.
• Init reads /etc/inittab and spawns getty
• when a user login successfully, getty goes
  through a login
• procedure and execs a login shell.
• Init executes the wait system call, monitoring
  the death
• of its child processes and the death of
  orphaned processes
• by exiting parent.

43
Init fork/exec a getty progrma to manage the line
When the shell dies, init wakes up and fork/exec
a getty for the line
Getty prints login message and waits for
someone to login
The shell runs programs for the user unitl the
user logs off
The login process prints the password message,
read the password then check the password
44
File Subsystem

• A file system is a collection of files and
  directories on
• a disk or tape in standard UNIX file system
  format.
• Each UNIX file system contains four major parts
• A. boot block
• B. superblock
• C. i-node table
• D. data block file storage

45
File System Layout
Block 0 bootstrap
Block 1 superblock
Block 2
Block 2 - ni-nodes
...
Block n
Block n1
Block n1 - lastFiles
...
The last Block
46
Boot Block

• A boot block may contains several physical
  blocks.
• Note that a physical block contains 512 bytes
• (or 1K or 2KB)
• A boot block contains a short loader program for

• booting
• It is blank on other file systems.

47
Superblock

• Superblock contains key information about a file
  system
• Superblock information
• A. Size of a file system and status
• label name of this file system
• size the number of logic blocks
• date the last modification date of super block.
• B. information of i-nodes
• the number of i-nodes
• the number of free i-nodes
• C. information of data block free data
  blocks.
• The information of a superblock is loaded into
  memory.

48
I-nodes

• i-node index node (information node)
• i-list the list of i-nodes
• i-number the index of i-list.
• The size of an i-node 64 bytes.
• i-node 0 is reserved.
• i-node 1 is the root directory.
• i-node structure next page

49
I-node structure
mode
owner
timestamp
Data block
Data block
Size
Data block
Data block
Reference count
...
...
Block count
Direct blocks 0-9
Data block
Data block
Indirect block
...
Single indirect
Indirect block
Double indirect
Indirect block
Indirect block
Triple indirect
50
I-node structure

• mode A. type file, directory, pipe, symbolic
  link
• B. Access read/write/execute (owner, group,)
• owner who own this I-node (file, directory,
  ...)
• timestamp creation, modification, access time
• size the number of bytes
• block count the number of data blocks
• direct blocks pointers to the data
• single indirect pointer to a data block which
• pointers to the data blocks (128 data blocks).
• Double indirect (12812816384 data blocks)
• Triple indirect (128128128 data blocks)

51
Data Block

• A data block has 512 bytes.
• A. Some FS has 1K or 2k bytes per blocks.
• B. See blocks size effect (next page)
• A data block may contains data of files or data
  of
• a directory.
• File a stream of bytes.
• Directory format

i-
Next
size
File name
pad
52
home
john
alex
jenny
Report.txt
bin
notes
find
grep
i-
Next
10
Report.txt
pad
i-
Next
3
bin
pad
i-
Next
5
notes
pad
0
Next
53
Boot Block
home
SuperBlock
i-node
i-nodes
kc
...
alex
i-node
...
Report.txt
source
notes
i-node
...
find
grep
i-node
...
Device driver Hardware control
In-core inodes
notes
u area
...
i-node
...
source
...
Current directory inode
i-node
...
Report.txt
...
Data Blocks
i-node
Current Dir
54
In-core inode table

• UNIX system keeps regular files and directories
  on block
• devices such as disk or tape,
• Such disk space are called physical device
  address space.
• The kernel deals on a logical level with file
  system
• (logical device address space) rather than
  with disks.
• Disk driver can transfer logical addresses into
  physical
• device addresses.
• In-core (memory resident) inode table stores the

• inode information in kernel space.

55
In-core inode table

• An in-core inode contains
• A. all the information of inode in disks.
• B. status of in-core inode
• inode is locked,
• inode data changed
• file data changed.
• C. the logic device number of the file system.
• D. inode number
• E. reference count

56
File table

• The kernel have a global data structure, called
  file table,
• to store information of file access.
• Each entry in file table contains
• A. a pointer to in-core inode table
• B. the offset of next read or write in the
  file
• C. access rights (r/w) allowed to the opening
  process.
• D. reference count.

57
User File Descriptor table

• Each process has a user file descriptor table to
  identify
• all opened files.
• An entry in user file descriptor table pointer
  to an entry
• of kernels global file table.
• Entry 0 standard input
• Entry 1 standard output
• Entry 2 error output

58
System Call open

• open A process may open a existing file to read
  or write
• syntax
• fd open(pathname, mode)
• A. pathname is the filename to be opened
• B. mode read/write
• Example

59
include ltstdio.hgt include ltsys/types.hgt include
ltfcntl.hgt main() int fd1, fd2, fd3
printf("Before open ...\n") fd1
open("/etc/passwd", O_RDONLY) fd2
open("./openEx1.c", O_WRONLY) fd3
open("/etc/passwd", O_RDONLY) printf("fd1d
fd2d fd3d \n", fd1, fd2, fd3)
cc openEx1.c -o openEx1 openEx1 Before open
... fd13 fd24 fd35
60
User file descriptor table
in-core inodes
file table
U area
0

...
1
Pointer to Descriptor table
2
CNT1 R
CNT2 /etc/passwd
3
...
4
...
CNT1 W
5
...
6
CNT1 ./openEx2.c
7
. . .
...
CNT1 R
...
61
System Call read

• read A process may read an opened file
• syntax
• fd read(fd, buffer, count)
• A. fd file descriptor
• B. buffer data to be stored in
• C. count the number (count) of byte
• Example

62
include ltstdio.hgt include ltsys/types.hgt include
ltfcntl.hgt main() int fd1, fd2, fd3
char buf120, buf220 buf119'\0'
buf219'\0' printf("\n") fd1
open("/etc/passwd", O_RDONLY) read(fd1, buf1,
19) printf("fd1d buf1s \n",fd1, buf1)
read(fd1, buf2, 19) printf("fd1d buf2s
\n",fd1, buf2) printf("\n")
cc openEx2.c -o openEx2 openEx2 fd13
buf1rootx01Super-Us fd13
buf2er//sbin/sh daemo
63
include ltstdio.hgt include ltsys/types.hgt include
ltfcntl.hgt main() int fd1, fd2, fd3
char buf120, buf220 buf119'\0'
buf219'\0' printf("\n") fd1
open("/etc/passwd", O_RDONLY) fd2
open("/etc/passwd", O_RDONLY) read(fd1, buf1,
19) printf("fd1d buf1s \n",fd1, buf1)
read(fd2, buf2, 19) printf("fd2d buf2s
\n",fd2, buf2) printf("\n")
cc openEx3.c -o openEx3 openEx3 fd13
buf1rootx01Super-Us fd24
buf2rootx01Super-Us
64
User file descriptor table
in-core inodes
file table
U area
0

...
1
Descriptor table
2
CNT1 R
CNT2 /etc/passwd
3
...
4
...
...
5
...
6
...
7
. . .
...
CNT1 R
...
65
System Call dup

• dup copy a file descriptor into the first free
  slot of the
• user file descriptor table.
• syntax
• newfd dup(fd)
• A. fd file descriptor
• Example

66
include ltstdio.hgt include ltsys/types.hgt include
ltfcntl.hgt main() int fd1, fd2, fd3
char buf120, buf220 buf119'\0'
buf219'\0' printf("\n") fd1
open("/etc/passwd", O_RDONLY) fd2
dup(fd1) read(fd1, buf1, 19)
printf("fd1d buf1s \n",fd1, buf1)
read(fd2, buf2, 19) printf("fd2d buf2s
\n",fd2, buf2) printf("\n") char
buf120, buf220
cc openEx4.c -o openEx4 openEx4 fd13
buf1rootx01Super-Us fd24
buf2er//sbin/sh daemo
67
User file descriptor table
in-core inodes
file table
U area
0

...
1
Descriptor table
2
CNT2 R
CNT1 /etc/passwd
3
...
4
...
...
5
...
6
...
7
. . .
...
...
...
68
System Call creat

• creat A process may create a new file by creat
  system
• call
• syntax
• fd write(pathname, mode)
• A. pathname file name
• B. mode read/write
• Example

69
System Call close

• close A process may close a file by close
  system
• call
• syntax
• close(fd)
• A. fd file descriptor
• Example

70
System Call write

• write A process may write data to an opened
  file
• syntax
• fd write(fd, buffer, count)
• A. fd file descriptor
• B. buffer data to be stored in
• C. count the number (count) of byte
• Example

71
/ creatEx1.c / include ltstdio.hgt include
ltsys/types.hgt include ltfcntl.hgt main() int
fd1 char buf1"I am a string\n" char
buf2"second line\n" printf("\n")
fd1 creat("./testCreat.txt", O_WRONLY)
write(fd1, buf1, 20) write(fd1, buf2, 30)
printf("fd1d buf1s \n",fd1, buf1)
close(fd1) chmod("./testCreat.txt", 0666)
printf("\n")
72
cc creatEx1.c -o creatEx1 creatEx1 fd1
3 buf1I am a string ls -l
testCreat.txt -rw-rw-rw- 1 cheng staff
50 May 10 2037 testCreat.txt more
testCreat.txt ...
73
System Call stat/fstat

• stat/fstat A process may query the status of a
  file (locked)
• file type, file owner, access permission. file
  size, number
• of links, inode number, access time.
• syntax
• stat(pathname, statbuffer) fstat(fd,
  statbuffer)
• A. pathname file name
• B. statbuffer read in data
• C. fd file descriptor
• Example

74
/ statEx1.c / include ltsys/stat.hgt main()
int fd1, fd2, fd3 struct stat bufStat1,
bufStat2 char buf120, buf220
printf("\n") fd1 open("/etc/passwd",
O_RDONLY) fd2 open("./statEx1", O_RDONLY)
fstat(fd1, bufStat1) fstat(fd2,
bufStat2) printf("fd1d inode nod block
sized blocksd\n", fd1, bufStat1.st_ino,buf
Stat1.st_blksize, bufStat1.st_blocks)
printf("fd2d inode nod block sized
blocksd\n", fd2, bufStat2.st_ino,bufStat2.st_
blksize, bufStat2.st_blocks)
printf("\n")
75
cc statEx1.c -o statEx1 statEx1 fd13
inode no21954 block size8192 blocks6 fd24
inode no190611 block size8192 blocks ...
76
System Call link/unlink

• link hardlink a file to another
• syntax
• link(sourceFile, targetFile) unlink(file)
• A. sourceFile targetFile, file file name
• Example
• Lab exercise write a c program which use
  link/unlink
• system call. Use ls -l to see the reference
  count.

77
System Call chdir

• chdir A process may change the current
  directory
• of a processl
• syntax
• chdir(pathname)
• A. pathname file name
• Example

78
include ltstdio.hgt include ltsys/types.hgt include
ltfcntl.hgt main() chdir("/usr/bin")
system("ls -l")
ls -l /usr/bin
79
End of System Kernel Lecture
