ASD and VSD in Adults Identification and
Indications for Intervention Martha Grogan, MD
No disclosures
2
Atrial Septal Defects
SVC
SV
SEC
P
RV
CS
IVC
3
Secundum ASD
4
Secundum ASD - TEENormal Pulmonary Veins
5
ASD Closure
6
Secundum ASD
WDE

• Usually isolated abnormality, 5 with APVC
• Intervention for ? right heart, exclude PHT
• Device closure feasible in most

7
Device ASD Closure

• Alternative to surgery for secundum ASD
• Largest device 38 mm
• 3-5 mm septal rim
• TEE or IC echo
• Monitor placement
• Surgery TR, AF, APV
• multiple ASDs

8
Secundum Atrial Septal Defect

• ? survival with surgery/intervention
• Konstandinides et al - NEJM 1995
• Patel et al - J Interv Cardiol 2007
• Excellent prognosis after closure
• Spies et al - Clin Res Cardiol 2007
• PHT rare with ASD
• Persistent risk of AF with ? age at op
• Murphy et al - NEJM 1990

9
ASD - AFib/Flutter
Murphy et al NEJM 1990
10
ASD - Familial
Holt-Oram Syndrome Familial ASD with AV
conduction defect
11
Primum ASD
12
Primum ASD Partial AV Defect

• ECG - left axis deviation, first degree AV block
• Associations - MV and TV cleft, VSD, LVOT
  obstruction

13
Partial AV Septal Defect

• Partial AV canal repair in pt 40 years - low
  risk
• Long-term survival good - ? in symptoms
• Bergin ML et al - J Am Coll Cardiol 1995
• Reoperation for left AV valve malfunction, or
  relief of LVOT obstruction necessary in gt10
• El-Najdawi et al - J Th CV Surg 2000

14
28 -Year-Old FemaleSevere MR

• Primum ASD closure and repair mitral cleft (age 3
  yrs)
• No Residual shunt
• Severe MR - residual cleft
• Mild LVE, EF 70, mild LA enlargement
• Asymptomatic, but sedentary

15
28 -Year-Old FemaleSevere MR due to residual
cleft

• You recommend
• Mitral Valve Repair
• Mitral Replacement Bioprosthesis
• Observation
• Mitral Replacement - Mechanical

16
Partial AV Septal DefectCleft Mitral Valve
Lesser chance of MV repair especially if
previous attempt
17
(No Transcript)
18
55-Year-Old Female w/Breast CancerTTE for Chemo
Right Heart Enlargement
19
55-Year-Old FemaleTEE - Sinus Venosus ASD
20
TEE - Sinus Venosus ASD Anomalous right upper
pulmonary vein
21
Sinous Venosus ASDBreast Cancer

• Central venous catheter placed six months ago
• Received 4 cycles of chemo
• Can she proceed with radiation ?
• Should the ASD be closed now

22
Sinus Venosus ASD

• Associations - anomalous PV connection (gt90)
• Surgery - ? morbidity, excellent postop survival
• Attenhofer Jost CA et al - Circulation 2005

23
NormalPulmonary VenousConnections
IV
SVC
Ao
LPA
RPA
LPVs
RPVs
LA
Ammash JACC, 1997
24
TEE
LU
RU
RL
LL
RPV
LPV
LA
70
110
90
25
AnomalousRUPVShort Axis View
AscAo
RUPV
MPA
SVC
RPA
LPA
LPV
LA
RLPV
Esophagus
Ammash JACC, 1997
26
Anomalous Right Upper Pulmonary Vein
SVC
RPA
CM881749-25
27
Anomalous Right Upper Pulmonary Vein
CM881749-26
28
Coronary Sinus ASDLeft-sided SVC
29
Coronary Sinus ASDLeft-sided SVC
30
Coronary Sinus ASD

• Often difficult to diagnose
• Isolated, with LSVC or complex CHD
• Amenable to surgical closure
• Attenhofer Jost CA et al Cardiol Young 2007

31
(No Transcript)
32
(No Transcript)
33
VSD Classification Scheme STS and European
Association CT Surgery

• Outlet 6 (33 Asia) 2) Membranous 80
• 3) Muscular 10 (20 infants) 4) Inlet 4

Jacobs JP et al Ann Thorac Surg 2000
34
Muscular VSD

• TTE diagnostic in most patients
• Identifies number, location, hemodynamics
• chamber size and function

35
Muscular VSD

• Spontaneous closure common
• Large defect close
• Operation
• Device available

36
What is the Diagnosis?
37
Membranous VSD

• Associations endocarditis, AV and TV
  regurgitation
• Management depends on size and associations

38
What is the Diagnosis?
39
What is the Diagnosis?
40
Outlet VSDInfundibular/Supracristal/Doubly
Committed

• Associations AV regurgitation often
  progressive
• Management surgery to prevent worsening AV
  regurg

41
Outlet Ventricular Septal DefectDilation and
Distortion of the Right Sinus
42
Indications for VSD ClosureOther than Outlet VSD

• QpQs gt1.51
• No associated severe PHT
• Progressive TR or AR
• Recurrent endocarditis
• Left-sided chamber enlargement

43
(No Transcript)
44
49-Year-Old with Eisenmenger VSD
45
Eisenmenger Syndrome

• Long-standing L-R shunt
• ? pulmonary blood flow
• Pulm vascular disease
• Reversal of shunt
• Cyanosis and clubbing

46
56 Year-Old Female Eisenmenger PDA

• Diagnosis age 19
• Parents told life expectancy 25 yrs
• Finished college , Married
• Phlebotomy - 30 yrs
• Hg as low as 10 gm/dl
• Self administered iron
• One episode hemoptysis
• SVT - Verapamil

47
56 Year-Old Eisenmenger Referred for Transplant

• Recurrent pulmonary infections
• DOE - worse recently, but improving
• 6 min walk 573 m (1882 ft)
• O2 TMET 4.8 min
• 9.1 ml/kg/min
• Hg 18.8 g/dl, Hct 57.8

48
Eisenmenger Syndrome
49
Eisenmenger Syndrome
50
Eisenmenger Syndrome
51
Pulmonary Artery Pressure
PR end diastolic 3.6 51 mmHg
TR 5.8 m/sec 135 mmHg
Estimated PA 145/61 mmHg Systemic
90/60 mmHg
52
Pulmonary Artery Pressure
PR end diastolic 3.6 51 mmHg
TR 5.8 m/sec 135 mmHg
Estimated PA 145/61 mmHg Systemic
90/60 mmHg
53
56 Year-Old Eisenmenger Hgb 19 gm/dl, HCT 58PA
145/61 mmHg
You would consider starting pulmonary
vasodilators and

• Stop phlebotomy
• Stop phelbotomy and start Iron
• Continue phlebotomy
• Continue phlebotomy and evaluate for transplant

54
56 Year-Old Female HG 18.7 gm/dl, HCT 57.8PA
145/61 mmHg
You would consider starting pulmonary
vasodilators and

• Stop phlebotomy
• Stop phelbotomy and start Iron
• Continue phlebotomy and list for transplant

Iron 12 ug/dl (nl 35-340), Iron saturation 8
55
Eisenmenger SyndromeConservative Management

• Survival gt PPH
• Avoid phlebotomy
• Caution with procedures
• Specialized care
• Promising role of vasodilator Rx

56
Eisenmenger SyndromeHematologic Issues
57
Iron Deficiency Anemia
58
Management Strategies
Avoid
High altitude
Dehydration
Pregnancy
59
Management Strategies
Caution
60
Eisenmenger Syndrome

• Rosenzweig et al Circulation 1999
• Long-term prostacyclin improves hemodynamics and
  quality of life
• Christensen et al Am J Cardiol 2004
• Bosentan - nonselective ET antagonist
• 9 Eisenmenger pt - bosentan 125 mg twice daily
• ? NYHA class (p 0.03), ? O2 sat (p 0.03)

61
Eisenmenger Syndrome

• Galie et al Circulation 2006
• Placebo-controlled trial in pt with Eisenmenger
• Bosentan - well tolerated, ? exercise capacity
  and hemodynamics without compromising oxygen sats

62
Eisenmenger SydromeNow 60-Year-Old

• Hg 24 gm/dl
• Sildenafil
• Feels great
• Breaks record for 6 min walk
• 40th Wedding Anniversary

63
(No Transcript)
64
ASD and VSD Nomenclature and Examples

• ASD
• TTE diagnosis in majority
• Look for associated defects
• Indications for intervention
• VSD
• TTE diagnosis in majority
• ? LA and LV, valve dysfunction
• Indications for intervention

65
Congenital Heart DiseaseLargely Pattern
Recognition
Male or Female Seagull?
