The Globalization of North American Gas

1

• The Globalization of North American Gas
• 2001 Energy Finance Conference
• February 23, 2001

2
Introduction to El Paso
3
Energy Use Per Capita
4
World Population GrowthClub of Rome Projected
in 1970
5
Energy Implications
6
North American Market Summary

• North American gas demand
• Electric generation drives natural gas demand in
  the U.S., Canada, and Mexico
• Global competition for production of goods
  requires competitive global pricing for energy in
  North America
• North American gas supply
• Conventional sources will not be sufficient to
  fill demand
• Supply from frontier areas required
• Increased demand and constrained supply requires
  new solutions

7
Annual North American Gas Demand by Country
8
Why Natural Gas?

• Cleanest burning fossil fuel
• Gives off one half as much carbon dioxide per
  unit of energy as coal 25 less than oil
• Gives off virtually no sulfur dioxide and only
  small amounts of nitrous oxides
• Extensive and reliable pipeline delivery and
  storage infrastructure in place in US, Canada,
  and to large extent, Mexico
• Including cross-border transportation access
• Gas-fired generation requires lower capital costs
  and shorter construction lead times

9
Gas Turbine Technology

• Advantages
• Low capital cost
• Environmentally friendly Low NOx and no
  particulates or SOx
• Short permitting/construction
• Load following capability
• Pipeline expansions allow for site targeting
• Superior heat rates
• Disadvantages
• High variable OM costfuel
• Higher fuel price and availability risks

10
U.S. Power PlantsUnder Development
11
Mexican Power PlantsUnder Development
12
North American Gas Demand for Electric Power
13
Todays PictureKey Market Statistics
14
Normalized Gulf of Mexico Decline Rates1970
Compared to 1996
15
North American Supply Summary

• Supply must increase by about 2.5 Bcf/d each year
  on average from 2000 to 2015
• The average increase over the last 5 years is
  less than 1 Bcf/d per year
• Reserves of 20 30 BCF/d must be found to offset
  declines
• The majority of the supply growth will come from
  the WCSB, GOM, Rocky Mountains, Mexico, and
  Arctic
• Several of these areas may have difficulty
  achieving the predicted growth

16
Pressure on Incremental Supply The LNG Solution

• Additional LNG could fill gap
• Now cost competitive due to cost reductions
• Arrives on fast growing coastal regions of North
  America
• Offers peaking services well suited to power
  plant generation
• Supports the grid by connecting to the end of
  telescoped pipelines can create new capacity
  by moving null points
• 700 Tcf of proved gas reserves stranded worldwide

17
Estimate of LNG Cost Reductions
18
Conclusions

• North America relies on significant increases in
  natural gas supplies to continue economic
  expansion
• North American demand growth should average over
  2.5 Bcf/d per year through 2015
• Conventional production regions will be stressed
  to meet demand frontier supply sources and
  increased LNG imports will be required
• Supply growth expected from WCSB, GOM, Rockies,
  Arctic and Mexico
• If projections of supply growth prove deficient,
  alternate fuels (such as clean coal) could fill
  gap for electric generation demand

19

• The Globalization of North American Gas
• 2001 Energy Finance Conference
• February 23, 2001
