Single photon sources

1
Single photon sources
2
Approximate single photon source

• Attenuated laser
• Coherent state

Laser
Attenuator
Mean number of photon per pulse 0,1
3
Pair photons and entangled photons
4
Why photon pairs?

• Heralded single photon source

JGR,JMO 1998, 45, 595-604
Triggered APD
Heralded photons
Source of Photon pairs
Trigger photons
APD
Mandel (1986)
Experimental realization of a localized
one-photon state, C. K. Hong and L. Mandel, Phys.
Rev. Lett. 56, 58 (1986) Observation of
sub-poissonian light in parametric
downconversion. J.G. Rarity, P.R.Tapster and E.
Jakeman, Opt. Comm., 62(3)201, 1987.
5
Creating Entangled Photon Pairs
C
Phase matching and energy conservation
D
6
Portable Crystal based entangled pair
source150mW diode70000 detected coincidences/sec
7
Recent experiments

• Free-Space distribution of entanglement and
  single
• photons over 144 km, R. Ursin, et al
  quant-ph/0607182

8
Pair photon generation in microstructured
fibres With University of Bath

• Non-linear process in ?(3)
• 2 pump photons ? 2 emitted photons

Phase matching and energy conservation

• Use of the normal dispersion region
• no pump power dependence
• wavelengths created far from the pump
• Raman and fluorescence amplification effects
  reduced

W. J. Wadsworth et al. (Opt. Express 2004)
9
Coincidences3.105 s-1
Spectra
Experiment
10
Coincidence results
Idler (895nm) single-mode fiber
14 of coincidences Signal (583nm) multimode
fiber 33 of coincidences
single-mode fiber 22 of
coincidences
2 photon peak

• Ppump540µW
• Coincidence rate 3.5.105 s-1
• Overall coupling efficiency in SMF 60

4 photon peak
Confirmation of bright pair photon emission
-potential for 80 coupling to SMF
11
Recent HOM Experiment
12
Entangled state, preliminary measurement
Latest result by narrow band filtering 90 in HV
and 80 in /-45.
