Continue on

1
Continue on Machine Language Representation of
Instruction
2

• What happens if we have immediate in the
  instruction
• I-Type layout is used for instruction that uses
  one of the following
• registers with an immediate value .
• registers with offset
• Such instructions are addi, lw, sw, bne, beq
• The format and fields for I-Type layout is

op rs rt Immediate
6 bit 5bit 5 bit
16 bit
3

• op field (opcode) in I-type layout has unique
  code for each instruction.
• rs field (source register) generally used to
  specify the register containing first operand
• rt field (target register) generally used to
  specify register that receives the result of
  computation.
• Immediate has immediate value. This value is a
  signed number and is signed extended.
• This immediate field is large enough to handle
  the offset in lw and sw instruction

4

• Example
• Write the machine instruction for this assembly
  instruction
• addi s5, s6, -50
• op field (opcode field) by looking at instruction
  code table, is 8
• rs field that contains s6 and corresponds to
  22nd register in the processor
• rt field that contains s5 and corresponds to
  21st register.
• Immediate has immediate value of -50

5

• Using this information
• addi s5, s6, -50

op rs rt Immediate
6 bit 5bit 5 bit 16bit
decimal representation
8 22 21 -50
6 bit 5bit 5 bit 16bit
Machine language instruction representation
001000 10110 10101 1111111111001110
6 bit 5bit 5 bit
16bit
6

• Example
• Write the machine instruction for this assembly
  instruction
• lw t0, 32(s3)
• op field (opcode field) by looking at instruction
  code table, is 35
• rs field (source field) that contains s3 and
  corresponds to 19th register in the processor
• rt field (target field) that gets the value
  from the address in memory.t0 corresponds to 8th
  register.
• Immediate has the offset value of 32.

7

• Using this information
• lw t0, 32(s3)

op rs rt Immediate
6 bit 5bit 5 bit 16bit
decimal representation
35 19 8 32
6 bit 5bit 5 bit 16bit
machine language instruction representation
100011 10011 01000 0000000000100000
6 bit 5bit 5 bit
16bit
8

• Example
• Write the machine instruction for this assembly
  instruction
• sw t0, 32(s3)
• op field (opcode field) by looking at instruction
  code table, is 43
• rs field (source field) contains s3 and
  corresponds to 19th register in the processor
• rt field (target field) represents the t0 that
  its value needs to be stored in memory.t0
  corresponds to 8th register
• Immediate has the offset value of 32.

9

• Using this information
• sw t0, 32(s3)

op rs rt Immediate
6 bit 5bit 5 bit 16bit
decimal representation
43 19 8 32
6 bit 5bit 5 bit 16bit
machine language instruction representation
101011 10011 01000 0000000000100000
6 bit 5bit 5 bit 16bit
10

• Example
• In this C segment Find the machine language for
  branch instruction (beq).
• loop add t0, t0, t1
• addi t0, t0, 4
• beq s1 , s2, loop
• op field (opcode field) by looking at instruction
  code table , is 4
• rs field (source field) contains s1 and
  corresponds to 17th register in the processor
• rt field (target field) represents s2 that its
  value need to be compare and corresponds to 18st
  register.
• Immediate a positive or negative value that
  shows the number of instructions a way from
  branch instruction.

11

• We know that PC (program counter) is a register
  that will increment as each instruction executed.
  It always shows the address of one instruction
  after current executing instruction.
• The 16-bit immediate field is a 16 bits signed
  integer that represents the number of words away
  from one instruction after branch instruction (PC
  shows one instruction after branch instruction).
  The number can be negative if the label in the
  branch instruction is referring to the
  instruction above the current Executing
  instruction or could be positive if the label is
  referring to the instruction under the current
  Executing instruction.
• Processor will add this immediate value to PC in
  order to find the exact address of label.
• In the last slide example, loop label is above
  the beq instruction, the immediate should be a 16
  bits negative value, and loop is 3 instruction
  away from the instruction after beq, therefore
  -3 will be placed in the immediate field

12

• In this C segment Find the machine language for
  branch instruction (beq).
• loop add t0, t0, t1
• addi t0, t0, 4
• bnq s1 , s2, loop
• op field op code is 4 by looking at table
• rs (source register field) s1 which corresponds
  to 17 register in the processor
• rt (target field)s2 corresponds to 18 register
  in the processor
• Immediate field is -3 which shows the number of
  words to the instruction after bnq.

op rs rt Immediate
6 bit 5bit 5 bit 16 bit
4 17 18 -3
10001 10010 1111111111111101
000100
6 bit 5bit 5 bit
16 bit
13

• Problem With Small Immediate Field
• In I-type Format
• MIPS has a computer architecture that supports a
  32 bit data path, (transfers 32 bit data from
  register to memory and vice versa.)
• It has 232 memory locations and each location has
  a 32 bit address.
• Now what will happen if, in the immediate field
  of I-Type layout, we have a big immediate number
  that need to be used in the calculation and dose
  not fit in the 16 bits immediate field of I-Type
  format
• Chances are that addi, lw, and sw will use
  an immediate that is small enough to fit in the
  immediate field, but we have to find a way to
  represent the big immediate in machine language.

14

• How to solve this problem
• Solution to use big immediate for addition is to
  use new instruction.
• lui register(at) immediate
• lui loads upper bits of immediate , it takes 16
  bit of immediate and puts them in the upper half
  of the specified register (at) and sets lower
  half to 0
• register that takes the upper half of immediate
  .Use at, it is specifically used for assembler.
  (by convention)
• Big immediate value

1
2
3
15

• Example
• Using big immediate number in addition
• addi t0 , t0, 0xABABCDCD (A big decimal
  number in hex)
• It will be implemented as follow
• lui at, 0xABAB
• ori at, at, 0xCDCD
• add t0, t0, at

16

• J-Type format
• Jump instructions such as j label and jal
  label use this instruction format.
• op field hold the unique value for each one of
  these instruction
• address field hold the address of the label.

op Address
6 bit 26 bit
17

• Example
• Write the machine instruction for this assembly
  instruction assume the label has address 0xC1C4
• j label_1
• op field (opcode field) by looking at instruction
  code table, is 2
• address field, contains the address of the label
  (0xC1C4)

op Address
6 bit 26 bit
2 C1C4(in hex)
6 bit 26 bit
machine language instruction representation
000010 00000000001100000111000100
6 bit 26 bit
18

• Example
• Write the machine instruction for this assembly
  instruction assume the label has address 0xC1C8
• jal label_2
• op field (opcode field) by looking at instruction
  code table ,is 3
• address field that contain the address of the
  label (0xC1C8)

op Address
6 bit 26 bit
decimal representation
3 C1C8(in hex)
6 bit 26 bit
machine language instruction representation
000011 00000000001100000111001000
6 bit 26 bit
