TrueSTEAM Humidification System

1
TrueSTEAM Humidification System
Click For Next Slide
2
What you will learn

• Overview of TrueSTEAM
• The Truth About Evaporative vs Steam Humidifiers
• TrueSTEAM Key Features and Benefits
• Application and Installation Overview
• TrueSTEAM Support Materials

Click For Next Slide
3
TrueSTEAM Humidification SystemOverview
Click For Next Slide
4
TrueSTEAM Overview

• Combines the benefits of steam with the
  reliability and easy install of bypass.
• Increases overall available market by more than
  30 due to install flexibility.
• Finally, a solution for unconditioned spaces.
• Simple maintenance.

True Innovation for Humidification
Click For Next Slide
5
TrueSTEAM Overview

• Quantum Leap in Application and Performance.
• Eliminates dealers 1 callback cant reach
  set-point!
• Installs faster than bypass can be mounted in
  under 5 minutes!
• Can be installed remotely up to 20 feet from
  HVAC equipment with remote mount hose.
• More control options for every user.
• 11 Humidification Delivery Rate (all water into
  air).

True Innovation for Humidification
Click For Next Slide
6
The Truth About Humidification Delivery

• Many humidifier manufacturers list output
  capacity in gallons per day (GPD), or the amount
  of moisture they can deliver in a 24-hour period
  while the furnace is running (plenum temp
  120F-140F).
• But how do you know which ones really work and if
  a home is getting enough moisture?

Click For Next Slide
Comparing humidification delivery is a great
place to start.
7
The Truth About Humidification Delivery

• Typically, the GPD claim is based on a homes
  heating equipment running 100 of the time, for
  24 hours a day at 120F.
• Since evaporative humidifiers are delivering 100
  of this humidity output only when the furnace is
  running (and no furnace runs full-time), they
  rarely deliver more than 1-gallon of humidified
  air for every FOUR gallons they use.
• In other words, for every 1 gallon humidified, 3
  gallons are being wasted down the drain!

Click For Next Slide
8
The Truth About Humidification Delivery

• Added to this are portable humidifiers that only
  humidify in the room which they are located, not
  the whole house. They also need to be constantly
  re-filled with water, which can be a hassle.
• TrueSTEAM offers the most reliable, efficient
  levels of moisture because of its near 11
  humidification delivery rate, regardless of
  equipment operation.

Click For Next Slide
9
The Truth About Evaporative

• Another factor limiting todays evaporative
  humidifier is that HVAC equipment is changing.
• Dealers are selling more
• High efficiency - 90-95 furnaces
• Heat pumps
• Variable speed
• Equipment changes negatively impact evaporative
  humidifier performance.

Click For Next Slide
10
The Truth About Evaporative

• Because equipment is running less and at lower
  temperatures, a capacity rating of 18 GPD on the
  box is closer to 6 GPD actual output delivery.

Click For Next Slide
11
The Truth About Evaporative

• Plus, for every gallon evaporated, up to 3
  gallons is wasted down the drain, which can
  increase homeowner water bills and is not an
  eco-friendly option.
• What does this mean over a 5-month heating
  season? See below

Click For Next Slide
12
So why are evaporative so popular?

• Todays evaporative humidifiers are flexible
• High familiarity with contractors. 30 year old
  technology.
• Have high reliability
• Can be installed at a much lower cost than steam
• Install quickly
• but bypass flow through humidifiers also
  experience issues
• Reduced output due to equipment changes
• Require large sections of available ducting and
  open space to install
• Require the heat to be on in order to deliver
  humidity

Reduced Output Leads to Callbacks
Click For Next Slide
13
The Truth About Last-Generation Steam

• GREAT PERFORMANCE
• Todays steam humidifiers offer great benefits
• More output
• Humidity on demand when you need it by
  activating equipment
• Reduced water consumption
• POOR RELIABILITY
• Steam units have had reliability issues with
  sticking floats, burning heating elements and
  difficult maintenance
• Can be difficult to install - leaves many
  opportunities on the table

Click For Next Slide
14
TrueSTEAM is True Innovation!


Plus


Quantum Leap in Application and Performance!
Click For Next Slide
15
Revolutionizing Steam Humidification

• The world of heating and cooling equipment is
  vastly different today than it was even a few
  years ago, with the trend towards
  high-efficiency, variable speed, dual-fuel and
  heat pump systems.
• Because of how these systems operate, yesterday's
  humidifiers often fail to deliver the
  humidification that homeowners desire. You told
  us that you needed a humidification system that
  operated independently of equipment.

Click For Next Slide
16
Breakthrough Technology

• TrueSTEAM takes the best features from current
  steam humidifiers with their efficiency,
  performance and decreased water consumption, and
  combines it with the ease of installation,
  reliability and value of flow-through
  humidifiers.
• TrueSTEAM is different from others because it
  operates independent of equipment operation. And,
  with its near 11 humidification delivery rate,
  TrueSTEAM delivers the right amount of
  humidification to keep your customers satisfied.

Click For Next Slide
17
TrueSTEAM Features Benefits
Click For Next Slide
18
TrueSTEAM Features Benefits
Click For Next Slide
19
Choice of Control Options

• TrueSTEAM comes with a control option to fit
  virtually every application and budget.
• Choose from the robust all-in-one control of the
  VisionPRO IAQ, the unique integrated control of
  the TrueIAQ Digital Control or the easy to use
  H8908 manual humidity control.
• The next slide will go through the features of
  each control.

Click For Next Slide
20
Honeywell Humidifier Controls
Click For Next Slide
21
TrueSTEAM Summary

• Combines the benefits of steam with reliability
  and easy install of bypass.
• Increases overall available market by more than
  30 due to install flexibility.
• Finally, a solution for unconditioned spaces.
• Eco-Friendly with 11 Humidification Rate not
  flushing water down the drain.
• Simple maintenance!
• 5-Year Warranty.

Click For Next Slide
True Innovation for Humidification
22
TrueSTEAM

• Installation Options

Click For Next Slide
23
Easy as 1, 2, 3, 4!
Click For Next Slide
24
Anywhere Installation!
Click For Next Slide
25
Remote Mounting Options

• TrueSTEAM can be remotely mounted up to 20 feet
  away from the system with a remote-mount kit,
  making humidification possible in homes where it
  was once thought impossible.

Click For Next Slide
26
Choose the size that is right for you

• 6 Gallon Model (7 amp power)
• Matches output capacity of large bypass and fan
  powered at 2000 sq ft
• Reduces water consumption by 90 over bypass
• Installs in 30 more applications than
  bypass/steam expanding market
• First steam unit capable of being mounted on
  existing electrical circuits

• 9 Gallon Model (10 amp power)
• Meets capacity requirement for homes 2500 sq ft

• Step up opportunity for six gallon buyers
• Presents opportunity to mount on existing
  electrical circuits where 20 Amp is code

• 12 Gallon Model (12 amp power)
• Comparable to majority of steam devices on
  market today at 12-15 gallon output
• Value above existing steam devices in
  reliability, installation, easy maintenance
• Mounting configuration expands market by 60
  over current steam applications
• (not available with H8908)

Click For Next Slide
27
TrueSTEAM Interactive Demos

• Get more marketing, technical and install
  information and interactive demos online at
  www.forwardthinking.honeywell.com.
• Use as a part of your overall training package
  with customers, sales and counter staff.

Click For Next Slide
28
TrueSTEAM Knowledge Test
Click For Next Slide
29
TrueSTEAM Knowledge Test

• Now that you completed this training module, take
  the short quiz to test your knowledge.

30
Test

• 1. The TrueSTEAM can run independent of the HVAC
  system to deliver humidification into the home.
  T F
• 2 .What is the TrueSTEAMs Humidification
  Delivery Rate?
• a. 14
• b. 13
• c. 11
• 3. What is the maximum length of remote hose that
  can be used with TrueSTEAM?
• a. 10 Feet
• b. 15 Feet
• c. 20 Feet
• d. 25 Feet
• e. Up to 10-ft on the 6-gallon model, and up to
  20-ft on the 9- and 12-gallon models.
• 4. When using a bypass humidifier, for every
  gallon evaporated, up to___ gallon(s) is wasted
  down the drain, which can increase homeowner
  water bills and is not an eco-friendly option.
• a. 1
• b. 3
• c. 5
• d. 0

31
Test

• 5. What size hole should be cut into the ductwork
  to mount the TrueSTEAM?
• a. 1
• b. 1 ½
• c. 1 ¾
• d. 2
• 6. What sizes does the TrueSTEAM come in?
• a. 4, 6 and 8 Gallon
• b. 6, 9 and 12 Gallon
• c. 9, 10 and 12 Gallon
• d. 6 Gallon Only

32
Test

• 7. The TrueSTEAM increases overall available
  market by more than ___ due to install
  flexibility.
• a. 10
• b. 30
• c. 50
• d. 60
• 8. What are the three controls that are bundled
  with the TrueSTEAM?
• a. VisionPRO IAQ, TrueIAQ, H8908 Manual
  Humidistat
• b. VisionPRO, TrueIAQ, H8909 Manual Humidistat
• c. FocusPRO 6000, TrueIAQ, H8908 Manual
  Humidistat
• d. Only the TrueIAQ

33
Test

• 9. The 9 Gallon TrueSTEAM meets capacity
  requirement for homes up to _____sq ft in size.
• a. 1500
• b. 2000
• c. 2500
• d. 3000
• 10. TrueSTEAM reduces water consumption by ___
  over bypass.
• a. 25
• b. 50
• c. 70
• d. 90

34
Answer Key

• 1. T
• 2. C
• 3. E
• 4. B
• 5. C
• 6. B
• 7. C
• 8. A
• 9. C
• 10. D
