ICS220 Data Structures and Algorithms

1
ICS220 Data Structures and Algorithms

• Lecture 13
• Dr. Ken Cosh

2
Review

• Data Compression Techniques
• Huffman Coding method

3
This week

• Memory Management
• Memory Allocation
• Garbage Collection

4
The Heap

• Not a heap, but the heap.
• Not the treelike data structure.
• But the area of the computers memory that is
  dynamically allocated to programs.
• In C we allocate parts of the heap using the
  new command, and reclaim them using the
  delete command.
• C allows close control over how much memory is
  used by your program.
• Some programming languages (FORTRAN, COBOL,
  BASIC), the compiler decides how much to
  allocate.
• Some programming languages (LISP, SmallTalk,
  Eiffel, Java) have automatic storage reclamation.

5
External Fragmentation

• External Fragmentation occurs when sections of
  the memory have been allocated, and then some
  deallocated, leaving gaps between used memory.
• The heap may end up being many small pieces of
  available memory sandwiched between pieces of
  used memory.
• A request may come for a certain amount of
  memory, but perhaps no block of memory is big
  enough, even though there is plenty of actual
  space in memory.

6
Internal Fragmentation

• Internal Fragmentation occurs when the memory
  allocated to certain processes or data is too
  large for its contents.
• Here space is wasted even though its not being
  used.

7
Sequential Fit Methods

• When memory is requested a decision needs to be
  made about which block of memory is allocated to
  the request.
• In order to discuss which method is best, we need
  to investigate how memory might be managed.
• Consider a linked list, containing links to each
  block of available memory.
• When memory is allocated or returned, the list is
  rearranged, either by deletion or insertion.

8
Sequential Fit Methods

• First Fit Algorithm,
• Here the allocated memory is the first block
  found in the linked list.
• Best Fit Algorithm,
• Here the block closest in size to the requested
  size is allocated.
• Worst Fit Algorithm,
• Here the largest block on the list is allocated.
• Next Fit Algorithm,
• Here the next available block that is large
  enough is allocated.

9
Comparing Sequential Fit Methods

• First Fit is most efficient, comparable to the
  Next Fit. However there can be more external
  fragmentation.
• The Best Fit algorithm actually leaves very small
  blocks of practically unusable memory.
• Worst Fit try to avoid this fragmentation, by
  delaying the creation of small blocks.
• Methods can be combined by considering the order
  in which the linked list is sorted if the
  linked list is sorted largest to smallest, First
  Fit becomes the same as Worst Fit.

10
Non-Sequential Fit Methods

• In reality with large memory, sequential fit
  methods are inefficient.
• Therefore non-sequential fit methods are used
  where memory is divided into sections of a
  certain size.
• An example is a buddy system.

11
Buddy Systems

• In buddy systems memory can be divided into
  sections, with each location being a buddy of
  another location.
• Whenever possible the buddies are combined to
  create a larger memory location.
• If smaller memory needs to be allocated the
  buddies are divided, and then reunited (if
  possible) when the memory is returned.

12
Binary Buddy Systems

• In binary buddy systems the memory is divided
  into 2 equally sized blocks.
• Suppose we have 8 memory locations
• 000,001, 010, 011, 100, 101, 110, 111
• Each of these memory locations are of size 1,
  suppose we need a memory location of size 2.
• 000, 010, 100, 110
• Or of size 4,
• 000, 100
• Or size 8.
• 000
• In reality the memory is combined and only broken
  down when requested.

13
Buddy System in 1024k memory
14
Sequence of Requests.

• Program A requests memory 34K..64K in size
• Program B requests memory 66K..128K in size
• Program C requests memory 35K..64K in size
• Program D requests memory 67K..128K in size
• Program C releases its memory
• Program A releases its memory
• Program B releases its memory
• Program D releases its memory

15
If memory is to be allocated

• Look for a memory slot of a suitable size
• If it is found, it is allocated to the program
• If not, it tries to make a suitable memory slot.
  The system does so by trying the following
• Split a free memory slot larger than the
  requested memory size into half
• If the lower limit is reached, then allocate that
  amount of memory
• Go back to step 1 (look for a memory slot of a
  suitable size)
• Repeat this process until a suitable memory slot
  is found

16
If memory is to be freed

• Free the block of memory
• Look at the neighbouring block - is it free too?
• If it is, combine the two, and go back to step 2
  and repeat this process until either the upper
  limit is reached (all memory is freed), or until
  a non-free neighbour block is encountered

17
Buddy Systems

• Unfortunately with Buddy Systems there can be
  significant internal fragmentation.
• Case Program A requests 34k Memory but was
  assigned 64 bit memory.
• The sequence of block sizes allowed is
• 1,2,4,8,162m
• An improvement can be gained from varying the
  block size sequence.
• 1,2,3,5,8,13
• Otherwise known as the Fibonacci sequence.
• When using this sequence further complicated
  problems occur, for instance when finding the
  buddy of a returned block.

18
Fragmentation

• It is worth noticing that internal and external
  fragmentation are roughly inversely proportional.
• As internal fragmentation is avoided through
  precise memory allocation

19
Garbage Collection

• Another key function of memory management is
  garbage collection.
• Garbage collection is the return of areas of
  memory once their use is no longer required.
• Garbage collection in some languages is
  automated, while in others it is manual, such as
  through the delete keyword.

20
Garbage Collection

• Garbage collection follows two key phases
• Determine what data objects in a program will not
  be accessed in the future
• Reclaim the storage used by those objects

21
Mark and Sweep

• The Mark and Sweep method of garbage collection
  breaks the two tasks into distinct phases.
• First each used memory location is marked.
• Second the memory is swept to reclaim the unused
  cells to the memory pool.

22
Marking

• A simple marking algorithm follows the pre order
  tree traversal method
• marking(node)
• if node is not marked
• mark node
• if node is not an atom
• marking(head(node))
• marking(tail(node))
• This algorithm can then be called for all root
  memory items.
• Recall the problem with this algorithm?
• Excessive use of the runtime stack through
  recursion, especially with the potential size of
  the data to sort through.

23
Alternative Marking

• The obvious alternative to the recursive
  algorithm is an iterative version.
• The iterative version however just makes
  excessive use of a stack which means using
  memory in order to reclaim space from memory.
• A better approach doesnt require extra memory.
• Here each link is followed, and the path back is
  remembered by temporarily inverting links between
  nodes.

24
Schorr and Waite

• SWmark(curr)
• prev null
• while(1)
• mark curr
• if head(curr) is marked or atom
• if head(curr) is unmarked atom
• mark head(curr)
• while tail(curr) is marked or atom
• if tail(curr) is an unmarked atom
• mark tail(curr)
• while prev is not null and tag(prev) is 1
• tag(prev)0
• invertLink(curr,prev,tail(prev))
• if prev is not null
• invertLink(curr, prev, head(prev))
• else finished
• tag(curr) 1
• invertLink(prev,curr, tail(curr))
• else invertLink(prev,curr,head(curr))

25
Sweep

• Having marked all used (linked) memory locations,
  the next step is to sweep through the memory.
• Sweep() checks every item in the memory, any
  which havent been marked are then returned to
  available memory.
• Sadly, this can often leave the memory with used
  locations sparsely scattered throughout.
• A further phase is required compaction.

26
Compaction

• Compaction involves copying data to one section
  of the computers memory.
• As our data is likely to involve linked data
  structures, we need to maintain the pointers to
  the nodes even when their location changes.

B
C
B
C
C
A
A
A
A
B
B
B
C
C
C
27
Compaction

• compact()
• lo bottom of heap
• hi top of the heap
• while (lo lt hi)
• while lo is marked
• lo
• while hi is not marked
• hi--
• unmarked cell hi
• lo hi
• tail(hi--) lo //forwarding address
• lo the bottom of heap
• while(lo lthi)
• if lo is not atom and head(lo) gt hi
• head(lo) tail(head(lo))
• if lo is not atom and tail(lo) gt hi
• tail(lo) tail(tail(lo))
• lo

28
Incremental Garbage Collection

• The Mark and Sweep method of garbage collection
  is called automatically when the available memory
  resources are unsatisfactory.
• When it is called the program is likely to pause
  while the algorithm runs.
• In Real time systems this is unacceptable, so
  another approach can be considered.
• The alternative approach is incremental garbage
  collection.

29
Incremental Garbage Collection

• In Incremental Garbage collection the collection
  phase is interweaved with the program.
• Here the program is called a mutator as it can
  change the data the garbage collector is tidying.
• One approach, similar to the mark and sweep, is
  to intermittently copy n items from a fromspace
  to a tospace, to semispaces in the computers
  memory.
• The next time the two spaces are switched.
• Consider what are the pros and cons of
  incremental vs mark and sweep?
