Wasteform Evolution Studies Methods and Observations

1
Wasteform Evolution Studies Methods and
Observations
Presented by Ed Butcher Encapsulation, Waste
Science and Analytical Team
2
Overview

• Research, Development and Implementation Work
• Product Evaluation Task Force/Programme
• Longevity Studies on Full Scale Real Time Aged
  Samples
• Additional Underpinning Studies at the
  Immobilisation Science (ISL)
• Legacy Waste streams
• Ongoing and Potential Future Work

3
Waste Management Life Cycle

• Encapsulation process
• Engineered Storage
• Transport and handling
• Repository Storage

4
Phased Approach to PETF/PEP Encapsulation
Programmes

• Phase 1 Waste characterisation. Simulant
  definition. Evaluation of range of matrix
  options
• Phase 2 Selection of preferred encapsulation
  matrix by physical testing of most favourable
  options from phase 1 study.
• Phase 3 Practical studies to determine the
  product properties of reference encapsulated
  wastes up to 90 days curing
• Phase 3a Extension of timescales of certain Phase
  3 studies to 360 days curing.
• Phase 4 Detailed Practical studies which define a
  range of acceptable formulations (envelope)
  for encapsulating waste

5
Parameters Assessed

• Physical Properties
• Fluidity, setting, working time,
• Bleed
• Strength development versus time
• Dimensional stability
• Impact and fire testing
• Generic longevity issues
• Radiation Stability
• Cement ageing
• Corrosion reactions

6
Magnox
7
Waste Encapsulant Interactions

• Reactive metals
• Magnox
• Acute versus chronic corrosion rates
• Temperature
• Water Content
• Swarf versus fin
• Precorrosion of magnox
• Infilling effects
• Acceptable expansion
• Loadings

8
Assessment of Full Scale - Aged samples

• Objectives
• Analysis of aged inactive samples to increase the
  understanding of wasteform evolution and provide
  additional data on stability
• Products assessed
• WPEP Ferric flocs
• MEP - Magnox
• WEP - Fuel hulls and BaCO3
• WTC Compacted PCM wastes

9
Available Samples

• Approximately 100 full-scale inactive samples
  stored in Cumbria.
• Representative of all plant products,
• 10 to 15 years, similar in age to plant packages,
• Samples have been stored under various conditions
  but generally at the warehouse conditions for
  last 9 years,
• Many of the samples have been sectioned,
• Few have been capped and lidded, and many do not
  have s/s drum,
• Can be considered a conservative comparison

10
Sampling

• 50mm diameter diamond drilled cores
• Stored - prevent oxidation, carbonation, etc
• Wet cored to depth

11
Encapsulated floc Product
12
Typical Solids drum
13
Testing techniques

• Physical and Chemical
• Visual
• Cracking
• Carbonation
• Acid neutralisation capacity (ANC)
• Equilibrium extraction
• Permeability / Porosity

• Instrumental
• SEM Electron Microscopy
• XRD
• TGA Thermal Analysis

14
Characterisation
Initial Characterisation

• Logging of cores physical characteristics,
• Logging of bore hole to identify historic faults,
• Bulk Density, Specific Gravity, Moisture content
  for moisture density relationships - porosity,
  degree of saturation,
• pH and redox profiles through low Liquid/Solid
  ratio extraction, and carbonation profiles using
  standard indicator method, and
• ANC profiles to indicate degree and form of
  alkalinity present.

15
Characterisation
Instrumental Characterisation

• Analysis of grout by SEM with elemental analysis
  using energy dispersive x-ray spectroscopy (EDS),
• Analysis of grout with x-ray diffraction (XRD)
  analysis to investigate CSH incorporation, and
• Thermogravimetric Analysis (TGA) of cores to
  confirm/refute presence of phases (e.g., Ca(OH)2).

16

• Results
• A selection

17
Physical characterisation

• The bulk density of wasteforms consistent
  throughout with little evidence of densification
  at depth.
• Porosity decreased over time.
• Moisture content remains consistent throughout
  wasteform generally 100 saturated - no
  significant desiccation.
• Slight carbonation of wasteforms 0-3mm, while
  lt35mm in cap.

18
Physical characterisation

• Flocs - one sample contains the only internal
  cracks found - probably due to handling methods
  and removal of paddle.
• Investigated with SEM

19
Scanning Electron Microscopy of cracks

• Historic fracture found -covered in ettringite
  which degrades in the presence of CO2.
• Suggests fracture is isolated from atmosphere
  cracks self sealing.

20
WTC products

• No sign of degradation of waste
• No sign of corrosion of puck walls
• Corrosion visible occurred after slicing

21
WTC core
22
Detail of WTC Puck Core
23
Physical characterisation - capping key

• IDM and Hulls - very good key of cap to matrix
• Magnox - less good keying of cap

24
Centrifuge Cake Cap
25
Physical characterisation summary

• Samples in good condition
• No significant desiccation
• Very little cracking observed - seems to be
  repaired
• Permeability / porosity reduced with ageing

26
Chemical Characteristics

• pH generally ranging from 11.92 to 12.32, below
  Ca(OH)2 saturation for the ambient temperature,
  and ANC indicates very little free Ca(OH)2 exists
  in all PFA/OPC wasteforms.
• EH ranging from 123.5 to 316.5 mV for PFA/OPC
  blend. Indicating that oxidising conditions
  prevail through selection of the PFA blended
  grout.
• EH ranging from -100.7 to 7.0 mV for BFS/OPC
  blend. Indicating reducing conditions maintained
  through selection of BFS blended grout.

27
Acid neutralisation capacity
Magnox swarf drum showing cap and matrix
28
Acid neutralisation capacity
Floc drum
29
Carbonation

• Phenolphthalein test - purple pHgt9.2
• Caps - see significant carbonation up to 35mm
• Matrix (including PFA of flocs) lt 3mm

Al Hulls (GR/93/44) grout/cap interface
30
Summary of Results

• Wasteforms all have significant buffering
  (gt4eq/kg) to pH9. Relates to a 1 kg sample
  capable of neutralising 40,000 L of pH 4 mineral
  acid.
• Carbonation of cap lt35mm,
• Carbonation of matrix (including flocs) lt3mm

31
SEM

• Normal calcium silicate hydrate field.
• Relatively dense matrices.
• Little hydration of large BFS particles in BaCO3
• Significant proportion of flyash remains
  available in WPEP wasteforms.
• Magnox samples showed little corrosion product
  except in originally water filled porosity
  adjacent to the Magnox.

32
Magnox Infill
Fresh Magnox in Grout GR/91/242
33
Summary of instrumental results

• XRD and TGA did not uncover any unexpected
  phases.
• Confirms carbonation observations
• Little lime present - little support for further
  pozzolanic reactivity
• BFS - little hydration of large particles in
  BaCO3
• No unexpected phases, reactants all consumed -
  product in virtual steady state

34
ISL - Encapsulation of Ferric Flocs

• Utilises five flocs reflecting the range of
  materials processed in WPEP
• Assessment in three stages
• characterisation of materials
• assessment of effect of pretreatment
• effect of cementation of floc material
• Identified phases formed
• CSH, calcium hydroxide, sulphate phases plus iron
  substituted CSH, CSH with adsorbed iron
• Floc chemically immobilised with in encapsulant
  matrix

35
ISL Corrosion of Metals in Composite Cements

• Assessing effect of
• metal type steel, aluminium and Magnox
• cement composition
• temperature
• time
• Identification of reaction products at
  encapsulant- metal interfaces

36
ISL - Effect of BaCO3 on Cement Hydration

• Examination of a range of blended cement
  compositions
• Effect of temperature on microstructure and
  phases formed
• BaCO3 simulant for WEP wastes
• Presence of unreacted slag at 720 days
• Reactions of BaCO3 with slag and cement

37
Legacy Wastes

• Multiple component waste streams
• Expected to be retrieved as highly heterogeneous
  materials
• Treatment systems will build on the knowledge of
  the behaviour of the wastes generated from
  research, development and operations
• Annulus double skinned box
• Option to fill annulus and also rework boxes
  during product finalisation stage

38
Ongoing Work and Future Work

• Project support work for legacy plants
• Legacy Magnox wastes
• Ongoing uranium corrosion trials in range of
  matrices
• Alternative cement systems
• Generic Research
• Water distribution with time in grouted wastes in
  relation to product evolution

39
Conclusions Aged Wasteforms

• Confirms validity of earlier work measuring
  properties over shorter timescales during the PEP

• Quality of products still very good, no
  significant changes observed in 10 years. More
  evidence for satisfactory longer term quality.
• No significant desiccation or carbonation even
  after gt10 years of storage in pessimistic
  conditions. Only two cracks found, one was
  investigated and appeared to have resealed itself.

40
Conclusions Aged Wasteforms

• Moisture, density, porosity and degree of
  saturation very consistent, throughout wasteform
• Wasteforms have a mature, relatively porous
  matrix, with no evidence of source of lime to
  support further pozzolanic reactivity.
• Wasteform reaching / reached a steady state.

41
Conclusions

• ISL based research work provides additional
  underpinning which correlates with PEP and aged
  wasteform observations
• Experience and data generated feeds into the
  legacy waste development trials

42
Options not available !

• Technology Readiness Level 0?

43
Acknowledgements

• Rob Caldwell
• Drs Claire Utton, Nick Collier, Anthony Setiadi
  and Neil Milestone and John Sharp at ISL
• Hugh Godfrey, Newton Bowmer, Drs Steve
  Palethorpe and Mike Angus at NNL
