Reinforcement Learning

1
Reinforcement Learning

• Ruti Glick
• Bar-Ilan university

2
learning

• result of interaction between an agent and the
  world
• Percepts received by an agent should be used not
  only for acting, but also for improving the
  agents ability to behave optimally in the future
  to achieve the goal.

3
Supervised Learning

• Learn from example
• E.g. Decisions tree
• Environment provide input / output pairs
• Learn functions and probability models
• You can think it as if there is a kind teacher

4
Supervised Learning

• Problems
• Difficulties in supplying large number of
  examples
• Example
• Train robot to juggle
• Board state in chess

5
Reinforcement learning

• Agent receives some evaluation of its action
• not told of which action is the correct one to
  achieve its goal

6
Example play chess

• Supervised Learning
• Gets examples of board state best move in this
  state
• Reinforcement learning
• Tries random movements
• Learn about environment
• How board will looks like after performing the
  action
• What the opponent will do
• Must get rewards / reinforcement

7
Types of Reinforcement 1

• Positive Reinforcement
• pleasurable consequence administered after a
  desired behavior
• strengthens behavior
• e.g. praising a dog after it performs a trick
• Extinction
• withholding positive reinforcement following an
  undesirable behavior
• reduces behavior
• e.g. imposing early curfew on a child who stayed
  out too late

8
Types of Reinforcement 2

• Punishment
• an unpleasant consequence administered following
  an undesirable behavior
• reduces behavior
• e.g. a choke chain for a dog
• Negative Reinforcement
• withholding an unpleasant consequence following a
  correct behavior
• strengthens behavior
• e.g. a boxer learning to block a jab

9
Reinforcement Schedules 1

• Continuous Reinforcement
• every behavior is reinforced
• Partial Reinforcement
• not every behavior reinforced
• Fixed interval fixed time interval passes
  between reinforcements
• Variable interval time interval varies between a
  min and max
• Final Reinforcement
• At the terminal states

10
Reinforcement Schedules 2

• Continuous schedule
• results in faster learning
• but fastest extinction if a reinforcement is
  missed
• Variable schedule
• results is most effective for developing more
  permanent behavior

11
Properties 1

• Accessible / inaccessible environment
• In accessible state can be identified by
  percept
• Otherwise agent must keep trucking after
  environment
• Exist knowledge
• Does agent have knowledge of environment and
  actions effects?
• If no has to learn the model
• Rewards - Schedules
• When does the agent get them?

12
Properties 2

• Rewards type
• Components of actual utility
• Score in ping pong
• Dollars on betting
• Hints fot utility
• bad dog
• hot
• Learning type
• Passive or active

13
Passive / active learner

• Passive learner
• Watches the world goes by
• tries to learn utility of being in varied states
• Active learner
• Acts using its learned information
• Must experience as mush as possible the
  environment

14
Agents types

• Utility - based agent
• Learns utility of states
• Use it to select best action
• Must know the model of environment
• E.g. in backgammon must know legal moves ant its
  effect
• Q-learning agent
• Learn expected utility of taking a given action
  in a given state
• Doesnt need to know the effect but legal moves
• Cant look ahead
