Space Partitioning

1
Space Partitioning

• Computer Graphics

2
What is Space Partitioning?

• A division of 3D space into distinct regions
• Specifically, a tree data structure is used to
  divide up the world in a hierarchical manner
• The tree leaf nodes usually contain pieces
  (triangles) of the world
• Each leaf holds onto the polygons that are in its
  sub-piece of the world

3
Why Perform Space Partitioning?

• Speed
• For example, an accurate model of a Boeing-777
  contains over 500M triangles
• You do not want to send 500M tri down the
  rendering pipeline
• We have seen various mapping techniques to make
  the model look good with less triangles
• But we can also cut down on the number of
  triangles by only sending triangles down the
  pipeline that are in the field of view of the
  camera
• By dividing the world into pieces we can
  cull/clip on large scale rather than per triangle
  as the rendering pipeline does

4
Types of Space Partitioning

• The two main types we will explore are
• Octrees
• Binary Space Partition (BSP) trees
• However, in the process we will also cover
• Frustum culling
• Bounding Volumes (BVs)
• Potentially Visible Sets (PVS)
• Scene Graphs

5
Frustum Culling

• In the classic rendering pipeline front-facing
  triangles are clipped against the Frustum
• All 3 vertices outside the volume implies the
  triangle is culled (not sent down the pipeline)
• The problem with this technique is that it is
  triangle-based and doesnt take into account
  spatial coherence
• All the triangles for a given object lie in about
  the same position in space

6
Frustum Culling

• Why is spatial coherence important?
• If an object is out of the Frustum then so are
  all its triangles
• If we could perform the Frustum check per object
  then we could cull all the objects triangles at
  the same time with a single test
• Note that this is a software test, but only 1 is
  made rather than 10s/100s/1000s of hardware tests

7
Frustum Culling

• How do we perform the test in software?
• First we need to find the planes of the Frustum
• Recall that there are 6 planes (near, far, left,
  right, top, bottom)

8
Frustum Culling

• If we can find the plane equation for each then
  we can test to see which side of the plane a
  point lies
• Recall the plane eqn is Ax By Cz D 0
• Where (A, B, C) is the normal of the plane
• If we have a point (x, y, z) and we plug it into
  this equation, we get
• Positive on the normal side of the plane (in
  front)
• Zero on the plane
• Negative on the non-normal side of the plane
  (behind)
• A point must be in front of all planes for it to
  be in the Frustum

9
Frustum Culling

• So, how do you find the Frustum planes?
• After setting up the Camera, get the modelview
  matrix and the projection matrix
• glGetFloatv( GL_MODELVIEW_MATRIX, mod )
• glGetFloatv( GL_PROJECTION_MATRIX, proj )
• Note that you need both because the modelview
  sets up the camera position and orientation
  whereas the projection sets up the shape of the
  Frustum
• Then multiply the two matrices together
• clip (mod) x (proj)

10
Frustum Culling

• The A, B, C, and D values can then be extracted
  from the clip matrix
• As an example the right plane is
• A clip 3 - clip 0B clip 7 - clip 4C
  clip11 - clip 8D clip15 - clip12
• These plane values are then normalized so /-
  distances from the plane are correct
• Each component (A-D) is divided by sqrt(A2 B2
  C2)

11
Frustum Culling

• This sounds like a lot of work
• Not coding, but execution time work
• But keep a couple of things in mind
• The Frustum plane equations only need to be
  recalculated whenever the camera moves
• We are going to test an entire object rather than
  a single point
• In particular, we will test sphere and cube
  objects

12
Frustum Culling

• Why just spheres and cubes?
• They make nice Bounding Volumes (BVs)
• A Bounding Volume is a simplified shape that
  encloses an entire complex object
• If the Frustum test against the BV fails then the
  entire complex object in the BV is not in the
  Frustum
• The advantage is that tests against simple shapes
  are computational much easier to perform than
  tests against complex shapes

13
Frustum Culling

• Sphere testing
• A sphere is defined by a center point and a
  radius
• Part of the sphere is still in front of the plane
  (and thus, it cant be culled) even if the center
  point is up to radius units on the back side of
  the plane
• Recall that Ax By Cz D is the distance from
  the point (x, y, z) to the plane
• Thus, we keep the sphere if the sphere center
  plugged into this equation produces values gt
  -radius for all 6 plane equations
• The point test is the same, but with gt 0

14
Frustum Culling

• Cube test
• A cube consists of 8 vertices
• Usually pass in as a center location and a size
• We could test to see if any of the 8 cube
  vertices are within the Frustum (i.e. test each
  vertex against all 6 planes)
• However, this leads to problems when the cube is
  bigger than the Frustum all 8 corners are
  outside the Frustum, but the cube contents should
  be drawn
• False negatives cube culled when it shouldnt be

15
Frustum Culling

• Instead we reverse the order and test all 8
  points against a single plane
• If all are to the back side of the plane then the
  cube is not visible and we can cull it
• If any are in front, then we move onto the next
  plane
• If it passes all 6 planes then we keep it
• However, this can lead to false positives (see
  figure)
• We let it though and simply let the card cull it
  on a triangle by triangle basis

16
Frustum Culling

• So what sort of speed up do you get?
• It depends on several factors
• How big the Frustum is (especially the far plane)
• How many object are in the scene and how they are
  distributed
• How complex each particular object is
• Check out gametutorials Frustum culling tutorial

17
Octrees

• Octrees are a space partitioning data structure
• We saw Octrees before in the context of modeling
• In modeling the leaf nodes were either filled or
  empty
• In space partitioning the leaf nodes contain a
  list of triangles that are in that sub-section of
  space
• The process
• A single cube is placed around the entire world
• If the cube contains too many triangles, then the
  cube is sub-divided into 8 smaller axis-aligned
  cubes
• Recurse until we hit the stopping condition

18
Octrees
19
Octrees

• When do you stop sub-dividing?
• When the cube contains less than a specified
  number of triangles
• When the sub-division depth has reached a maximum
• When the total number of cubes in my octree has
  reached a maximum number

20
Octrees

• What happens to triangles that cross a cube
  boundary?
• Place the object in the largest box that fully
  contains it
• Not efficient in that a small object can be
  placed in a large bounding box if it lies
  directly on the boundary
• Implies that not all triangles are stored in the
  leaf nodes
• Split the triangle
• Increases the number of primitives in the scene
• Place the triangle in both sub-divisions
• As the triangles from each sub-division are sent
  to the renderer we need to mark them so we dont
  draw them twice
• Makes Octree editing, such as deletion, is more
  difficult

21
Octrees

• So how to Octrees help us?
• We can combine Octrees with Frustum culling
• The Octree cubes are Bounding Volumes for the
  triangles in their region of space
• We only need to send the triangles contained in
  the cubes that pass the Frustum test to the
  rendering pipeline

22
Octrees

• This leads to a process called Hierarchical
  Frustum Culling
• Starting with the root node of the Octree, test
  the Octree cube against the Frustum
• If not in frustum, then prune children
• If in frustum, then
• Send any contained triangles to renderer
• Recurse on each of the children
• Demo Octree2 and Octree3 from gametutorials

23
BSP Trees

• The idea is much the same as with Octrees
• However, the space is repeatedly split into 2
  parts (hence the name binary space partition)
  by a given splitting plane
• Octrees always use cubes
• There are two variants
• Axis-Aligned
• Polygon Aligned

24
Axis-Aligned BSP Trees

• Starting with a bounding box around the entire
  world, split it into 2 parts with an xy, xz, or
  yz splitting plane
• Divide all the triangles between the two
  half-spaces
• Triangles that intersect the splitting plane can
  be dealt with the same way we did with Octrees
• Recursively continue thesubdivision process
  until astopping criteria is reached
• Note that each successivesubdivision only splits
  its ownhalf-space

25
Axis-Aligned BSP Trees

• The interesting part is how to decide what axis
  and where along that axis to split
• Suggestions on how?
• Hint how does all this relate to what you
  learned in cs255 about merge sort vs. quick sort

26
Polygon-Aligned BSP Trees

• In this version, a polygon is chosen as the
  divider polygon
• This polygon is part of a plane and it is this
  plane that is used as the splitting plane

27
Polygon-Aligned BSP Trees

• Just as with Axis-Aligned BSP trees the most
  important choice is the selection of the polygon
  divider
• There are two main issues to consider
• How balanced is the tree
• How many extra triangles did we have to make
  because of triangle splitting
• It is a debatable question as to which is better
• A balanced tree with lots of extra triangles
• A unbalanced tree with fewer extra triangles
• However most people pick the unbalanced tree with
  fewer splits of triangles

28
Polygon-Aligned BSP Trees

• Generating an optimal BSP tree requires trying
  every possible splitting combination
• The problem is that this is a O(n!) algorithm
• Recall that 20! 2,432,902,008,176,640,000
• The next best option is to pick the best splitter
  at each level
• Divide-and-Conquer with a Greedy selection of the
  splitter at each level
• This is an O(n2) algorithm
• This is the option that most games use
• However, it is still pre-computed and saved in a
  file

29
BSP Trees

• Hierarchical Frustum Culling can be used fairly
  easily with Axis-Aligned BSP trees
• Very similar to how it was used for Octrees since
  each region is rectangular
• However, for Polygon-Aligned BSP trees testing is
  more complex
• The region (leaf or interior) in question is
  convex, so one could test all the corners of the
  region the same way the 8 corners are tested for
  rectangular regions
• Or a bounding box of the region can be tested
• Quicker test, but more false positives (passed
  frustum test when not actually in the fustum

30
BSP Trees

• However, Polygon-Aligned BSP trees have their
  advantage in visibility
• Allow us to easily perform a visibility ordering
• Allow us to align splitting planes along walls
  which may not be axis aligned

31
BSP Tree Visibility

• In complex indoor scenes, not only do we have
  lots of geometry that is not in the cameras
  frustum but we also have lots of geometry that is
  hidden by walls
• That is, the frustum might extend through many
  walls
• Frustum culling would simply select all nodes it
  intersected and send them to the renderer where a
  Z-buffer technique is used to handle the
  occlusion in the normal way
• With Polygon-Aligned BSP Trees we can determine
  visibility ordering w.r.t. a given camera
  position
• Works in linear time
• Works for any given camera position

32
BSP Tree Visibility

• In order to determine the visibility ordering
• First, build the BSP tree for the scene
• Usually done off-line
• For a static scene
• Dynamic scenes objects are usually handled
  separately
• Second, insert a viewpoint into the scene
• Third, perform a in-order traversal of the tree
  to determine the polygon order
• Recall in-order traversals mean process child,
  process node, process other child

33
BSP Tree Visibility

• What order should we process the children in?
• To obtain a back-to-front ordering
• Process the far-side child first
• Relative to the location of the camera
• To obtain a front-to-back ordering
• Process the near-side child first

34
BSP Tree Visibility

• Back-to-front C1, B, D, A, C2, E
• Front-to-back E, C2, A, D, B, C1

35
BSP Tree Visibility

• Back-to-front ordering leads to a version of the
  painters algorithm
• This doesnt suffer from the intersecting problem
  seen previously in the painters algorithm
• Any polygons that would have intersected have now
  been split into multiple pieces
• However, the painters algorithm is still really
  slow
• Pixels will be drawn only to be overdrawn by
  closer tris
• Often 10x overdraws (Michael Abrash of Quake
  frame)
• Overdraw amount varies so framerate is not stable
• Overdraw problems increase with scene complexity

36
BSP Tree Visibility

• Front-to-back has no overdraw problems
• Each pixel is drawn exactly once
• But we need to find a way to not overwrite a
  pixel once it has been drawn
• Could use the normal Z-buffer technique
• However, this is overkill since we will never
  need to replace a value in the Z-buffer with a
  newer one
• Could use a Stencil buffer technique
• Stencil filters pixels that have already been
  drawn
• As new pixels are drawn, the stencil buffer is
  updated
• This technique is usually faster than
  back-to-front

37
Stencil Buffer

• A Stencil Buffer is another buffer like the color
  (frame) buffer and the Z-buffer
• On most hardware this is an 8 bit buffer
• The Stencil Test is a test that occurs
  immediately before the Z-buffer test
• If the Stencil Test fails, the fragment is
  discarded rather than passed on to the Z-buffer
• Fragment wont show up in the color buffer either

38
Stencil Buffer

• The Stencil Test is a test of the value currently
  stored in the Stencil Buffer
• The Stencil Function controls the type of Stencil
  Test to perform

39
Stencil Buffer

• There are 3 possible outcomes of the combined
  Stencil and Z-buffer tests
• Stencil Test fails
• Stencil Test passes, Depth Test fails
• Stencil Test passes, Depth Test passes
• The Stencil Operation lets you specify what
  happens to the Stencil Buffer values in each of
  these cases

40
Stencil Buffer

• The possible Stencil Operations are
• GL_KEEP ? old value kept
• GL_ZERO ? value replaced by zero
• GL_REPLACE ? value replaced by given reference
  value (allows setting to a specific value)
• GL_INCR ? value incremented by 1
• GL_DECR ? value decremented by 1
• GL_INVERT ? value bitwise inverted

41
Stencil Buffer

• The Stencil buffer/test are only performed if
• The Stencil buffer is enabled
• The underlying hardware/drivers support it
• The stencil buffer is usually used as a mask
• Example creating a non-rectangular windshield
  for a first-person driving game
• Store 1s in the stencil buffer pixels where you
  wish the windshield to be and then set the
  stencil test to render if not equal to 0

42
BSP Tree Visibility

• Note that the visibility ordering is not directly
  related to either
• Viewing direction
• Both A and B appear in the visibility ordering
  even though camera is facing the other direction
• Distance of the polygons from the viewpoint
• In back-to-front ordering, B is before A in both
  figures even though A is sometimes farther than B
  from the camera

A
B
43
BSP Tree Visibility

• The previous slides have assumed that the BSP
  tree will continue dividing until every polygon
  is used as a splitting plane
• However, in indoor scenes we often want to use
  BSP trees aligned with the walls to provide
  visibility on a room level and then let the
  normal Z-buffer algorithm handle objects within
  the room
• That is, a hybrid visibility scheme

44
Portals

• World is divided up into Cells and Portals
• Cells are convex regions
• Could be BSP tree leaves
• Portals are doorways/windows between the Cells

45
Portals

• Basic algorithm
• Start in the cell that contains the camera
• Equating Cells to BSP tree leaves helps here
• Perform a frustum check against all objects in
  the current cell to determine what is visible
• If any portals are visible (in frustum), add the
  connecting cell to the list of cells to process
• Continue until all visible cells have been
  rendered

46
Portals

• An optimization of the previous algorithm is
  frustum reduction
• When a portal is visible, it means the cell it
  leads to is visible, but only partially, because
  the camera can only see this cell through the
  portal
• Thus, the frustum can be reduced in the new cell
• Cuts down the number of objects in the cell that
  are sent to the renderer
• And cuts down on the number of visible portals
  seen which reduces the amount of recursion

47
Portals

• The reduced frustum is created by planes from the
  camera through the portal edges
• For portals with vertical walls, it turns into a
  2D issue of casting rays through points

48
PVS

• Techniques that were tried and rejected for
  large-scale culling in Quake
• Pure Z-buffering
• Painters algorithm
• Beam tree
• Subdividing raycasting
• Edge or Span sorting
• Portals
• Direct visibility extraction from BSP
• Instead Quake went with PVS

49
PVS

• Potentially Visible Sets (PVS) involve
  pre-computing visibility information from the BSP
  tree
• That is, first divide up the world using a BSP
  tree, storing all the polygon faces in the leaf
  nodes
• Next, perform off-line visibility checks to
  determine which leaf nodes are visible from which
  other leaf nodes ? creating a 2D visibility
  matrix
• Visible from anywhere in the source leaf node
• The 2D visibility matrix information, called a
  Potentially Visible Set (PVS) is then used to
  cull large parts of the BSP tree away when
  rendering

50
PVS

• The PVS is used by first descending the BSP tree
  with the camera coordinates to determine in which
  leaf node the camera resides
• Then the PVS is consulted to determine other leaf
  nodes that may also need to be rendered
• This can then be combined with frustum culling to
  test the bounding boxes of these leaf nodes with
  the frustum
• And finally, the polygons from the surviving leaf
  nodes are sent to the renderer

51
PVS

• Creating the PVS is a difficult task
• Very time-consuming
• Various way to create it, but often portals are
  used to create view-independent visibility maps
• Note that the previously discussed portal
  information was view-dependent (known camera
  position/orientation)
• If we are going to pre-compute visibility, we
  need view-independent information

52
PVS

• The entire cell of the potential camera (blue) is
  used as the starting cell
• Lines (of sight) are constructed between portal
  edges to determine which cells are visible
• There are more exampleson p.298-301 of Gamesbook

53
PVS

• The PVS can be built from these portal
  constructed visibility maps by using every leaf
  node as a potential starting position and
  recording all the other leaf nodes that are
  visible from the starting leaf

54
Collision Detection

• When objects are moving we need to determine if,
  when, and where they collide
• Each question gets harder so solve (both
  computationally and theoretically)
• To answer when one also needs to know if
• To answer where one also needs to know when
• There are methods that solve all at once, but you
  cant solve each successive one without the prior

55
Collision Detection

• The brute force solution is to test every
  triangle of each object against every triangle of
  every other object
• The problem O(n2 m2)
• n is the number of objects
• m is the number of triangles per object
• So it becomes infeasible as scene complexity or
  object complexity increases

56
Collision Detection

• The solution is two-fold
• Space Partitioning
• Reduces the n2 term
• Bounding Volumes
• Reduces the m2 term

57
Collision Detection

• We have already seen several Space Partitioning
  schemes
• Octrees
• BSP Trees
• An object can only collide with another object
  that is in the same part of space
• This is sometimes called a collision group

58
Collision Detection

• The problem with using space partitioning schemes
  is that one needs to keep the partitions updated
  as objects move through space
• It certainly can be done, it just takes time
• Loose Octrees hold an advantage here because of
  their fast insert/delete times
• Often, spatial coherence can be used to quickly
  determine the objects new node
• For collision detection of a moving object with
  only static objects (architectural) the problem
  is easier since one can avoid updating the tree
• Keep only the static objects in the tree and
  dynamically determine the moving objects node

59
Collision Detection

• Bounding volumes simplify objects
• An object containing 10K triangles can be
  represented with a single sphere
• Makes collision tests much simpler
• However, false positives can occur
• The bounding volumes collide but the objects they
  contain do not
• The standard solution is to use a two-phase
  collision detection scheme

60
Collision Detection

• The two-phase scheme
• Broad phase
• Bounding volumes are used to cull away pairs of
  moving objects that cannot possibly collide
• Leaves some false positives
• Narrow phase
• An exact collision detection method on the pairs
  that survive the culling process
• The particular choice of algorithms for each
  phase can be made independently

61
Collision Detection

• Common Bounding Volumes
• Sphere
• Axis-Aligned Bounding Box (AABB)
• Oriented Bounding Box (OBB)
• Discrete Orientation Polytope (k-dop)
• Pairs of parallel planes

62
Collision Detection

• In deciding which is best, there is a tradeoff
  between bounding efficiency and intersection test
  speed
• Bounding efficiency is how closely the volume
  bounds the actual object
• Higher bounding efficiency reduces false
  positives
• Intersection test speed is controlled by the
  complexity of the shape
• Sphere/Sphere intersection is much faster than
  kDOP/kDOP intersection

63
Collision Detection

• One also needs to worry about how to update these
  volumes for moving objects
• Obviously there is the issue of translation which
  is easily handled by translating the BV
• However, the problems can occur when the objects
  can rotate
• This is a major problem for AABBs which cant be
  rotated and need to be recalculated
• But not a issue at all for Spheres

64
Collision Detection

• Hierarchies of bounding volumes can be used
  instead of a single BV
• Collision detection starts at the top of the
  hierarchy and proceeds downward to the leaf nodes
• The goal is to reduce the number of triangles
  involved in the narrow phase

65
Collision Detection

• There are also many other BVs in use
• Capsules, Lozenges, Cylinders, Ellipsoids, etc.
• It is somewhat surprising that some simple shapes
  such as cylinders should be avoided
• intersection testing against a moving cylinder
  is extremely complicated and somewhat expensive
  process

66
Collision Detection

• When implementing collision detection, one needs
  to know the potential shapes involved
• There are sets of (sometimes complex) math
  equations for intersecting almost any shape
  against another
• Eberlys 3D Game Engine Design is full of them
• You probably want to keep the shapes in your
  system to a minimum so you dont end up with an
  explosion of testing code

67
Collision Detection

• Some rules of thumb when implementing
  intersection routines (from real-time rendering)
• Perform computations that might trivially reject
  or accept various types of intersections early
• Exploit results from previous tests
• Postpone expensive calculations (esp. trig
  functions) until they are truly needed
• If a single object is being tested against many
  other objects look for precalculations that can
  be done once
• Watch out for floating-point precision problems

68
Collision Detection

• There are also difficulties associated with
  temporal sampling
• If the velocity of an objects is high with
  respect to the sampling rate for collision
  detection then the objects can pass through each
  other without being detected
• In general, collision will not be detected until
  after the objects has penetrated each other

69
Collision Detection

• To help address the problem of objects passing
  through each other undetected one can use
  adaptive sampling rates
• As objects get closer to each other sample more
  frequently
• How do we determine if objects are getting
  closer?
• Most intersection tests can be made to return
  more than a Boolean, such as a distance
• Use a larger bounding volume to trigger the need
  to sample more often

70
Collision Detection

• What do we do when detection occurs?
• This is often called the collision response
• Recall that most detection occurs after
  penetration
• Some systems simply need to back the objects away
  from each other in the direction opposite their
  direction of travel
• Used to prevent objects from going through walls,
  etc.
• This happens before the scene is rendered so the
  collision is never seen by the user
• Scene rendered
• Objects moved
• Collision detection occurs
• Collision response activated
• Scene rendered

71
Collision Detection

• Other systems that perform more realistic dynamic
  simulations need to bounce the objects off of
  each other in a realistic way
• They need to know the exact time of collision
• To achieve this we need to back time up to the
  point of impact
• Most algorithms produce an estimate of the impact
  time, set the objects to that time, recalculate
  the collision test, and recurse if estimate was
  not accurate enough
• The main problem with this is time cost,
  specifically non-uniform time cost
