Matrix Vector Multiplication Summary

1
Matrix Vector Multiplication(Summary)
2
Parallel Matrix Vector Multiplication

• We want to multiply a matrix by a vector
• If the matrix is m rows and n columns, then the
  vector must be n columns
• Parallelization
• We can divide the vector
• Into vectors of smaller sizes
• Replicate into each processor (vectors require
  less memory)
• We can divide the matrix
• Along the rows
• Along the columns
• Into small blocks

Dividing the data among processors
3
Three Algorithms

• Decompose matrix along rows and replicate the
  vector
• Decompose matrix along columns and divide the
  vector
• Decompose matrix in blocks and divide the vector

NOTE It makes sense to divide up the vector when
the matrix has less rows
4
Analyzing a Parallel Algorithm

• Partitioning
• Communication
• Agglomeration Mapping
• Computational Complexity
• Communicational Complexity
• Scalability

Algorithmic Characteristics
Performance Evaluation
5
Method 1 Matrix divided by RowVector Replicated
9
7
2
5
6
MPI_Allgatherv
7
MPI_Allgatherv
int MPI_Allgatherv ( void
send_buffer, int send_cnt,
MPI_Datatype send_type, void
receive_buffer, int receive_cnt,
int receive_disp, MPI_Datatype
receive_type, MPI_Comm communicator)
8
Agglomeration and Mapping

• Static number of tasks
• Regular communication pattern (all-gather)
• Computation time per task is constant
• Strategy

• Agglomerate groups of rows
• Create one task per MPI process

9
Complexity Analysis

• Sequential algorithm complexity ?(n2)
• Parallel algorithm computational complexity
  ?(n2/p)
• Each processor has n/p rows of width n
• Each inner product takes n(n/p)
• Communication complexity of all-gather ?(log p
  n)
• Gather takes log(p) steps
• Each processor takes n/p elements
• It sends it to p-1 processors
• Total log(p)latency n/p(p-1)/bandwidth
• Overall complexity ?(n2/p log p)

10
Isoefficiency Analysis

• Sequential time complexity ?(n2)
• Parallel communication is all-gather
• Communication complexity
• log(p)latency (n/p(p-1))/bandwidth
• When n is large, message transmission time
  dominates message latency
• Parallel communication time ?(n)
• n2 ? Cpn ? n ? Cp and M(n) n2
• T(1,n)gtCTo(n,p)
• System is not highly scalable

11
Method 1 Matrix divided by ColumnVector
Decomposed
1
0
1
2
2061
1001
0023
2023
12
Getting Columns of the Matrix

• In the memory the matrices are stored as rows
• Let one process handle the I/O
• Read the matrix from memory and distribute it as
  columns

13
MPI_Scatterv
14
Header for MPI_Scatterv
int MPI_Scatterv ( void send_buffer,
int send_cnt, int
send_disp, MPI_Datatype send_type, void
receive_buffer, int
receive_cnt, MPI_Datatype receive_type,
int root, MPI_Comm communicator)
15
Communication

• After calculating inner product, each processor
  sends its entire partial vector to other
  processes

2061
1001
2023
0023
16
Function MPI_Alltoallv
17
Header for MPI_Alltoallv
int MPI_Gatherv ( void send_buffer,
int send_cnt, int
send_disp, MPI_Datatype send_type, void
receive_buffer, int
receive_cnt, int receive_disp,
MPI_Datatype receive_type, MPI_Comm
communicator)
18
Agglomeration and Mapping

• Static number of tasks
• Regular communication pattern (all-to-all)
• Computation time per task is constant
• Strategy

• Agglomerate groups of columns
• Create one task per MPI process

19
Complexity Analysis

• Sequential algorithm complexity ?(n2)
• Parallel algorithm computational complexity
  ?(n2/p)
• Each processor has n/p columns
• Each column has n elements
• Communication complexity?(p nlog(p))
• Scatter takes log(p) steps sends n/p elements
  to (p-1) processors
• Log(p)latency(n/p)(p-1)/bandwidth
• All-to-all
• Option 1 Each process sends a message to the
  rest, sending the
• Destination only the part required
• Number of messages (p-1)
• Total amount sent O(n)
• Complexity ( p-1)latencyn/bandwidth

Total ?(p n2/p )
20
Isoefficiency Analysis

• Sequential time complexity ?(n2)
• Only parallel overhead is all-to-all
• When n is large, message transmission time
  dominates message latency
• Parallel communication time ?(n p log(p))
• n2 ? Cpn ? n ? Cp
• Scalability function same as rowwise algorithm
  C2p

21
Printing the Results Vectors

• In order to view the vector in order of indices,
  only one processor should print it
• This is opposite of scatter a gather operation

9
2
5
7
22
Function MPI_Gatherv
23
Header for MPI_Gatherv
int MPI_Gatherv ( void send_buffer,
int send_cnt, MPI_Datatype
send_type, void receive_buffer,
int receive_cnt, int
receive_disp, MPI_Datatype receive_type,
int root, MPI_Comm communicator)
24
Count/Displacement Arrays

• Scatter, Gather, All to all requires two types of
  count/displacement arrays
• First pair for values being sent
• send_cnt number of elements (always)
• send_disp index of first element (If breaking a
  array)
• Second pair for values being received
• recv_cnt number of elements (always)
• recv_disp index of first element (If joining
  into array)

25
Method 1 Matrix divided into CrossSectionsVecto
r Decomposed
26
Decomposing the Vector
27
Agglomeration and Mapping

• Static number of tasks
• Regular communication pattern (all-to-all)
• Computation time per task is constant
• Strategy

• Agglomerate groups of columns
• Create one task per MPI process

28
Complexity Analysis

• p is a square number
• Each process does its share of computation
  ?(n2/p)
• There are n / ?p n / ?p matrices in each block
• Redistribute b ?( log (? p)(n / ?p ))
• Sending n / ?p information
• Can do it in log (? p) steps (sends it to log (?
  p) processors)
• Reduction of partial results vectors?( log (?
  p)(n / ?p ))
• Sending information log (? p)
• Have to add n / ?p elements
• Overall parallel complexity ?(n2/p log (?
  p)(n / ?p ))

29
Isoefficiency Analysis

• Sequential complexity ?(n2)
• Parallel communication complexity ? (log (?
  p)(n / ?p )) ?(n log p / ?p)
• Isoefficiency functionn2 ? Cn ?p log p ? n ? C
  ?p log p
• This system is much more scalable than the
  previous two implementations
