Cognitive Support for Intelligent Survivability Management

1
Cognitive Support for Intelligent Survivability
Management
Dec 18, 2007
2
Outline

• Project Summary and Progress Report
• Goals/Objectives
• Changes
• Current status
• Technical Details of Ongoing Tasks
• Event Interpretation
• Response Selection
• Rapid Response (ILC)
• Learning Augmentation
• Simulated test bed (simulator)
• Next steps
• Development and Integration
• Red team evaluation

OLC
3
Project Summary Progress Report

• Partha Pal

4
Background

• Outcome of DARPA OASIS Dem/Val program
• Survivability architecture
• Protection, detection and reaction (defense
  mechanisms)
• Synergistic organization of overlapping defense
  functionality
• Demonstrated in the context of an AFRL exemplar
  (JBI)
• With knowledge about the architecture, human
  defenders can be highly effective
• Even against a sophisticated adversary with
  significant inside access and privilege (learning
  exercise runs)

Survivability architecture provides the dials and
knobs, but an intelligent control loop in the
form of human expertswas needed for managing
them
Managing Making effective decisions
What was this knowledge? How did the human
defenders use it? Can the intelligent control
loop be automated?
5
Incentives and Obstacles

• Incentives
• Narrowing of the qualitative gap in automated
  cyber-defense decision making
• Self managed survivability architecture
• Self-regenerative systems
• Next generation of adaptive system technology
• From hard-coded adaptation rules to cognitive
  rules to evolutionary

• Obstacles (at various levels)
• Concept insight (sort of) but no formalization
• Implementation Architecture, Tool capability
  choice
• Evaluation How to create a easonably complex
  context wide range of incidents
• Real system?
• Evaluation how to quantify and validate
• Usefulness and effectiveness
• Measuring technological advancement

6
CSISM Objectives

• Design and implement an automated cyber-defense
  decision making mechanism
• Expert level proficiency
• Drive a typical defense enabled system
• Effective, reusable, easy to port and retarget
• Evaluate it in a wider context and scope
• Nature and type of events and observations
• Size and complexity of the system
• Readiness for a real system context
• Understanding the residual issues challenges

7
Main Problem

• Making sense of low-level information (alerts,
  observations) to drive low-level
  defense-mechanisms (block, isolate etc.) such
  that higher-level objectives (survive, continue
  to operate) are achieved
• Doing it as well as human experts
• And also as well as in other disciplines
• Additional difficulties
• Rapid and real time decision-making and response
• Uncertainty due to incomplete and imperfect
  information
• Widely varying operating conditions (no alerts to
  100s of alerts per second)
• New symptoms and changes in adversarys strategy

8
For Example.

• Consider a missing protocol message alert
• Observable a system specific alert
• A accuse B of omission
• Interpretation
• A is not dead (he reported it)
• Is A lying? (corrupt)
• B is dead
• B is not dead, just behaving badly (corrupt)
• A and B cannot communicate
• Refinement (depending on what else we know about
  the system, the attacker objective..)
• Other communications between A and B
• A svc is dead if the host is dead..
• OS platform and likelihood of multi-platform
  exploits..
• Response selection
• Now or later?
• Many options

related
related
9
Approach
Learn
Stream of events and observations
Interpret
React
React
React
Hypotheses
System
Respond
Actions
Modify parameter or policy

• Multiple levels of reasoning
• Varying spatial and temporal scope
• Different techniques
• The main control loop is partitioned into 2 main
  parts event interpretation response selection

10
Concrete Goals

• A working prototype integrating
• Policy based reactive (cyber-defense) response
• Cognitive control loop for system-wide
  (cyber-defense) event interpretation and response
• Learning augmentation to modify defense
  parameters and policies
• Achieve expert level proficiency
• In making appropriate cyber-defense decision
• Evaluation by
• ground truth ODV operator responses to
  symptoms caused by red team
• Program metrics

11
Current State

• Accomplished quite a bit in 1 year
• KR and reasoning framework for handling
  cyber-defense events well developed
• Proof of concept capability demonstrated for
  various components at multiple levels
• OLC, ILC, Learner and Simulator
• E.g., Prover9, Soar (various iterations)
• Began integration and tackling incidental issues
• Evaluation ongoing (internal external)
• Slightly behind in terms of response
  implementation and integration
• Various reasons (inherent complexity, and the
  fact that it is very hard to debug the reasoning
  mechanism)
• Longer term issue Confidence in such cognitive
  engine? Is a system-wide scope really tenable? Is
  it possible to build better debugging support?
• Taken mitigating steps (see next)

12
Significant Changes
Recall the linear flow using various types of
knowledge? That was what we were planning in
June. This evolved, and the actual flow looks
like the following
Knowledge about attacker goal (bin3)
Knowledge about bad behavior (bin 1) , protocols
and scenarios (bin 4)
Knowledge about info flow (bin 2) and protocols
and scenarios (bin 4)
Process Accusation Evidence
Translation Map Down
Prune (Coherence and proof)
Garbage collect
Build
Refine
accusation
evidence
Constraint network
13
Significant Changes (contd)

• Response mechanism
• Do in Jess/Java instead of Soar
• Issues
• Get the state accessible to Jess/Java
• Viewers
• Dual purpose usability and debugging
• Was Rule driven write a Soar rule to produce
  what to display
• Now get the state from Soar and process

14
Schedule

• Midterm release (Aug 2007) done
• Red team visit (Early 2008)
• Next release (Feb 2008)
• Code freeze (April 2008)
• Red team exercises (May/June 2008)

15
Event Interpretation and Response (OLC)

• Franklin Webber

16
OLC Overall Goals

• Interpret alerts and observations
• (sometimes lack of observations triggers alerts)
• Find appropriate response
• (sometimes it may decide that no response is
  necessary)
• Housekeep
• Keep history
• Clean up

17
OLC Components
Event Interpretation
Response Selection
Summary
responses
accusations and evidence
Learning
History
18
Event Interpretation

• Main Objectives
• Essential Event Interpretation
• Interpreting events in terms of hypotheses and
  models
• Uses deduction and coherence to decide which
  hypotheses are candidates for response
• Incidental Undertakings
• Protecting the interpretation mechanisms from
  attack flooding and resource consumption
• Current status and plans
• Note that items with a are in progress

Event interpretation creates candidate hypotheses
which can be responded to.
19
Event Interpretation Decision Flow
Response Selection
Event Interpretation
generator
Summary
hypotheses
claims
theorem proving
dilemmas
coherence
learning
history
20
Knowledge Representation

• Turn very specific knowledge into an intermediate
  form amenable to reasoning
• i.e. Q2SM sent a malformed Spread Message -gt
• Q2SM is Corrupt

• Create a graph of inputs and intermediate states
  to enable reasoning about the whole system
• Accusations and Evidence
• Hypotheses
• Constraints between A and B
• Use the graph to enable deduction via proof and
  to perform a coherence search

Specific system inputs are translated into a
reusable intermediate form which is used for
reasoning.
21
Preparing to Reason

• Observations and Alerts are transformed to
  Accusations and Evidence
• Currently translation is done in Soar but may
  move outside to keep the translation and
  reasoning separate

Alerts notification of an anomalous event
Accusations generic alert
Observation notification of an expected event
Evidence generic observation
Alerts and Observations are turned into
Accusations and Evidence that can be reasoned
about.
22
Alerts and Accusations

• By using accusations the universe of bad behavior
  used in reasoning is limited, with limited loss
  of fidelity.
• The five accusations below are representative of
  attacks in the system
• Value accused sent malformed data
• Policy accused violated a security policy
• Timing accused send well-formed data at the
  wrong time
• Omission expected data was never received from
  accused
• Flood accused is sending much more data than
  expected

CSISM uses 5 types of accusations to reason about
a potentially infinite number of bad actions that
could be reported.
23
Evidence

• While accusations show unexpected behavior
  evidence is used for expected behavior
• Evidence limits the universe of expected behavior
  used in reasoning, with limited loss of fidelity.
• Alive The subject is alive
• Timely The subject participated in a timely
  exchange of information
• Specific historical data about interactions is
  used by the OLC, just not in event interpretation

CSISM uses two types of evidence to represent the
occurrence of expected actions for event
interpretation.
24
Hypotheses

• When an accusation is created a set of hypotheses
  are proposed that explain the accusation
• For example a value accusation means either the
  accuser or accused is corrupt and that the
  accuser is not dead.
• The following hypotheses (both positive and
  negative) can be proposed
• Dead Subject is dead fail-stop failure
• Corrupt Subject is corrupt
• Communication-Broken Subject has lost
  connectivity
• Flooded Subject is starved of critical resources
• OR a meta-hypothesis that either of a number of
  related hypotheses are true

Accusations lead to hypotheses about the cause of
the accusation.
25
Reasoning Structure

• Hypotheses, Accusations, and Evidence are
  connected using constraints
• The resulting graph is used for
• Coherence search
• Proving system facts

host dead
-100
accusation
100
100
OR
100
100
-400
-400
host dead
comm broken
-400
100
host corrupt
A graph is created to enable reasoning about
hypotheses.
26
Proofs about the System

• The OLC needs to derive as much certain
  information as it can, but it needs to do this
  very quickly. The OLC does model-theoretic
  reasoning to find hypotheses that are theorems
  (i.e., always true) or necessarily false
• For example, it can assume the attacker has a
  single platform exploit, and consider each
  platform in turn, finding which hypotheses are
  true or false in all cases. Then it can assume
  the attacker has exploits for two platforms and
  repeat the process
• A hypothesis can be proven true or proven false
  or have an unknown proof status
• Claims Hypotheses that are proven true

Claims are definite candidates for response
27
Coherence

• Coherence partitions the system into clusters
  that make sense together
• For example, for a single accusation either the
  accuser or the accused may be corrupt but these
  hypotheses will cluster apart
• Responses can be made on the basis of the
  partition, or partition membership when a proof
  is not available

In the absence of provable information coherence
may enable actions to be taken.
28
Protection and Cleanup

• Without oversight resources can be overwhelmed
• Due to flooding we rate limit incoming messages

• Excessive information accumulation
• We take two approaches to mitigate excessive
  information accumulation
• Removing outdated information by making it
  inactive
• If some remedial action has cleared up a past
  problem
• If new information makes previous information
  outdated or redundant
• If old information contradicts new information
• If an inconsistency occurs we remove
  low-confidence information until the
  inconsistency is removed
• When resources are very constrained more drastic
  measures are taken
• Hypotheses that have not been acted upon for some
  time will be removed, along with related
  accusations

Resources are reclaimed and managed to prevent
uncontrolled data loss or corruption.
29
Current Status and Future Plans

• Knowledge Representation
• Accusation translation is implemented
• May need to change to better align with the
  evidences
• Evidence implementation in process
• Will leverage the code and structure for
  accusation generation
• Use of coherence partition in response
  selection--ongoing
• Protection and Cleanup are being implemented
• Flood control development is ongoing
• The active/inactive distinction is designed and
  ready to implement
• Drastic hypothesis removal is still being
  designed

Much work has been accomplished, work still
remains.
30
Response Selection
Main Objectives

• Decide promptly how to react to an attack
• Block the attack in most situations
• Make gaming the system difficult
• Reaction based on high-confidence event
  interpretation
• History of responses is taken into account when
  selecting next response
• Not necessarily deterministic

31
Response Selection Decision Flow
Response Selection
Event Interpretation
Summary
propose
claims
dilemmas
potentially useful responses
responses
prune
learning
history
32
Response Terminology

• A response is an abstract OLC action, described
  generically
• Example quarantine(X), where X could be a host,
  file, process, memory segment, network segment
  etc.
• A response will be carried out in a sequence of
• response steps
• Steps for quarantine(X) isHost(X) include
• Reconfigure process protection domains on X
• Reconfigure firewall local to X
• Reconfigure firewalls remote to X
• Steps for quarantine(X) isFile(X) include
• Mark file non-exectuable
• Take specimen then delete
• A command is the input to actuators that
• implement a single response step
• Use /sbin/iptables to reconfigure software
  firewalls
• Use ADF Policy Server commands to reconfigure ADF
  cards
• Use tripwire commands to scan file systems

or
Resp1
Resp2
and
specialization
Step2
Step1
Step3
Cmd1
Cmd1
Cmd1
33
Kinds of Response

• Refresh e.g., start from checkpoint
• Reset e.g., start from scratch
• Isolate -- permanent
• Quarantine/unquarantine -- temporary
• Downgrade/upgrade services and resources
• Ping check liveness
• Move migrate component

The DPASA design used all of these except
move. The OLC design has similar emphasis.
34
Response Selection Phases

• Phase I propose
• Set of claims (hypotheses that are likely true)
  implies set of possibly useful responses
• Phase II prune
• Discard lower priority
• Discard based on history
• Discard based on lookahead
• Choose between incompatible alternatives
• Choose unpredictably if possible
• Learning algorithm will tune Phase II parameters

35
Example

• Event interpretation claims Q1PSQ is corrupt
• Relevant knowledge
• PSQ is not checkpointable
• Propose
• (A) Reset Q1PSQ, i.e., reboot, or
• (B) Quarantine Q1PSQ using firewall, or
• (C) Isolate Quad 1
• Prune
• Reboot has already been tried, so discard (A)
• Q1PSQ is not critical, so no need to discard (B)
• Prefer (B) to (C) because more easily reversible,
  but override if too many previous anomalies in
  Quad 1
• Learning
• Modify the definition of too many used when
  pruning (B)

36
Using Lookahead for Pruning

• Event interpretation provides an intelligent
  guess about the attackers capability
• OLC rules encode knowledge about attackers
  possible goals
• Lookahead estimates the potential future state,
  given assumptions about capability, goals, and
  response selection
• If response X has better potential future than Y,
  favor X

37
Status

• Design
• Rules for proposing responses encoded in
  first-order logic
• Corresponding pruning rules described in English
• Implementation
• Mounting responses for given hypotheses
  prototyped in Soar
• Actual response logic is being moved outside Soar
• Risk mitigation step
• Some specific to a particular Learning Exercise
  run

Much less complete than Event Interpretation, but
we are getting there
38
Fast Containment Response and Policies

• Michael Atighetchi
• (On behalf of Steve Harp)

39
Inner Loop Controller (ILC) Objectives
Goal Attempt to contain and correct problems at
the earliest stage possible

• Policy Driven Implement policies and tactics
  from OLC on a single host.
• Autonomous high speed responsecan work when
  disconnected from the OLC by an attack or
  failure
• Flexible Policies can be updated at any time
• Adaptive Use learned characteristics of host
  and monitored services to tune the policy.
• Low impact on mission able to back out of
  defensive decisions when warranted

40
Current ILC Policies

• Generic...
• Excessive resource consumption
• Memory, CPU load
• Tampering with component files
• Unexpected service termination
• Unexpected network connections

• Specialized...
• JBI client registration failure
• ADF Agent failure modes
• SELinux enforcement status

41
Policy Example ?
File Integrity Check Fails, F1
Local File F1 statuscorrupted
File Tampering Problem
Block Network
Suspend Affected Services
File Cleanup Subgoal
Quarantine
Restore File
Remove Block/Suspend Reasons
42
ILC Recent Work

• ILC Configuration
• Made this driven by (ontology) model of DPASA
• No need for configuration files for each host
• ILC runs on each simulated host, automatically
  loads required policy components
• Integration
• Hitherto ILC has been (unit) tested as
  stand-alone
• Initial integration with jess DPASA simulator
  complete, broadening support for multiple
  policies
• Adjustments to API to match simulator

43
ILC Current Status

• ILC policy to handle various applications
• Model driven configuration
• Metrics
• Rules 94 Functions 134 Frames 24
  Globals 20
• Base reaction time (in unit test) 4 ms.
• (Measuring the inference part only.)
• Target reaction time is lt 100 ms.

44
ILC Ongoing Work

• Complete integration with the rest of CSISM
  framework
• DPASA Simulator
• ILC---OLC Interaction
• Designed integration TBD
• Testing
• Verify correct reactions in simulator to various
  simulated attacks
• Measure reaction times

45
Learning Augmentation

• Michael Atighetchi
• (On behalf of Karen Haigh)

46
Learning Augmentation Motivation

• Why learning?
• Extremely difficult to capture all the
  complexities of the system, particularly
  interactions among activities
• The system is dynamic (static configuration gets
  out of date)
• Core Challenge

Offline Training Good data Complex
environment - Dynamic system
Online Training - Unknown data Complex
environment Dynamic system
Human Good data - Complex environment - Dynamic
system
CSISMs Experimental Sandbox Good data
(self-labeled) Complex environment Dynamic
system
Very hard for adversary to train the learner!!!
Sandbox approach successfully tried in SRS phase 1
Adaptation is the key to survival
47
Development Plan for Learning in CSISM

• Responses under normal conditions (Calibration)
• Important first step because it learns how to
  respond to normal conditions
• Showed at June PI meeting
• Situation-dependent responses under attack
  conditions
• Multi-stage attacks
• Since June

48
Calibration Results for all Registration times
Beta0.0005
These two shoulder points indicate upper and
lower limits.
As more observations are collected, the estimates
become more confident of the range of expected
values (i.e. tighter estimates to observations)
June07 PI meeting
49
Multistage Attacks

• Multistage attacks involve a sequence of actions
  that span multiple hosts and take multiple steps
  to succeed.
• A sequence of actions with causal relationships.
• An action A must occur set up the initial
  conditions for action B. Action B would have no
  effect without previously executing action A.
• Challenge identify which observations indicate
  the necessary and sufficient elements of an
  attack (credit assignment).
• Incidental observations that are either
• side effects of normal operations, or
• chaff explicitly added by an attacker to divert
  the defender.
• Concealment (e.g. to remove evidence)
• Probabilistic actions (e.g. to improve
  probability of success)

Not yet
50
Architectural Schema for Learning ofAttack
Theories and Situation-Dependent Responses
CSISM Sensors (ILC, IDS)
1
2
3
4
5
6
Observations ending in failure of protected
system. Only some are essential.
Viable Defense Strategies and Detection Rules
Viable Attack Theories
Failure
51
Multi-Stage Learner
The hard part!

• Do
• Generate Theory according to heuristic
• Complete set of theories is all permutations of
  all members of Powerset( observations )
• Test Theory
• Incrementally Update OLC / ILC rulebase
• while Theories remain

52
Heuristics Structure of Results

• Primary Goal Find all shortest valid attacks
  (i.e. minimum required subset) as soon as
  possible
• Example In ABCDE, AC and DE may both be valid
• Secondary Goal Find all valid attacks as soon as
  possible
• Example In ABCDE, ABC may also be valid
• Heuristics
• Shortest first
• Longest first
• Edit distance to original
• Dynamic resort to valid set
• Initially, edit distance to the original attack
• Remaining theories are compared to all valid
  attacks edit distance is averaged
• Dynamic Resort / Free to remove chaff
• Same as Dynamic Resort to valid set, but cost
  of deletion is zero
• Worst Case Comparison Sort theories so that
• Shortest valid attack is found last
• All valid attacks at the end

53
Comparison of Heuristics
4-observation 3-stage attack 4 obs 64
potential trials 10 obs 10 million potential
trials
54
Incremental Hypothesis Generation

• Enhanced query learner generates attack
  hypotheses
• incrementally, with low memory overhead it is
  able to explore large observation spaces (gtgt8
  steps)
• in heuristic order to acquire the concept
  rapidly
• Heuristic bias
• look for shorter attacks first (adjustable prior)
• suspect order of steps has an influence
• suspect steps to interact positively (for the
  attacker)
• performance comparable to edit-distlength

55
Incremental Hypothesis Generation Results

• Target concept The disjunction ".A.B." or
  ".B.C."
• Scores represent sum of trial numbers for
  elementary concepts
• Note
• There are many possible observation sequences
  that could generate these target concepts scores
  is average of 8 of the sequences
• For observation sequences longer than 8, learners
  that pre-enumerate and sort their queries run out
  of memory

SONNI Short-Ordered-NonNegative Incremental
Hypothesis Generator
56
Status, Development Plan Future steps

• June07 PI Meeting
• Responses under normal conditions (Calibration)
• Analyze DPASA data (done)
• Integrate with ILC (single node) (done)
• Add experimentation sandbox (single-node)
• Calibrate across nodes
• Situation-dependent responses under attack
  conditions
• Multi-stage attacks

• Since June
• Development of sandbox, and initial integration
  efforts with learner (done)
• Attack actions, observations, and control actions
• Quality signal
• Development of multistage algorithm (version 1.0
  done)
• Theories with sandbox
• Incremental generation of theories
• TODO ILC input / OLC output

57
Simulated Testbed

• Michael Atighetchi
• (on behalf of Michael Atighetchi)

58
Why Simulation ?
Defense-Enabled JBIas tested under OASIS Dem/Val

• Simulation of defense-enabled system
• Use a specification
• Use as integration middleware
• Use for red team experimentation

59
JessSim The JESS Simulator
Implemented via JESS rules and functions
Generatedvia Protégé plugin
60
JessSim Current Status

• Implemented Protocols (14)
• Plumbing (5 rules)
• Alert (6 rules)
• Registration (8 rules)
• SELinux (1 rule)
• Reboot (3 rules)
• LC message (3 rules)
• ADF (3 rules)
• Heartbeat (1 rule)
• PSQ (3 rules)
• Tripwire (3 rules)
• ServiceControl (1 rule)
• POSIX Signals (1 rule)
• Process Memory/CPU status (2 rules)
• Host Memory/CPU status (2 rules)

Implemented Attacks (8) Avail Disable SELinux
service Avail Shutdown a host Avail Cause a
Downstream Controller to crash Avail Cause
corruption of endpoint references in SMs Avail
Killing of processes via kill -9 Integrity
Corruption of files Policy Violation Creation of
a new (rogue) process Avail Causing a process to
overload CPU

• Test Coverage
• Unit tests 28 junit tests covering protocol
  details
• OASIS Dem/Val Main events of DPASA Run 6.
• Fidelity
• Focused on application-level protocols

61
JessSim Ongoing Work

• Increase fidelity of network simulation
• checks for network connectivity crash(router)
  gt com broken (A,B)
• Simulation of TCP/IP flows for ILC
• Increase fidelity of host simulation for ILC
• install-network-block / remove-network-block
• note-network-connection / reset-network-connection

• quarantine-file / restore-file / delete-file /
  checkpoint-file
• note-selinux-down / note-selinux-up
• shun-network-address / unshun-network-address
• Enable-interface / disable-interface
• Set-boot-option
• Protocols for ILC/OLC communication
• forward-to-olc()
• Cleanup
• Convert all time unit to seconds in all scenarios

62
Next Steps Integration and Evaluation

• Partha Pal

63
Learning Integration

• ILC Learning
• Pre-deployment calibration learn threshold
  parameters for registration times
• Calibrate across nodes
• OLC-Learning
• Results from learning with the experimentation
  sand box
• Parameter tuning
• New rules/heuristics

64
ILC lt-gt OLC Integration

• ILC-gtOLC
• Calls to OLC implemented in ILC policies via
  calls to ilc-api
• ILC as an Informant to OLC
• ILC as Henchman of OLC
• OLC-gtILC
• OLC can process alerts forwarded to it from the
  ILC
• Consider ILC as a mechanism during response
  selection

65
JessSim Integration

• ILC integration with jessSim
• ArrestRunawayProcess loop working
• Implement file, network, and reboot protocols
  necessary to support other existing ILC loops
• OLC integration with jessSim
• OLC fully integrated with jessSim
• Adjust integration given changes due to
• Moving transcription logic Alerts-gtAccusation,
  Observations-gtEvidence into Jess
• Performing response selection in Jess
• Integration Framework
• All components execute within a single JVM
• Support execution of ILC and OLC on dedicated
  hosts to measure timeliness.

66
Integration FrameworkCurrent Status
67
Integration FrameworkNeeded for Red Team
Experimentation
68
Evaluation

• Interaction with Red and White Teams
• Initial telecon (Late October)
• Continued technical interchange about CSISM
  capabilities
• Potential gaps/disagreements
• How to use the simulator
• Evaluation goals
• Next steps
• Demonstration of the system
• Red team visit
• Code drop
