Building Science Gateways with EnginFrame Life
Science example
Maurizio Melato e-mail maurizio_at_nice-software.com
2
At the beginning
Aliases
Scripts
NFS
FTP

• At the beginning was the command line

Restart
Repository
DOE

• At first glance, simple tools and technology,
  light
• but the complexity handled by users arose and
  arose

Teamwork
Versioning
LSF
Scripting
Library
Disk quota
CLI
Windows
CRASH!
Compute-/Data-Grid Middlewares
Queue
Linux
Convert
IP Protection
Resource
Working directory
Password
Execution host
FlexLM
3
The Web (r)evolution

• Web interface to the Grid Grid Portals

• At first glance, the all-purpose-every-day-do-ever
  ything solution
• Portals as glue-technology integrate services,
  tools and applications
• Users may have various level of customizations on
  both layout and contents
• They are general purpose and any specific need
  requires to be addressed and developed.

Grid Portal
Scripting
CLI
Compute-/Data-Grid Middlewares
4
The Science Gateway perspective

• A community-developed set of tools, applications,
  and data that is integrated via a portal or a
  suite of applications

• SGs are specializations of Portals for specific
  scientific communities.
• SG is customized to meet the needs of the
  targeted community
• SG provides a a common interface configured for
  optimal use.
• SG allows researchers to focus on their research
  and fostering collaborations

Portal
Scripting
CLI
Compute-/Data-Grid Middlewares
Other Community specific Data Sources
Distributed and heterogeneous Data Sources
Distributed and heterogeneous Computing
Resources (Grid/Compute/Visualization Farm)
5
The Science Gateway perspective

• Gateways are independent projects, each of which
  has its own guidelines, requirements and
  constraints.
• But they have similar technological challenges
• Compute-/Data-Grid integration
• Authentication/Authorization
• Collaboration mechanisms
• Tools Application integration
• Does the wheel need to be reinvented every time??
• ? Need of Scientific Gateway Framework technology

6
Science Gateway Capabilities

• Depend on the needs of the specific community
• Authentication and Authorization
• Job Execution Services
• Domain-Specific Computational Applications
• Resource Discovery
• Access to Data Collections
• Data Movement Tools
• Visualization Hardware and Software
• Workflows

7
SG Authentication and Authorization

• Satisfy the authentication and authorization
  security constraints of the community
• Integrating with the target authentication
  technology
• Providing the proper authorization mechanism

• Configurable authentication mechanims
• NIS
• PAM
• LDAP
• Windows ActiveDirectory
• MyProxy
• X509 Certificates
• Krb5
• Built-in Authorization system with extension
  points
• e.g. custom inheritance of group definitions

8
SG Job Execution Services

• Preparation, submission, monitoring and result
  retrieval

• Born as abstraction layer and interface on the
  underlying Job Scheduler
• Supports many Job Schedulers

9
SG Domain-Specific Computational Applications

• Provide high-level vertical services

• Computing Portal was initially adopted by
  Industrial communities
• Automotive
• Manufacturing
• Electronics
• Oil Gas
• Telecommunication
• Life Sciences
• and Research Institutions
• INFN - National Institute of Nuclear Physics
• CILEA Lombard Inter-university Consortium for
  Automatic Computation
• CERN

10
A growing number of customers
10

• Energy Utilities
• Addax Petroleum, AECL, Amerada Hess, British Gas,
  CC of Water Resources, Chevron, Conoco-Phillips,
  DSC-Libya, ENI/Agip, GazPromNeft, Marathon Oil,
  Nexen, Rosneft, Schlumberger, Sibneft, Sinopec,
  Slavneft, Sonatrach, Statoil, Talisman Energy,
  Telecom Italia, TNK-BP, TNNC, TOTAL,
  TyumenNIIGaz, VNIIGaz, Xinjiang Oil

Aerospace Manufacturing AIRBUS, Air Products
and Chemicals, ProcterGamble, Galileo Avionica,
Hamilton Sunstrand, Kimberly Clark, Magellan
Aerospace, MTU, Northrop Grumman, PW, Raytheon,
Simpson Strong-Tie
Automotive Industrial Equipment Audi, ARRK,
Bridgestone, Bosch, Corus Automotive, Delphi,
Elasis/CRF, Ferrari, Brawn GP, Jaguar-LandRover,
Lear, Magneti Marelli, McLaren, PZ, PSA, RedBull
Engineering, Swagelok, Suzuki, Toyota, TRW,
Volkswagen
Life Sciences LitBio project, DEISA project,
Biolab, Swiss Institute for Bioinformatics,
Partners Healthcare, M.D. Anderson Cancer Center
Research Education ASSC, CCLRC, CERN, CILEA,
CINECA, CNR, CNRS/IN2P3, ENEA, FzU, ICI, IFAE,
INFN, ITEP, Harvard Business School, SSC-Russia,
SDSC, Ferrara Uni, ITU, T.U.Dresden, Trinity
College Dublin, Huazhong Normal Uni, Yale
University
High Tech STMicroelectronics, Accent, Samsung
SDI, SensorDynamics, Motorola
11
Which applications are used in EnginFrame?
12
EnginFrame snapshots Technology Overview

• Services are XML description defining
• Input parameters
• The action to accomplish (Unix/Windows script,
  Java, )

13
EnginFrame Customizable Job Submission
13
User friendly, Application-oriented Job submission
Flexible and efficient Input file management
Ties in with dynamic enterprise data - Such as
databases
14
Interactive job submission
Hide complexity of Underlying scheduler
15
Monitoring control
Global Job monitoring
Cluster host monitoring
Job details control
16
Output management
Data lifecycle managemnet
Comprehensive output File manipulation (view,
edit, delete, zip, )
Follow-up actions support
RESUBMIT jobs Rapidly edit input files and
re-submit with same parameters/settings?
17
SG Resource Discovery

• The ability to dynamically discover resources and
  available services
• To build an indexed collections of the resources

• New defined services are dynamically published
  according to authorization settings
• EF relies on the underlying Grid middlewares for
  query the availability of new hardware or
  software resources
• In A-WARE EU Project custom functionality for
  dynamic discovering of third party services.

18
SG Access to Data Collections

• The ability to access, query and retrieve data
  collections and their metadata

• EF plugins provide integration with
• gLite Storage and AMGA metadata system
• SRB / iRODS datagrid middlewares
• Functionalities
• Browse data collections
• search metadata
• Integrated file-system view
• Read and search various audit data
• Seamless authentication and user mapping
• Define and run rules

19
SG Data Movement Tools

• The capability to provision the required data to
  a specific location considering network,
  performance, caching concerns

• Browsing of local or remote Grid filesystem can
  be transparent to users
• Specific services can move data accordingly to
  users needs
• No analysis is currently performed on performance
  or network latency concerns

20
EF Data Management
Flexible and efficient Input file management
21
EF Data Management
Data lifecycle management
View or stream Output files
22
SG Workflows

• The possibility to design and run workflows (aka
  virtual experiments) made up of basic tasks
  with inter-dependencies

• Workflow technologies integrated
• Taverna, EF used as a third party webservice
  provider
• Moteur, batch Taverna workflows enactor
• EU Project A-WARE aimed to develop a Grid
  worlkflow system
• UNICORE Grid middleware
• BPMN/BPEL

23
EF and Workflows

• EF Moteur

24
EF and Workflows

• EF in A-WARE

25
SG Visualization Software

• Provide high-end visualization tools to
  visualize, work and collaborate with complex / 3D
  interactive applications

• EF Remote visualization integrates
• RealVNC
• TurboVNC and VirtualGL
• Nomachine NX
• 3D Optimization technologies
• IBM Deep Computing Visualization (DCV)
• HP Remote Graphics Software (RGS)
• Sun OpenGL
• Session Management from the Web
• Collaboration capabilities via session sharing

26
EF Visualization
IBMDCV
27
EF Visualization Seamless Interactive
Application Integration
28
Portal case study Remote 3D visualization
28
See demo online!
Application isolation (users do not need access
to command line)?
Collaborate
29
Life Science Application Example

• How many steps you need to build and run your own
  application in EnginFrame portal?
• How much development effort it will take?
• Going practical... Here the steps an EF developer
  should follow to build and expose his own
  application
• The use case is a Survival Analysis service
• The service performs an analysis on data from
  different domains and with different tools

30
Step 0 Use case analysis

• Analyse large microarray datasets for breast
  cancer prognosis assessment
• Concatenate clinical data and microarray results
• Mix of custom and R/Bioconductor programs
• Automatic analysis and plot creation

Demo available at http//ada.dist.unige.it8080/
enginframe/bioinf
31
Step 1 Prepare Components

• Choose the pieces you already have
• Existing R and Bioconductor analysis scripts
• Existing CLI tools with parameters
• A bit of directory structure on the filesystem
• Bash (or similar) script you have to submit code
• Nothing is automagic but the probability you
  will be able to recycle existing work is really
  high
• If not, we're talking about 50 lines of bash
  script!

32
Step 2 The EF Service Definition File
33
Step 3 and the corresponding Web GUI
Just custom background !
Submission form
34
Step 4 Monitor Execution
35
Step 5 View Results!
36
The End

• Thanks for your attention!

37
EnginFrame Architecture (detail)
Plugins

Skins / Themes
Template-based dynamic presentation engine with
AJAX support
Single-Sign-On
Auth. delegation
ACL manager
Channel security
Usage acct./billing engine
User mapping
Session manager
GUI Virtualization
Service chaining
Distributed file manager
Custom XML Application Kits
Data life-cycle manager
Multi-language services
Workflow Engine
GridML virtualization
Data virtualization
App. virtualization
38
EnginFrame Process
Service Request
EnginFrame Server
XSLT
Execute
Authorize
39
(No Transcript)
40
Bioinformatics Challenges

• Analyze large datasets ? big computational effort
• Store big amount of data ? data management needs
• Access to distributed data
• Make experiments automated and reproducible
• Integrate heterogeneous tools and data
• Ease accessibility usability
• Increase quality of experiments

41
(No Transcript)
42
Increasing complexity...

• What about the possibility to create a unique
  virtual working environment between
  geographically distributed sites ?
• What about the possibility to run applications
  and data randomly distributed on different sites?
• This scenario has already
• been experimented in ...
• DEISA project!

43
The DEISA Project

• Market
• Gov Life Sciences
• Value proposition
• User-friendly portal for the Life Science user
  community (VO)?
• Context
• 2 largest European Grid
• Connects the 11 largest HPC centers in Europe
• Complex security policies
• Multiple schedulers
• Solution
• NICE EnginFrame
• NICE DataGate
• Custom enhancements (will be included in v5.x)?

www.deisa.org

• Benefits
• IT App managers happy not to re-invent the
  wheel
• HPC centers want it locally, too
• Excellent reference

44
The Portal for Life Sciences community
45
(No Transcript)
46
Harnessing grid computing to save womens lives
Case Study HealthCare

• Genetics Analysis

Screening Mammography
Together for a better diagnosis/prognosis
47
Case Study Neuroinf.it (EGEE)

• Market
• Research Life Sciences
• Value proposition
• Distributed access to medical images across
  hospitals and remote processing
• 3D remote visualization of medical images
• Context
• 1 largest European Grid
• Privacy must be assured

• Solution
• EnginFrame used as application interface and data
  grid resource manager

48
Remote 3D Visualization
49
(No Transcript)
50
Why EnginFrame Elements?

• Ease of use for small HPC clusters
• Empowered end users
• Lack of Sysadmin with focus on HPC
• Low customization needs
• SSH replacement
• Simplified sales and delivery process
• No upfront services or customization required
• Next-next-next installation
• Suitable as differentiator for hardware sales
• Low budget solution
• License at 95 / node / year
• Premium support at 3900/year every 50 users

51
My HPC Dashboard
52
Managing files
53
Interactive access
54
Job monitoring
55
Cluster monitoring
56
WYSIWYG service editor
