1Setup DG-104SH (H.323) Hunt Group
function (connecting to DPH-100) Using Web Browser
2DG-104SH and DPH-100 (H.323) Connection Diagram
RadVision Gatekeeper
IP 10.47.80.26
Switch
DPH-100 IP 10.1.1.110 Codec 723 F/W R32
DG-104SH IP10.1.1.105 Codec 723 F/W 1.0B12-G
1.0B32-G
TEL 5001
TEL 6004
TEL 6001
TEL 6002
TEL 6003
3Step 1. Create Phone No. from 60016004 for port
14
4Step 2. Check ATPM Destination Table
Then, you can see the ATPM Destination Table
shown as above Destination ID 14 means
port1port4
5Step 3. Adding Hunt Group (I)
Go the ATPM Hunt Group Table, and click Add
icon to create your Hunt Group.
6Step 4. Adding Hunt Group (II)
Adding Hunt Group 5, and the group include
Destination IDs 1,2,3,4 (port1port4), then click
Save
7Step 5. Check Hunt Group Table
Then you can see the Hunt Group table shown as
above
8Step 6. Create Dial No. in ATPM Address Table (I)
Go the ATPM Address Table, and click Add icon
to create a Dial No. for this Hunt Group.
9Step 7. Create Dial No. in ATPM Address Table(II)
Adding Dial No. 6000 for Hunt Group 5, and the
min and max digits is 4, then click Save
10Step 7. Check ATPM Address Table
Then you can see the Address table shown as above
11Step 7. Remember to Save Changes
Click Save Changes to save and reboot this
device.
12Result
- While DPH-100 Call 6000(Hunt Group),
Phone1(6001) will ring. - While DPH-100 Call 6000(Hunt Group),
Phone1(6001) is busy then Phone2(6002) will
ring. - While DPH-100 Call 6000(Hunt Group),
Phone1(6001) is busy and Phone2(6002) is also
busy then Phone3(6003) will ring. - While DPH-100 Call 6000(Hunt Group),
Phone1(6001) is busy and Phone2(6002),
Phone3(6003) are also busy then Phone4(6004)
will ring.
13Remark
1) For Hunt Group issues, please check our define
and setting example as below Creating a "Hunt
Group" by setting up a series of phones that
forward busy to the next phone in the Group. In
this situation, all phones do not ring at one
time. A "Hunt Group" is a group of lines that are
organized hierarchically so that if the first
number in the "Hunt Group" list is busy, the
second number is dialed. If the second number is
busy, the next number is dialed, and so on.
Assume you have a Hunt Group with a number of
6000, and a "Hunt Group" defined with a list of
phones like the following o Phone B has
extension 6001 o Phone C has extension 6002
o Phone A has extension 6003 o Phone A has
extension 6004
