IC Layout Techniques

1
IC Layout Techniques
Saravanan Ramamoorthy
2
N Well
3

• Source and Drain

4

• Gate or poly

5

• Metal 1 Contact

6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
DRC

• (Design Rule Check)

10

• RX Active region ( gate oxide and N-/P
  diffusion region )
• NW N-Well region
• PC Polysilicon line (gate of the
  transistor)
• BP Area which are blocked from P
  source and drain implant
• CA Square stud contact which contacts
  either RX or PC to M1
• M1 First level thin metal layer
• V1 Square vias for connecting M1 to M2


11

• Minimum length and width of CA should be 0.2um

12

• Minimum overlap of CA by M1 should be
  0.02um

13

• Min overlap of CA by RX should be 0.1um

14

• Min distance between CA should be 0.24um

15

• Min distance between CA and PC should be 0.16um

16

• Min PC width should be 0.18um

17

• Min distance between PC should be 0.24um

18

• Min distance from RX to PC and BP should be
  0.24um and 0.36um respectively

19

• Min overlap of RX by N well should be 0.42um

20

• Min distance between RX should be 0.26um

21

• Min M1 width should be 0.24um

22

• Min distance between M1 should be 0.2um

23

• Min length and width for V1 should be 0.28um

24

• Min M2 width should be 0.28um
