GRASP: More Objects with Responsibilities

1
GRASP More Objects with Responsibilities

• Chapter 25
• Applying UML and Patterns
• Craig Larman

Prepared By Krishnendu Banerjee
2
Objectives

• Learn to apply the following GRASP patterns
• Polymorphism
• Pure Fabrication
• Indirection
• Protected Variations

3
Introduction

• GRASP stands for General Responsibility
  Assignment Software Patterns.
• It is a learning aid of fundamental principles by
  which responsibilities are assigned to objects
  and objects are designed.
• We already learned about the first five GRASP
  patterns
• Information Expert, Creator, High Cohesion, Low
  Coupling, Controller

4
Introduction

• In this presentation we will look at four new
  GRASP patterns
• Polymorphism
• Indirection
• Pure Fabrication
• Protected Variations

5
Polymorphism

• Problem
• Who is responsible when behaviors vary by type?
• How to handle alternatives based on type?
• How to create pluggable software components?

6
Polymorphism

• Solution
• Polymorphism is a fundamental principle in
  designing how a system is organized to handle
  similar variations.
• When related alternatives or behaviors vary by
  type (class), assign responsibility for the
  behavior using polymorphic operations to the
  types for which the behavior varies.

7
Polymorphism

• UML Notation for Interfaces and Return types

8
Polymorphism Example

• NextGen POS application supporting multiple Tax
  Calculators is a polymorphic operation.

9
Polymorphism Example
10
Polymorphism Contraindications

• Developers may not critically evaluate true
  likelihood of variability before investing in
  increased flexibility.
• Developers may indulge in speculative
  future-proofing against unknown possible
  variations.

11
Polymorphism Benefits

• Extensions required for new variations are easy
  to add.
• New implementation can be introduced without
  affecting clients.

12
Pure Fabrication

• Problem
• What object should have the responsibility, when
  you do not want to violate High Cohesion and Low
  Coupling, or other goals, but solutions offered
  by Information Expert are not appropriate?

13
Pure Fabrication

• Solution
• Assign a highly cohesive set of responsibilties
  to an artificial class that does not represent a
  problem domain concept - something made up, in
  order to support high cohesion and low coupling
  and reuse.

14
Pure Fabrication Example

• Suppose there is a requirement to save the Sale
  instances in a relational database.
• Per Information Expert, this responsibility would
  be assigned to the Sale class itself, because the
  sale has the data that needs to be saved.

15
Pure Fabrication Example

• But the above solution leads to
• Low Cohesion Including tasks not related to the
  concept of sale-ness.
• High Coupling The Sale class is coupled to the
  relational database interface.
• Low Reusability The general task of saving to
  the database may be needed by other classes.
  Assigning it to Sale class causes poor reuse and
  lots of duplication.

16
Pure Fabrication Example

• A reasonable solution is to create a new class
  that is solely responsible for saving objects.
  This class is a Pure Fabrication.

17
Pure Fabrication Contraindications

• Behavioral decomposition into pure fabrication to
  object design and more familiar with decomposing
  or organizing objects is sometimes over used by
  those new software in terms of functions.

18
Pure Fabrication Benefits

• High Cohesion is supported because that only
  focuses on a very specific responsibility are
  factored into a fine grained class set of related
  tasks.
• Reuse potential may be increased because of the
  presence of fine grained pure fabrication classes.

19
Indirection

• Problem
• Where to assign a responsilibity, to avoid direct
  coupling between two or more things?
• How to de-couple objects so that low coupling is
  supported and reuse potential remains higher?
• Solution
• Assign the responsibilty to an intermediate
  object to mediate between other components so
  that they are not directly coupled.

20
Indirection Example

• Tax Calculator Adapter
• These objects act as intermediaries to the
  external tax calculators. By adding a level of
  indirection and adding polymorphism, the adapter
  objects protect the inner design against
  variations in the external interfaces.

21
Indirection Example
22
Indirection Benefits

• Low Coupling between components.

23
Protected Variations

• Problem
• How to design objects, subsystems and systems so
  that the variations or instability in these
  elements does not have an undesirable impact on
  other elements?
• Solution
• Identify points of predicted variation or
  instability assign responsibilities to create a
  stable interface around them.

24
Protected Variations

• PV is the root principle motivating most of the
  mechanism and patterns in programming and design
  to provide flexibility and protection from
  variation.
• It is essentially the same as David Parnass
  information hiding and Bertrand Meyers
  Open-Close Principle.

25
Protected Variations Mechanisms

• Core Protected Variation
• Data encapsulation, interfaces, polymorphism,
  indirection.
• Data Driven Design
• Reading codes, class file paths, class name.
• Service Lookup
• JNDI, LDAP, Javas Jini, UDDI.

26
Protected Variations Mechanisms

• Interpreter Driven Design
• Rule interpreters, virtual machines, neural
  network engines, logic engines.
• Reflective of Meta-level Design
• Java introspector
• Uniform Access
• Language supported constructs that do not change
  with change in underlying implementation.

27
Protected Variations Mechanisms

• The Liskov Substitution Principle (LSP)
• Software methods that work with a class T should
  work with all subclasses of T.
• Structure-Hiding Design
• Places constraints on what object you should send
  messages to within a method.

28
Protected Variations Example

• In the external tax calculator problem, the point
  of instability is the different interfaces to the
  external tax calculators.
• By adding a level of indirection, an interface,
  and using polymorphism with various adaptors,
  protection within the system from variations in
  external calculator APIs is achieved.

29
Protected Variations Contraindications

• The cost of speculative future-proofing at
  evolution point may outweigh the cost incurred by
  a simple design that is reworked as necessary.
  Evolution point is a speculative point of
  variation that may arise in future, but not
  specified in current requirement.

30
Protected Variations Benefits

• Extensions required for new variations are easy
  to add.
• New implementations can be introduced without
  affecting clients.
• Coupling is lowered.
• The impact or cost of changes be lowered.
